430 Stainless Steel Tube Steel Tube

430 STAINLESS STEEL TUBE, STAINLESS STEEL 430 HEAT EXCHANGER TUBES, WERKSTOFF NR. 1.4016 TUBING, SS UNS S43000 WELDED PIPES, ASTM A731 STAINLESS STEEL 430 PIPES

ASTM A268 SS 430 TUBING, SS DIN 1.4016 PIPES, STAINLESS STEEL UNS S43000 PIPE, ASME SA731 SS TP430 SEAMLESS PIPES, 430 STAINLESS STEEL PIPE, SS TP430 EFW PIPES, SS TP430 RECTANGULAR PIPES, SS 430 CAPILLARY TUBES, SS 430 TUBING EXPORTER, SS 430 ELECTRIC FUSION WELDING PIPE

Siddhgiri Exports is one of The Largest Manufacturers & Suppliers of 430 Stainless Steel Pipe, 430 Stainless Steel Tube. We are one of the leading industries offer our customers & clients the best quality of pipes. These pipes are used extensively in various applications and industries like petrochemical industry, food processing industry, marine industry, chemical industry, and oil & gas industry. These are SS 430 Pipes, therefore, they are known best for their high tensile strength, resistance to oxidation and corrosion, ductility, good workability, and long functional life. These pipes are made using top-notch quality of raw material and used in accordance with the international quality standards. These UNS S43000 Seamless Pipes include ASTM A/ ASME SA268/ A731 CL specifications and standards like API, ASTM, and ASME.

430 Stainless Steel Tube Steel Tube SPECIFICATION

Siddhgiri Exports offering 430 Stainless Steel Tube Steel Tube in customized designs. SS 304 Square Pipes are used for pressure operations such as moving liquids and gases in processing operations in the water treatment, chemical, petrochemical, food processing, dairy and marine industries. Welded tube is used as handrails, legs for office, kitchen, and hospital equipment and as architectural supports. Siddhgiri Exports is specialized as providing 430 Stainless Steel Tube Steel Tube in Hollow Grit 120 - 600 finish. SS Square pipe dimensions are nominated by outside diameter indicated by the NPS (imperial) or DN (metric) designator and sometimes referred to as the 'nominal bore' - and wall thickness is determined by the schedule number.

Specification

Form	Round Pipes, Square Pipes, Rectangular Pipe, “U” Shape Pipes, Hydraulic Pipes
Item	Stainless Steel 430 Pipe
Standard	GB, AISI, ASTM, ASME, EN, BS, DIN, JIS
Wall Thickness	Schedule 10 To Schedule 160 (3 mm to 100 mm Thickness)
Length	01 Meter to 12.5 Meters, Single Random Length, Double Random Length And Customize Size End: Plain End, Beveled End, Treaded
Type	Seamless / ERW / Welded / Fabricated / CDW
Outer Diameter Size	SEAMLESS - 1/2" NB TO 18" NB WELDED / ERW- 1" NB TO 16" NB EFW - 8" NB TO 110" NB
Delivery Conditions	As Rolled, Formed, Stress Relieved, Annealed, Hardened, Tempered, Cold Draw
Coating	Electropolish, Mechanical Polish, Satin Finish, Passivated
Testing	Product Analysis, Transverse Tension Test, Flattening Test, Etching Test, Radiographic Examination, Stabilizing Heat Treatment, Intergranular Corrosion Test, Weld Decay Test, Magnetic Particle Detection, Grain Size Test, NACE 0175, Dual Grade, PWHT (POST WELD HEAT TREATMENT), Flare Test, Bend Test, Hardness Test, Tensile Test etc
Dimension	All Pipes Is Manufactured and Inspected / Tested to the Relevant standards including ASTM and ASME
Value Added Services	Draw / Expansion / Machining / Sand Blasting / Shot Blasting / Heat Treatment
Packaging	Loose / Bundle / Wooden Pallet / Wooden Box / Plastic Cloth Wraps / Plastic End Caps / Beveled Protector
Material Test Certificate	Manufacturer Test Certificate As Per EN10204 3.1, 3.2 / Laboratory Test Certificate From NABL Approved Lab. / Under Third Party Inspection Agency Like SGS, TUV, DNV, LLOYDS, ABS ETC

