316 Stainless Steel Pipe
316 STAINLESS STEEL PIPE SCHEDULE 40, STAINLESS STEEL 316 PIPE MANUFACTURER IN INDIA, 316 STAINLESS STEEL PIPE SCHEDULE 80 , STAINLESS STEEL 316 WELDED PIPES EXPORTER IN INDIA
Siddhgiri Exports is a prominent stockist & supplier of 316 stainless steel pipe that is manufactured from high quality of raw materials as per national and international standards. Kamal Steel Industries stock & sell a wide range of SS 316 Pipe includes Stainless Steel 316 square Pipe, SS 316 rectangular Pipe, Stainless Steel 316 Exhaust Pipe, Stainless steel 316 oval Pipe, Stainless Steel 316 Hollow Pipe, and Stainless Steel 316 Round Pipe are used for piping systems in various industrial applications. Buy SS 316l pipe at best price. Stainless steel 316 Pipes are being used in different industries such as petrochemicals & pumps, cement & construction industries, sugar mills, and others. We have a well reputed name as stainless steel 316 seamless & welded pipe Supplier.
316 Stainless Steel Pipe SPECIFICATION
316 STAINLESS STEEL PIPE DESCRIPTION 316 SS Pipe is made from between 70 % to 90 % recycled materials are fully recyclable at the end of their lifecycles. Stainless Steel 316 Seamless Pipe have excellent weld-ability, with or without the addition of filler metal. Type Stainless Steel 316 Pipe exhibit better corrosion resistance and are stronger at elevated temperatures. Annealing of SS 316 Welded Pipes requires heating to between 1,900 and 2,100 degrees Fahrenheit (1,038 to 1,149 degrees Celsius) before rapidly quenching. We are well reputed as a SS 316 pipe supplier, we supply these SS Seamless 316 Pipe after all quality parameters checks by experienced and well knowledgeable staff. We have a huge inventory of 316 Stainless Steel Pipe in both forms Seamless and welded. Our inventories primarily consist of Stainless Steel 316 Seamless Pipe in a size range from 1/2” to 8” NB. We can also supply stainless steel 316 pipe with an abrasive polished finish and Polish Grit 600 -1200 suitable for architectural applications.
Specification
Specification | Description |
Size | 12.75 X 12.75, 15 X 15, 20 X 20, 25 X 25, 30 X 30, 40 X 40, 50 X 50, 60 X 60, 75 X 75, 80 X 80, 90 X 90, 100 X100 |
Grade | TP - 304/L/H, TP - 316/L/H/Ti, TP - 317L, TP - 321/H, TP - 347/H, 202, JT - 7, J4 - 1, TP - 409/L, TP - 410, TP - 430Ti, TP 439 |
Standards | ASTM A249 - A269 - A312 - A358 - A409 - A554 - A778 - A789 - A790 |
TOLERANCE on Length | Commercial Length: 6000mm +/- 30mm Fix Length: from 1200 mm up to 12000mm with a tolerance up to -0/+ 5mm |
Finish | Oval Grit 120 - 600, Seamless, Welded, Brushed, Pickled, Solution Annealed and Pickled up to O.D. 219.1mm,Mirror Oval |
316 Stainless Steel Pipe Ploishing Machine, SS Square Pipes, SS Square Pipe Dealer in India, High Quality 316 Stainless Steel Pipe, 316 Stainless Steel Pipes Exporter in India, 316 Stainless Steel Pipes for Architectural Applications, SS Square Pipe for Petrochemical Plants, Stainless Steel Square Oval Sections, Seamless 316 Stainless Steel Pipes. SUPPLIERS OF 316 Stainless Steel PipeS, 316 Stainless Steel Pipe EXPORTER, SS 304 SQUARE PIPE WEIGHT CHART, 304 SQUARE STEEL PIPES, SS 316 SQUARE PIPE SUPPLIER IN MUMBAI, INDIA.
316 Stainless Steel Pipe SIZES
SS Square pipes are finished in accordance with customer needs regarding dimensional and wall thickness specifications as well as heat treatment for more demanding applications. In general a 316 Stainless Steel Pipe is manufactured in sizes from 1/8” to 24” according to current standards ASTM, API and ASME. If required for special projects we can also supply SS Square seamless pipes & SS Square welded pipes for bigger sizes starting from outside diameter 26” up to 48”. More Information of Stainless Steel Pipe Sizes and 316 Stainless Steel Pipe weight chart
- • Machinery
- • Automative
- • Transport
- • construction
- • Home and commercial fixtures
316 Stainless Steel Pipe DIMENSIONS AND WEIGHTS
MM | 0.65 | 0.80 | 0.90 | 0.95 | 1.00 | 1.20 | 1.50 | 2.00 | 2.50 | |
12.5 x 12.5 | 0.075 | 0.091 | 0.102 | 0.107 | 0.112 | 0.133 | 0.163 | |||
20 x 20 | 0.176 | 0.184 | 0.220 | 0.271 | 0.354 | 0.433 | 0.508 | |||
25 x 25 | 0.221 | 0.232 | 0.277 | 0.343 | 0.450 | 0.553 | 0.652 | |||
30 x 30 | 0.267 | 0.280 | 0.335 | 0.415 | 0.516 | 0.673 | 0.796 | |||
38 x 38 | 0.340 | 0.358 | 0.427 | 0.531 | 0.700 | 0.866 | 1.027 | |||
40 x 40 | 0.358 | 0.376 | 0.450 | 0.559 | 0.738 | 0.898 | 1.084 | |||
50 x 50 | 0.473 | 0.565 | 0.703 | 0.930 | 1.153 | 1.372 |
Stainless Steel Square Oval Section / Size / Dimensions / Weight Chart
Size (mm) | Thickness (mm) | Kg / Metre |
---|---|---|
20 X 20 Size (mm) | 2 Thickness (mm) | 1.11 Kg / Metre |
25 X 25 Size (mm) | 2 Thickness (mm) | 1.43 Kg / Metre |
25 X 25 Size (mm) | 2.5 Thickness (mm) | 1.74 Kg / Metre |
25 X 25 Size (mm) | 3 Thickness (mm) | 2.04 Kg / Metre |
30 X 30 Size (mm) | 2 Thickness (mm) | 1.74 Kg / Metre |
30 X 30 Size (mm) | 2.5 Thickness (mm) | 2.14 Kg / Metre |
30 X 30 Size (mm) | 3 Thickness (mm) | 2.51 Kg / Metre |
30 X 30 Size (mm) | 3.2 Thickness (mm) | 2.65 Kg / Metre |
40 X 40 Size (mm) | 2 Thickness (mm) | 2.37 Kg / Metre |
40 X 40 Size (mm) | 2.5 Thickness (mm) | 2.92 Kg / Metre |
40 X 40 Size (mm) | 3 Thickness (mm) | 3.45 Kg / Metre |
40 X 40 Size (mm) | 4 Thickness (mm) | 4.46 Kg / Metre |
40 X 40 Size (mm) | 5 Thickness (mm) | 5.40 Kg / Metre |
50 X 50 Size (mm) | 2 Thickness (mm) | 3.00 Kg / Metre |
50 X 50 Size (mm) | 2.5 Thickness (mm) | 3.71 Kg / Metre |
50 X 50 Size (mm) | 3 Thickness (mm) | 4.39 Kg / Metre |
50 X 50 Size (mm) | 4 Thickness (mm) | 5.72 Kg / Metre |
50 X 50 Size (mm) | 5 Thickness (mm) | 6.97 Kg / Metre |
50 X 50 Size (mm) | 6 Thickness (mm) | 8.20 Kg / Metre |
50 X 50 Size (mm) | 8 Thickness (mm) | 10.50 Kg / Metre |
60 X 60 Size (mm) | 3 Thickness (mm) | 5.34 Kg / Metre |
60 X 60 Size (mm) | 3.2 Thickness (mm) | 5.67 Kg / Metre |
60 X 60 Size (mm) | 3.6 Thickness (mm) | 6.34 Kg / Metre |
60 X 60 Size (mm) | 4 Thickness (mm) | 6.97 Kg / Metre |
60 X 60 Size (mm) | 5 Thickness (mm) | 8.54 Kg / Metre |
70 X 70 Size (mm) | 2.5 Thickness (mm) | 5.28 Kg / Metre |
70 X 70 Size (mm) | 3 Thickness (mm) | 6.28 Kg / Metre |
70 X 70 Size (mm) | 3.5 Thickness (mm) | 7.25 Kg / Metre |
70 X 70 Size (mm) | 3.6 Thickness (mm) | 7.46 Kg / Metre |
70 X 70 Size (mm) | 4 Thickness (mm) | 8.23 Kg / Metre |
70 X 70 Size (mm) | 5 Thickness (mm) | 10.10 Kg / Metre |
70 X 70 Size (mm) | 8 Thickness (mm) | 15.29 Kg / Metre |
70 X 70 Size (mm) | 10 Thickness (mm) | 19.13 Kg / Metre |
80 X 80 Size (mm) | 3 Thickness (mm) | 7.22 Kg / Metre |
80 X 80 Size (mm) | 3.5 Thickness (mm) | 8.35 Kg / Metre |