430 Stainless Steel Tube Steel Tube Ploishing Machine, SS Square Pipes, SS Square Pipe Dealer in India, High Quality 430 Stainless Steel Tube Steel Tube, 430 Stainless Steel Tube Steel Tubes Exporter in India, 430 Stainless Steel Tube Steel Tubes for Architectural Applications, SS Square Pipe for Petrochemical Plants, Stainless Steel Square Hollow Sections, Seamless 430 Stainless Steel Tube Steel Tubes. SUPPLIERS OF 430 Stainless Steel Tube Steel TubeS, 430 Stainless Steel Tube Steel Tube EXPORTER, SS 304 SQUARE PIPE WEIGHT CHART, 304 SQUARE STEEL PIPES, SS 316 SQUARE PIPE SUPPLIER IN MUMBAI, INDIA.

430 Stainless Steel Tube Steel Tube SIZES

SS Square pipes are finished in accordance with customer needs regarding dimensional and wall thickness specifications as well as heat treatment for more demanding applications. In general a 430 Stainless Steel Tube Steel Tube is manufactured in sizes from 1/8” to 24” according to current standards ASTM, API and ASME. If required for special projects we can also supply SS Square seamless pipes & SS Square welded pipes for bigger sizes starting from outside diameter 26” up to 48”. More Information of Stainless Steel Pipe Sizes and 430 Stainless Steel Tube Steel Tube weight chart

• Machinery
• Automative
• Transport
• construction
• Home and commercial fixtures

430 Stainless Steel Tube Steel Tube DIMENSIONS AND WEIGHTS

MM	0.65	0.80	0.90	0.95	1.00	1.20	1.50	2.00	2.50
12.5 x 12.5	0.075	0.091	0.102	0.107	0.112	0.133	0.163
20 x 20				0.176	0.184	0.220	0.271	0.354	0.433	0.508
25 x 25				0.221	0.232	0.277	0.343	0.450	0.553	0.652
30 x 30				0.267	0.280	0.335	0.415	0.516	0.673	0.796
38 x 38				0.340	0.358	0.427	0.531	0.700	0.866	1.027
40 x 40				0.358	0.376	0.450	0.559	0.738	0.898	1.084
50 x 50					0.473	0.565	0.703	0.930	1.153	1.372