80 X 80 Size (mm) | 3.6 Thickness (mm) | 8.59 Kg / Metre |
80 X 80 Size (mm) | 4 Thickness (mm) | 9.48 Kg / Metre |
80 X 80 Size (mm) | 5 Thickness (mm) | 11.70 Kg / Metre |
80 X 80 Size (mm) | 6 Thickness (mm) | 13.80 Kg / Metre |
80 X 80 Size (mm) | 6.3 Thickness (mm) | 14.40 Kg / Metre |
80 X 80 Size (mm) | 8 Thickness (mm) | 17.83 Kg / Metre |
80 X 80 Size (mm) | 10 Thickness (mm) | 21.88 Kg / Metre |
90 X 90 Size (mm) | 3 Thickness (mm) | 8.16 Kg / Metre |
90 X 90 Size (mm) | 3.5 Thickness (mm) | 9.45 Kg / Metre |
90 X 90 Size (mm) | 3.6 Thickness (mm) | 9.72 Kg / Metre |
90 X 90 Size (mm) | 4 Thickness (mm) | 10.70 Kg / Metre |
90 X 90 Size (mm) | 5 Thickness (mm) | 13.30 Kg / Metre |
90 X 90 Size (mm) | 6 Thickness (mm) | 15.70 Kg / Metre |
90 X 90 Size (mm) | 6.3 Thickness (mm) | 16.40 Kg / Metre |
90 X 90 Size (mm) | 8 Thickness (mm) | 20.32 Kg / Metre |
90 X 90 Size (mm) | 10 Thickness (mm) | 25.53 Kg / Metre |
100 X 100 Size (mm) | 3 Thickness (mm) | 9.10 Kg / Metre |
100 X 100 Size (mm) | 4 Thickness (mm) | 12.00 Kg / Metre |
100 X 100 Size (mm) | 5 Thickness (mm) | 14.80 Kg / Metre |
100 X 100 Size (mm) | 6 Thickness (mm) | 17.60 Kg / Metre |
100 X 100 Size (mm) | 6.3 Thickness (mm) | 18.40 Kg / Metre |
100 X 100 Size (mm) | 8 Thickness (mm) | 22.90 Kg / Metre |
100 X 100 Size (mm) | 10 Thickness (mm) | 27.86 Kg / Metre |
100 X 100 Size (mm) | 12 Thickness (mm) | 33.44 Kg / Metre |
120 X 120 Size (mm) | 4 Thickness (mm) | 14.50 Kg / Metre |
120 X 120 Size (mm) | 5 Thickness (mm) | 18.00 Kg / Metre |
120 X 120 Size (mm) | 6 Thickness (mm) | 21.30 Kg / Metre |
120 X 120 Size (mm) | 6.3 Thickness (mm) | 22.30 Kg / Metre |
120 X 120 Size (mm) | 8 Thickness (mm) | 27.90 Kg / Metre |
120 X 120 Size (mm) | 10 Thickness (mm) | 34.13 Kg / Metre |
120 X 120 Size (mm) | 12 Thickness (mm) | 39.94 Kg / Metre |
120 X 120 Size (mm) | 16 Thickness (mm) | 54.64 Kg / Metre |
140 X 140 Size (mm) | 6 Thickness (mm) | 25.97 Kg / Metre |
140 X 140 Size (mm) | 8 Thickness (mm) | 32.89 Kg / Metre |
140 X 140 Size (mm) | 10 Thickness (mm) | 41.15 Kg / Metre |
150 X 150 Size (mm) | 4 Thickness (mm) | 18.30 Kg / Metre |
150 X 150 Size (mm) | 5 Thickness (mm) | 22.70 Kg / Metre |
150 X 150 Size (mm) | 6 Thickness (mm) | 27.00 Kg / Metre |
150 X 150 Size (mm) | 6.3 Thickness (mm) | 28.30 Kg / Metre |
150 X 150 Size (mm) | 8 Thickness (mm) | 35.40 Kg / Metre |
150 X 150 Size (mm) | 10 Thickness (mm) | 43.47 Kg / Metre |
150 X 150 Size (mm) | 12 Thickness (mm) | 53.48 Kg / Metre |
150 X 150 Size (mm) | 16 Thickness (mm) | 65.05 Kg / Metre |
160 X 160 Size (mm) | 6 Thickness (mm) | 27.39 Kg / Metre |
160 X 160 Size (mm) | 8 Thickness (mm) | 36.90 Kg / Metre |
160 X 160 Size (mm) | 10 Thickness (mm) | 46.88 Kg / Metre |
180 X 180 Size (mm) | 5 Thickness (mm) | 27.97 Kg / Metre |
180 X 180 Size (mm) | 6 Thickness (mm) | 33.26 Kg / Metre |
180 X 180 Size (mm) | 8 Thickness (mm) | 43.00 Kg / Metre |
180 X 180 Size (mm) | 10 Thickness (mm) | 53.00 Kg / Metre |
180 X 180 Size (mm) | 12 Thickness (mm) | 61.01 Kg / Metre |
180 X 180 Size (mm) | 12.5 Thickness (mm) | 65.20 Kg / Metre |
180 X 180 Size (mm) | 16 Thickness (mm) | 81.30 Kg / Metre |
200 X 200 Size (mm) | 5 Thickness (mm) | 31.18 Kg / Metre |
200 X 200 Size (mm) | 6 Thickness (mm) | 37.09 Kg / Metre |
200 X 200 Size (mm) | 8 Thickness (mm) | 48.00 Kg / Metre |
200 X 200 Size (mm) | 10 Thickness (mm) | 59.30 Kg / Metre |
200 X 200 Size (mm) | 12 Thickness (mm) | 68.84 Kg / Metre |
200 X 200 Size (mm) | 12.5 Thickness (mm) | 73.00 Kg / Metre |
200 X 200 Size (mm) | 16 Thickness (mm) | 90.91 Kg / Metre |
250 X 250 Size (mm) | 6 Thickness (mm) | 46.83 Kg / Metre |
250 X 250 Size (mm) | 8 Thickness (mm) | 60.50 Kg / Metre |
250 X 250 Size (mm) | 10 Thickness (mm) | 75.00 Kg / Metre |
250 X 250 Size (mm) | 12 Thickness (mm) | 88.45 Kg / Metre |
250 X 250 Size (mm) | 12.5 Thickness (mm) | 92.70 Kg / Metre |
250 X 250 Size (mm) | 16 Thickness (mm) | 111.48 Kg / Metre |
300 X 300 Size (mm) | 6 Thickness (mm) | 55.30 Kg / Metre |
300 X 300 Size (mm) | 8 Thickness (mm) | 74.18 Kg / Metre |
300 X 300 Size (mm) | 10 Thickness (mm) | 90.70 Kg / Metre |
300 X 300 Size (mm) | 12 Thickness (mm) | 108.68 Kg / Metre |
300 X 300 Size (mm) | 12.5 Thickness (mm) | 112.00 Kg / Metre |
300 X 300 Size (mm) | 16 Thickness (mm) | 141.84 Kg / Metre |
350 X 350 Size (mm) | 10 Thickness (mm) | 105.93 Kg / Metre |
350 X 350 Size (mm) | 12 Thickness (mm) | 126.74 Kg / Metre |
350 X 350 Size (mm) | 16 Thickness (mm) | 166.94 Kg / Metre |
400 X 400 Size (mm) | 8 Thickness (mm) | 97.56 Kg / Metre |
400 X 400 Size (mm) | 10 Thickness (mm) | 121.95 Kg / Metre |
400 X 400 Size (mm) | 12 Thickness (mm) | 151.97 Kg / Metre |
400 X 400 Size (mm) | 16 Thickness (mm) | 191.94 Kg / Metr |
Size | kg / m |
12 x 12 x 1.5 mm | 0.59 |
15 x 15 x 1.2 mm | 0.54 |
15 x 15 x 1.5 mm | 0.66 |
20 x 20 x 1.2 mm | 0.73 |
20 x 20 x 1.5 mm | 0.90 |
20 x 20 x 2.0 mm | 0.18 |
25 x 25 x 1.2 mm | 0.93 |
25 x 25 x 1.5 mm | 1.15 |
25 x 25 x 2.0 mm | 1.50 |
25 x 25 x 3.0 mm | 2.22 |
30 x 30 x 1.2 mm | 1.11 |
30 x 30 x 1.5 mm | 1.37 |
30 x 30 x 2.0 mm | 1.84 |
30 x 30 x 3.0 mm | 2.72 |
40 x 40 x 1.2 mm | 1.50 |
40 x 40 x 1.5 mm | 1.86 |
40 x 40 x 2.0 mm | 2.45 |
40 x 40 x 3.0 mm | 3.76 |
316 Stainless Steel Pipe SCHEDULE CHART
NB SIZES | SCH 5 | SCH 10 | SCH 40 | SCH 80 | SCH 160 |
---|---|---|---|---|---|
1/8″ |
|||||
1/4″ |
|||||
3/8″ |
|||||
1/2″ |
|||||
3/4″ |
|||||
1″ |
|||||
1 1/4″ |
|||||
1 1/2″ |
|||||
2″ |
|||||
2 1/2″ |
|||||
3″ |
|||||
4″ |
|||||
5″ |
|||||
6″ |
SS SQUARE PIPE NOMINAL BORE SCHEDULE SIZES
Nominal | SS Schedule 5 | SS Schedule 10 | SS Schedule 40 | |||||||
Inch | MM | Wt./MM | Kg./M | Kg./Ft | Wt./MM | Kg./M | Kg./Ft | Wt./MM | Kg./M | Kg./Ft |
1 / 2 | 21 | 1.65 | 0.801 | 0.244 | 2.11 | 0.999 | 0.305 | 2.77 | 1.270 | 0.387 |
3 / 4 | 21.30 | 1.65 | 1.020 | 0.311 | 2.11 | 1.280 | 0.390 | 2.87 | 1.680 | 0.512 |
1 | 26.70 | 1.65 | 1.290 | 0.393 | 2.77 | 2.090 | 0.637 | 3.38 | 2.500 | 0.762 |
1 1 / 4 | 33.40 | 1.65 | 1.650 | 0.503 | 2.77 | 2.690 | 0.820 | 3.56 | 3.380 | 1.030 |
1 1 / 2 | 42.20 | 1.65 | 1.900 | 0.579 | 2.77 | 3.110 | 0.948 | 3.68 | 4.050 | 1.230 |
2 | 48.30 | 1.65 | 3.340 | 0.728 | 2.77 | 3.920 | 1.200 | |||
2 1 / 2 | 73.00 | 2.11 | 3.690 | 1.130 | 3.05 | 5.260 | 1.600 | |||
3 | 88.90 | 2.11 | 4.510 | 1.380 | 3.05 | 6.450 | 1.970 | |||
3 1 / 2 | 101.60 | 2.11 | 5.190 | 1.580 | 3.05 | 7.400 | 2.260 |
316 Stainless Steel Pipe PRESSURE RATING
Pressure Rating (psig) | ||||||||||
---|---|---|---|---|---|---|---|---|---|---|
Pipe Size (inches) |
Pipe Schedule | Temperature (oF) | ||||||||
100 | 200 | 300 | 400 | 500 | 600 | 650 | 700 | 750 | ||
1" | 40 | 3048 | 2629 | 2362 | 2171 | 2019 | 1924 | 1867 | 1824 | 1810 |
80 | 4213 | 3634 | 3265 | 3002 | 2791 | 2659 | 2580 | 2528 | 2501 | |
160 | 6140 | 5296 | 4759 | 4375 | 4068 | 3876 | 3761 | 3684 | 3646 | |
1 1/2" | 40 | 2257 | 1947 | 1750 | 1608 | 1496 | 1425 | 1383 | 1354 | 1340 |