Stainless Steel Square Hollow Section / Size / Dimensions / Weight Chart

Size (mm)	Thickness (mm)	Kg / Metre
20 X 20 Size (mm)	2 Thickness (mm)	1.11 Kg / Metre
25 X 25 Size (mm)	2 Thickness (mm)	1.43 Kg / Metre
25 X 25 Size (mm)	2.5 Thickness (mm)	1.74 Kg / Metre
25 X 25 Size (mm)	3 Thickness (mm)	2.04 Kg / Metre
30 X 30 Size (mm)	2 Thickness (mm)	1.74 Kg / Metre
30 X 30 Size (mm)	2.5 Thickness (mm)	2.14 Kg / Metre
30 X 30 Size (mm)	3 Thickness (mm)	2.51 Kg / Metre
30 X 30 Size (mm)	3.2 Thickness (mm)	2.65 Kg / Metre
40 X 40 Size (mm)	2 Thickness (mm)	2.37 Kg / Metre
40 X 40 Size (mm)	2.5 Thickness (mm)	2.92 Kg / Metre
40 X 40 Size (mm)	3 Thickness (mm)	3.45 Kg / Metre
40 X 40 Size (mm)	4 Thickness (mm)	4.46 Kg / Metre
40 X 40 Size (mm)	5 Thickness (mm)	5.40 Kg / Metre
50 X 50 Size (mm)	2 Thickness (mm)	3.00 Kg / Metre
50 X 50 Size (mm)	2.5 Thickness (mm)	3.71 Kg / Metre
50 X 50 Size (mm)	3 Thickness (mm)	4.39 Kg / Metre
50 X 50 Size (mm)	4 Thickness (mm)	5.72 Kg / Metre
50 X 50 Size (mm)	5 Thickness (mm)	6.97 Kg / Metre
50 X 50 Size (mm)	6 Thickness (mm)	8.20 Kg / Metre
50 X 50 Size (mm)	8 Thickness (mm)	10.50 Kg / Metre
60 X 60 Size (mm)	3 Thickness (mm)	5.34 Kg / Metre
60 X 60 Size (mm)	3.2 Thickness (mm)	5.67 Kg / Metre
60 X 60 Size (mm)	3.6 Thickness (mm)	6.34 Kg / Metre
60 X 60 Size (mm)	4 Thickness (mm)	6.97 Kg / Metre
60 X 60 Size (mm)	5 Thickness (mm)	8.54 Kg / Metre
70 X 70 Size (mm)	2.5 Thickness (mm)	5.28 Kg / Metre
70 X 70 Size (mm)	3 Thickness (mm)	6.28 Kg / Metre
70 X 70 Size (mm)	3.5 Thickness (mm)	7.25 Kg / Metre
70 X 70 Size (mm)	3.6 Thickness (mm)	7.46 Kg / Metre
70 X 70 Size (mm)	4 Thickness (mm)	8.23 Kg / Metre
70 X 70 Size (mm)	5 Thickness (mm)	10.10 Kg / Metre
70 X 70 Size (mm)	8 Thickness (mm)	15.29 Kg / Metre
70 X 70 Size (mm)	10 Thickness (mm)	19.13 Kg / Metre
80 X 80 Size (mm)	3 Thickness (mm)	7.22 Kg / Metre
80 X 80 Size (mm)	3.5 Thickness (mm)	8.35 Kg / Metre
80 X 80 Size (mm)	3.6 Thickness (mm)	8.59 Kg / Metre
80 X 80 Size (mm)	4 Thickness (mm)	9.48 Kg / Metre
80 X 80 Size (mm)	5 Thickness (mm)	11.70 Kg / Metre
80 X 80 Size (mm)	6 Thickness (mm)	13.80 Kg / Metre
80 X 80 Size (mm)	6.3 Thickness (mm)	14.40 Kg / Metre
80 X 80 Size (mm)	8 Thickness (mm)	17.83 Kg / Metre
80 X 80 Size (mm)	10 Thickness (mm)	21.88 Kg / Metre
90 X 90 Size (mm)	3 Thickness (mm)	8.16 Kg / Metre
90 X 90 Size (mm)	3.5 Thickness (mm)	9.45 Kg / Metre
90 X 90 Size (mm)	3.6 Thickness (mm)	9.72 Kg / Metre
90 X 90 Size (mm)	4 Thickness (mm)	10.70 Kg / Metre
90 X 90 Size (mm)	5 Thickness (mm)	13.30 Kg / Metre
90 X 90 Size (mm)	6 Thickness (mm)	15.70 Kg / Metre
90 X 90 Size (mm)	6.3 Thickness (mm)	16.40 Kg / Metre
90 X 90 Size (mm)	8 Thickness (mm)	20.32 Kg / Metre
90 X 90 Size (mm)	10 Thickness (mm)	25.53 Kg / Metre
100 X 100 Size (mm)	3 Thickness (mm)	9.10 Kg / Metre
100 X 100 Size (mm)	4 Thickness (mm)	12.00 Kg / Metre
100 X 100 Size (mm)	5 Thickness (mm)	14.80 Kg / Metre
100 X 100 Size (mm)	6 Thickness (mm)	17.60 Kg / Metre
100 X 100 Size (mm)	6.3 Thickness (mm)	18.40 Kg / Metre