80 | 3182 | 2744 | 2466 | 2267 | 2108 | 2009 | 1949 | 1909 | 1889 | |
160 | 4619 | 3984 | 3580 | 3291 | 3060 | 2916 | 2829 | 2772 | 2743 | |
2" | 40 | 1902 | 1640 | 1474 | 1355 | 1260 | 1201 | 1165 | 1141 | 1129 |
80 | 2747 | 2369 | 2129 | 1957 | 1820 | 1734 | 1682 | 1648 | 1631 | |
160 | 4499 | 3880 | 3486 | 3205 | 2980 | 2840 | 2755 | 2699 | 2671 | |
3" | 40 | 1806 | 1558 | 1400 | 1287 | 1196 | 1140 | 1106 | 1084 | 1072 |
80 | 2553 | 2202 | 1979 | 1819 | 1691 | 1612 | 1564 | 1532 | 1516 | |
160 | 3840 | 3312 | 2976 | 2736 | 2544 | 2424 | 2352 | 2304 | 2280 | |
4" | 40 | 1531 | 1321 | 1187 | 1091 | 1014 | 967 | 938 | 919 | 909 |
80 | 2213 | 1909 | 1715 | 1577 | 1466 | 1397 | 1355 | 1328 | 1314 | |
160 | 3601 | 3106 | 2791 | 2566 | 2386 | 2273 | 2206 | 2161 | 2138 | |
5" | 40 | 1342 | 1158 | 1040 | 956 | 889 | 847 | 822 | 805 | 797 |
80 | 1981 | 1709 | 1535 | 1411 | 1312 | 1250 | 1213 | 1189 | 1176 | |
160 | 3414 | 2945 | 2646 | 2433 | 2262 | 2155 | 2091 | 2049 | 2027 | |
6" | 40 | 1219 | 1052 | 945 | 869 | 808 | 770 | 747 | 732 | 724 |
80 | 1913 | 1650 | 1483 | 1363 | 1267 | 1208 | 1172 | 1148 | 1136 | |
160 | 3289 | 2836 | 2549 | 2343 | 2179 | 2076 | 2014 | 1973 | 1953 | |
8" | 40 | 1073 | 926 | 832 | 765 | 711 | 678 | 657 | 644 | 637 |
80 | 1692 | 1459 | 1311 | 1205 | 1121 | 1068 | 1036 | 1015 | 1005 | |
160 | 3175 | 2738 | 2460 | 2262 | 2103 | 2004 | 1944 | 1905 | 1885 | |
10" | 40 | 974 | 840 | 755 | 694 | 645 | 615 | 596 | 584 | 578 |
80 | 1609 | 1388 | 1247 | 1147 | 1066 | 1016 | 986 | 966 | 956 | |
160 | 3147 | 2714 | 2439 | 2242 | 2085 | 1986 | 1927 | 1880 | 1868 |
STAINLESS STEEL PIPE TOLERANCES
NPS Designator | Permissible Variations in Outside Diameter | |
---|---|---|
Over In. | Under In. | |
1/8 to 1-1/2, incl | 1/64 (0.015) | 1/32 (0.031) |
Over 1-1/2 to 4, incl | 1/32 (0.031) | 1/32 (0.031) |
Over 4 to 8, incl | 1/16 (0.062) | 1/32 (0.031) |
Over 8 to 18, incl | 3/23 (0.093) | 1/32 (0.031) |
Nominal Wall Thickness:
NPS Designator | Outside Diameter in. | Schedule 10S in. | Schedule 40S in. | Schedule 80S in. | Schedule 160 in. | Schedule XX in. |
---|---|---|---|---|---|---|
1/4 | 0.540 | 0.065 | 0.088 | 0.119 | ||
3/8 | 0.675 | 0.065 | 0.091 | 0.126 | ||
1/2 | 0.840 | 0.083 | 0.109 | 0.147 | .188 | .294 |
3/4 | 1.050 | 0.083 | 0.113 | 0.154 | .218 | .308 |
1.0 | 1.315 | 0.109 | 0.133 | 0.179 | .250 | .358 |
1 1/4 | 1.660 | 0.109 | 0.140 | 0.191 | .250 | .382 |
1 1/2 | 1.900 | 0.109 | 0.145 | 0.200 | .281 | .400 |
2 | 2.375 | 0.109 | 0.154 | 0.218 | .343 | .436 |
2 1/2 | 2.875 | 0.120 | 0.203 | 0.276 | .375 | .552 |
3 | 3.500 | 0.120 | 0.216 | 0.300 | .438 | .600 |
3 1/2 | 4.000 | 0.120 | 0.226 | 0.318 | .636 | |
4 | 4.500 | 0.120 | 0.237 | 0.337 | .534 | .674 |
5 | 5.563 | 0.134 | 0.258 | 0.375 | .625 | .750 |
6 | 6.625 | 0.134 | 0.280 | 0.432 | .719 | .864 |
8 | 8.625 | 0.148 | 0.322 | 0.500 | .906 | .875 |
10 | 10.750 | 0.165 | 0.365 | 0.500 | 1.125 | |
12 | 12.750 | 0.180 | 0.375 | 0.500 | 1.312 | |
14 | 14.000 | 0.188 | 0.375 | 0.500 | 1.406 | |
16 | 16.000 | 0.188 | 0.375 | 0.500 | 1.594 |
Minimum Wall Thickness on Inspection:
- tn * 0.875 = tm Where: tn = nominal wall thickness, in. [mm], and tm= minimum wall thicknesses, in. [mm]
- The wall thickness is inch-pound units is rounded to three decimal places in accordance with the rounding method of Practice E29. The wall thickness in SI units is rounded to one decimal place in accordance with the rounding method of Practice E29.
Nominal Thickness | Minimum Thickness on Inspection | Nominal Thickness | Minimum Thickness on Inspection | Nominal Thickness | Minimum Thickness on Inspection | ||||||
---|---|---|---|---|---|---|---|---|---|---|---|
in. | mm | in | mm | in | mm | in | mm | in | mm | in | mm |
0.068 | 1.7 | 0.060 | 1.5 | 0.294 | 7.5 | 0.257 | 6.5 | 0.750 | 19.0 | 0.658 | 16.6 |
0.068 | 2.2 | 0.077 | 2.0 | 0.300 | 7.6 | 0.262 | 6.7 | 0.812 | 20.6 | 0.710 | 18.0 |
0.091 | 2.3 | 0.080 | 2.0 | 0.307 | 7.8 | 0.269 | 6.8 | 0.843 | 21.4 | 0.736 | 18.7 |
0.095 | 2.4 | 0.083 | 2.1 | 0.308 | 7.8 | 0.270 | 6.9 | 0.854 | 21.7 | 0.756 | 19.2 |
0.113 | 2.9 | 0.099 | 2.5 | 0.312 | 7.9 | 0.273 | 6.9 | 0.875 | 22.2 | 0.766 | 19.5 |
0.119 | 3.0 | 0.104 | 2.6 | 0.318 | 8.1 | 0.278 | 7.1 | 0.906 | 23.0 | 0.783 | 20.1 |
0.125 | 3.2 | 0.109 | 2.8 | 0.322 | 8.2 | 0.282 | 7.2 | 0.937 | 23.8 | 0.820 | 20.8 |
0.126 | 3.2 | 0.110 | 2.8 | 0.330 | 8.4 | 0.289 | 7.3 | 0.968 | 24.6 | 0.847 | 21.5 |
0.133 | 3.4 | 0.116 | 2.9 | 0.337 | 8.6 | 0.295 | 7.5 | 1.000 | 25.4 | 0.875 | 22.2 |
0.140 | 3.6 | 0.122 | 3.1 | 0.343 | 8.7 | 0.300 | 7.6 | 1.031 | 26.2 | 0.902 | 22.9 |
0.145 | 3.7 | 0.127 | 3.2 | 0.344 | 8.7 | 0.301 | 7.6 | 1.062 | 27.0 | 0.929 | 23.6 |
0.147 | 3.7 | 0.129 | 3.3 | 0.358 | 9.1 | 0.313 | 8.0 | 1.083 | 27.8 | 0.956 | 24.3 |
0.154 | 3.9 | 0.135 | 3.4 | 0.365 | 9.3 | 0.319 | 8.1 | 1.125 | 28.6 | 0.984 | 25.0 |
0.156 | 4.0 | 0.136 | 3.5 | 0.375 | 9.5 | 0.328 | 8.3 | 1.156 | 29.4 | 1.012 | 25.7 |
0.179 | 4.5 | 0.157 | 4.0 | 0.382 | 9.7 | 0.334 | 8.5 | 1.218 | 30.9 | 1.066 | 27.1 |
0.187 | 43.7 | 0.164 | 4.2 | 0.400 | 10.2 | 0.350 | 8.9 | 1.250 | 31.8 | 1.094 | 27.8 |
0.188 | 4.8 | 0.164 | 4.2 | 0.406 | 10.3 | 0.355 | 9.0 | 1.281 | 32.5 | 1.121 | 28.5 |
0.191 | 4.9 | 0.167 | 4.2 | 0.432 | 10.4 | 0.378 | 9.6 | 1.312 | 33.3 | 1.148 | 29.2 |
0.200 | 5.1 | 0.175 | 4.4 | 0.436 | 11.1 | 0.382 | 9.7 | 1.343 | 34.1 | 1.175 | 29.8 |
0.203 | 5.2 | 0.178 | 4.5 | 0.437 | 11.1 | 0.382 | 9.7 | 1.375 | 34.9 | 1.203 | 30.6 |
0.216 | 5.5 | 0.189 | 4.8 | 0.438 | 11.1 | 0.383 | 9.7 | 1.406 | 35.7 | 1.230 | 31.2 |
0.218 | 5.5 | 0.191 | 4.9 | 0.500 | 12.7 | 0.438 | 11.1 | 1.436 | 36.5 | 1.258 | 32.0 |
0.219 | 5.6 | 0.192 | 4.9 | 0.531 | 13.5 | 0.465 | 11.8 | 1.500 | 36.1 | 1.312 | 33.3 |
0.226 | 5.7 | 0.196 | 5.0 | 0.552 | 14.0 | 0.483 | 12.3 | 1.531 | 38.9 | 1.340 | 34.0 |
0.237 | 6.0 | 0.207 | 5.2 | 0.562 | 14.3 | 0.492 | 12.5 | 1.562 | 39.7 | 1.367 | 34.7 |
0.250 | 6.4 | 0.219 | 5.6 | 0.593 | 15.1 | 0.519 | 13.2 | 1.593 | 40.5 | 1.394 | 35.4 |
0.258 | 6.6 | 0.226 | 5.7 | 0.600 | 15.2 | 0.525 | 13.3 | 1.750 | 44.5 | 1.531 | 38.9 |
0.276 | 7.0 | 0.242 | 6.1 | 0.625 | 15.9 | 0.547 | 13.9 | 1.781 | 45.2 | 1.558 | 39.6 |
0.277 | 7.0 | 0.242 | 6.1 | 0.656 | 16.6 | 0.573 | 14.6 | 1.812 | 46.0 | 1.586 | 49.3 |
0.279 | 7.1 | 0.244 | 6.2 | 0.674 | 17.1 | 0.590 | 15.0 | 1.968 | 50.0 | 1.772 | 43.7 |
0.280 | 7.1 | 0.245 | 6.2 | 0.687 | 17.4 | 0.601 | 15.3 | 2.062 | 52.4 | 1.804 | 45.8 |
0.281 | 7.1 | 0.246 | 6.2 | 0.719 | 18.3 | 0.629 | 16.0 | 2.343 | 59.5 | 2.050 | 52.1 |
316 Stainless Steel Pipe CHEMICAL COMPOSITION
The below table shows the chemical composition of the used for Stainless Steel Pipes:
GRADES | UNS | C | Mn | P | S | Si | Cr | Ni | Mo | Ti | Nb | N |
TP304 | S30400 | 0.08 | 2 | 0.045 | 0.03 | 1 | 18.0-20.0 | 8.0-11.0 | ||||
TP304L | S30403 | 0.035 | 2 | 0.045 | 0.03 | 1 | 18.0-20.0 | 8.0-13.0 | ||||
TP316 | S3160 | 0.08 | 2 | 0.045 | 0.03 | 1 | 16.0-18.0 | 11.0-14.0 | 2.0-3.0 | |||
TP316L | S31603 | 0.035 | 2 | 0.045 | 0.03 | 1 | 16.0-18.0 | 10.0-14.0 | 2.0-3.0 |
316 Stainless Steel Pipe MECHANICAL PROPERTIES
Material | Heat | Temperure | Tensile Strength | Yield Strength | Elongation %, Min |
Treatment | Min. | Ksi (MPa), Min. | Ksi (MPa), Min. | ||
º F(º C) | |||||
TP304 | Solution | 1900 (1040) | 75(515) | 30(205) | 35 |
TP304L | Solution | 1900 (1040) | 70(485) | 25(170) | 35 |
TP316 | Solution | 1900(1040) | 75(515) | 30(205) | 35 |
TP316L | Solution | 1900(1040) | 70(485) | 25(170) | 35 |
AVAILABLE STOCK OF SS SQUARE PIPE
Stainless Steel Seamless Square Pipe Supplier & Manufacturer in India | SS Seamless Square Pipe Supplier |
Seamless SS Square Pipe Supplier & Manufacturer in India | SS Oval Square Pipe Supplier & Manufacturer in India |
316 Stainless Steel Pipe Suppliers & Manufacturer in India | 316 Stainless Steel Pipe Exporter |
304 316 Stainless Steel Pipe Suppliers & Manufacturer in India | 316L 316 Stainless Steel Pipe |
SS Square Pipe Oval Sections Supplier & Manufacturer in India | ASTM A312 TP304 SS Square Pipe Supplier & Manufacturer in India |
SS Bright Annealed Square Pipe | ASTM A312 TP304LStainless Steel Supplier & Manufacturer in India |
Stainless Steel 201 Square Pipes Supplier & Manufacturer in India | Stainless Steel Square 316 Pipe Supplier |
Large Diameter 316 Stainless Steel Pipe | ASTM A312 TP304/304L SS Square Pipe Supplier & Manufacturer in India |
SS Square Pipe Supplier & Manufacturer in India | ASTM A312 TP316 Stainless Steel Supplier & Manufacturer in India |
Hot Rolled 316 Stainless Steel Pipe Suppliers & Manufacturer in India | ASTM A312 TP316L Stainless SS & Manufacturer in India |
1/2″ NB in Thickness Schedule 316 Stainless Steel Pipe | ASTM A312 TP201 316 Stainless Steel Pipe |
4″ NB in Thickness Schedule SS Square Pipe Supplier & Manufacturer in India | ASTM A312 TP316/316L 316 Stainless Steel Pipe Suppliers |
5″ NB in Thickness Schedule SS Square Pipe Supplier & Manufacturer in India | Schedule 40 SS Square Pipe Supplier & Manufacturer in India |
6″ NB in Thickness Schedule 316 Stainless Steel Pipe Suppliers & Manufacturer in India | Schedule 80 316 Stainless Steel Pipe Suppliers & Manufacturer in India |
7″ NB in Thickness Schedule SS Square Pipe Supplier & Manufacturer in India | Schedule 10 SS Square Pipe Supplier |
8″ NB in Thickness Schedule 316 Stainless Steel Pipe Suppliers & Manufacturer in India | Sch 5 316 Stainless Steel Pipe Suppliers |
14″ NB in Thickness Schedule SS Square Pipe Supplier | 316 Stainless Steel Pipe Weight per meter |
16″ NB in Thickness Schedule 316 Stainless Steel Pipe Supplier & Manufacturer in India | Weight of 316 Stainless Steel Pipe |
18″ NB in Thickness Schedule SS Square Pipe Supplier | 316 Stainless Steel Pipe Price in India |
PACKAGING AND LABELING
To ensure the safe transportation of our products, we take meticulous care in packaging them. In the case of exports, we employ standard wooden cases for packaging. Each pipe is marked with essential information, including Grade, Lot No, Size, Degree, and our trademark. Furthermore, we can provide custom markings on our products upon special requests.
QUALITY ASSURANCE
Our Products maintains stringent quality control measures for all fittings and bars throughout every production stage, from the procurement of raw materials to the dispatch of the final products. Visual inspections ensure compliance with industry-standard codes and regulations such as ASTM, ASME, MSS, DIN, EN, and JIS. Should the need arise, we can arrange for official certified Inspection Agencies to witness material reports, dimensions, and product quality conformity.
TEST CERTIFICATES
Our products come with a Manufacturer Test Certificate per EN 10204 / 3.1B and a Raw Materials Certificate. In addition, they undergo a 100% Radiography Test, and Third Party Inspection Reports can also be provided.
SHIPPING POLICY
The delivery time and dates are determined based on the type and quantity of steel ordered. Our sales team will provide a delivery schedule when you request a quotation. Please note that the delivery schedule may occasionally be subject to change, so we recommend checking with our sales department when placing your orders. Orders are typically dispatched within 2-3 business days and may take 5-10 business days to reach their destination. If Forgings are out of stock, orders may require 2-4 weeks for shipping. Our Products will promptly notify the buyer if such a situation occurs.
Stainless Steel Square Rod
Stainless Steel Rods
Stainless Steel Rods
316 Stainless Steel Pipes
Industry We Serve
Cities We Deliver To
Istanbul, Coimbatore, Jamshedpur, Haryana, Dammam, Ankara, Hyderabad, Sharjah, Kuala Lumpur, Mumbai, Surat, Ranchi, Pune, Bangkok, Busan, Kuwait City, Singapore, Indore, Vadodara, Madrid, Al Jubail, Dallas, Faridabad, Secunderabad, Toronto, Petaling Jaya, Brisbane, Jaipur, Thiruvananthapuram, Colombo, Atyrau, Algiers, Los Angeles, Houston, Visakhapatnam, Tehran, Thane, Doha, Hanoi, Edmonton, Karachi, Cairo, Gurgaon, Jakarta, Ahmedabad, Geoje-si, Ho Chi Minh City, Chiyoda, Kanpur, Riyadh, Rajkot, Bhopal, La Victoria, Milan, Muscat, Chennai, Bogota, Gimhae-si, New York, Ernakulam, Granada, Santiago, Ludhiana, Dubai, Kolkata, Caracas, Howrah, Jeddah, Lahore, Courbevoie, Perth, Pimpri-Chinchwad, Aberdeen, Manama, Nagpur, Ahvaz, Montreal, Seoul, Bengaluru, Sydney, Al Khobar, Lagos, Calgary, Vung Tau, New Delhi, Nashik, Ulsan, Noida, Mexico City, Hong Kong, Rio de Janeiro, Abu Dhabi, Melbourne, Chandigarh, Baroda, Port-of-Spain, London, Navi Mumbai, Moscow.
Countries We Deliver To
Peru, Kazakhstan, Bolivia, Bhutan, Poland, Nigeria, China, Bangladesh, Norway, Estonia, Costa Rica, Taiwan, Sri Lanka, Qatar, Iran, Canada, Zimbabwe, Malaysia, Morocco, Denmark, Poland, Thailand, Egypt, Iran, Gabon, Lithuania, Netherlands, Belgium, Bulgaria, Bahrain, Mexico, Japan, Turkey, Portugal, Venezuela, South Korea, Ecuador, United Arab Emirates, Namibia, Hong Kong, Ghana, Slovakia, Germany, Austria, Vietnam, Gambia, Mongolia, Ireland, Italy, Romania, United States, Kuwait, Spain, Indonesia, Greece, France, Chile, Czech Republic, Nigeria, Israel, Tunisia, Libya, Ukraine, Nepal, Jordan, Brazil, Serbia, Afghanistan, South Africa, Lebanon, Chile, Angola, Philippines, Hungary, Mexico, Yemen, United Kingdom, Sweden, Tibet, Macau, Kenya, Puerto Rico, New Zealand, Singapore, Algeria, Azerbaijan, Oman, Pakistan, India, Saudi Arabia, Russia, Iraq, Australia, Finland, Colombia, Argentina, Croatia, Belarus, Switzerland, Trinidad & Tobago.
Other Available Products of Aluminium Rods
» Stainless Steel Round Pipe
» Stainless Steel Rectangular Pipe
» Stainless Steel Hydraulic Pipe
» 316 Stainless Steel Pipe
» Stainless Steel 304 Pipe
» Stainless Steel 304L Pipe
» Stainless Steel ERW Pipe
» Stainless Steel 316 Pipe
» Stainless Steel 316L Pipe
» Stainless Steel Oval Pipe
» Stainless Steel Perforated Pipe
People also search for Stainless Steel Products
Stainless Steel Tube price per kg, 316 Stainless Steel Pipe manufacturers in india, 316 Stainless Steel Pipe, Stainless Steel Perforated Pipe.