100 X 100 Size (mm)	8 Thickness (mm)	22.90 Kg / Metre
100 X 100 Size (mm)	10 Thickness (mm)	27.86 Kg / Metre
100 X 100 Size (mm)	12 Thickness (mm)	33.44 Kg / Metre
120 X 120 Size (mm)	4 Thickness (mm)	14.50 Kg / Metre
120 X 120 Size (mm)	5 Thickness (mm)	18.00 Kg / Metre
120 X 120 Size (mm)	6 Thickness (mm)	21.30 Kg / Metre
120 X 120 Size (mm)	6.3 Thickness (mm)	22.30 Kg / Metre
120 X 120 Size (mm)	8 Thickness (mm)	27.90 Kg / Metre
120 X 120 Size (mm)	10 Thickness (mm)	34.13 Kg / Metre
120 X 120 Size (mm)	12 Thickness (mm)	39.94 Kg / Metre
120 X 120 Size (mm)	16 Thickness (mm)	54.64 Kg / Metre
140 X 140 Size (mm)	6 Thickness (mm)	25.97 Kg / Metre
140 X 140 Size (mm)	8 Thickness (mm)	32.89 Kg / Metre
140 X 140 Size (mm)	10 Thickness (mm)	41.15 Kg / Metre
150 X 150 Size (mm)	4 Thickness (mm)	18.30 Kg / Metre
150 X 150 Size (mm)	5 Thickness (mm)	22.70 Kg / Metre
150 X 150 Size (mm)	6 Thickness (mm)	27.00 Kg / Metre
150 X 150 Size (mm)	6.3 Thickness (mm)	28.30 Kg / Metre
150 X 150 Size (mm)	8 Thickness (mm)	35.40 Kg / Metre
150 X 150 Size (mm)	10 Thickness (mm)	43.47 Kg / Metre
150 X 150 Size (mm)	12 Thickness (mm)	53.48 Kg / Metre
150 X 150 Size (mm)	16 Thickness (mm)	65.05 Kg / Metre
160 X 160 Size (mm)	6 Thickness (mm)	27.39 Kg / Metre
160 X 160 Size (mm)	8 Thickness (mm)	36.90 Kg / Metre
160 X 160 Size (mm)	10 Thickness (mm)	46.88 Kg / Metre
180 X 180 Size (mm)	5 Thickness (mm)	27.97 Kg / Metre
180 X 180 Size (mm)	6 Thickness (mm)	33.26 Kg / Metre
180 X 180 Size (mm)	8 Thickness (mm)	43.00 Kg / Metre
180 X 180 Size (mm)	10 Thickness (mm)	53.00 Kg / Metre
180 X 180 Size (mm)	12 Thickness (mm)	61.01 Kg / Metre
180 X 180 Size (mm)	12.5 Thickness (mm)	65.20 Kg / Metre
180 X 180 Size (mm)	16 Thickness (mm)	81.30 Kg / Metre
200 X 200 Size (mm)	5 Thickness (mm)	31.18 Kg / Metre
200 X 200 Size (mm)	6 Thickness (mm)	37.09 Kg / Metre
200 X 200 Size (mm)	8 Thickness (mm)	48.00 Kg / Metre
200 X 200 Size (mm)	10 Thickness (mm)	59.30 Kg / Metre
200 X 200 Size (mm)	12 Thickness (mm)	68.84 Kg / Metre
200 X 200 Size (mm)	12.5 Thickness (mm)	73.00 Kg / Metre
200 X 200 Size (mm)	16 Thickness (mm)	90.91 Kg / Metre
250 X 250 Size (mm)	6 Thickness (mm)	46.83 Kg / Metre
250 X 250 Size (mm)	8 Thickness (mm)	60.50 Kg / Metre
250 X 250 Size (mm)	10 Thickness (mm)	75.00 Kg / Metre
250 X 250 Size (mm)	12 Thickness (mm)	88.45 Kg / Metre
250 X 250 Size (mm)	12.5 Thickness (mm)	92.70 Kg / Metre
250 X 250 Size (mm)	16 Thickness (mm)	111.48 Kg / Metre
300 X 300 Size (mm)	6 Thickness (mm)	55.30 Kg / Metre
300 X 300 Size (mm)	8 Thickness (mm)	74.18 Kg / Metre
300 X 300 Size (mm)	10 Thickness (mm)	90.70 Kg / Metre
300 X 300 Size (mm)	12 Thickness (mm)	108.68 Kg / Metre
300 X 300 Size (mm)	12.5 Thickness (mm)	112.00 Kg / Metre
300 X 300 Size (mm)	16 Thickness (mm)	141.84 Kg / Metre
350 X 350 Size (mm)	10 Thickness (mm)	105.93 Kg / Metre
350 X 350 Size (mm)	12 Thickness (mm)	126.74 Kg / Metre
350 X 350 Size (mm)	16 Thickness (mm)	166.94 Kg / Metre
400 X 400 Size (mm)	8 Thickness (mm)	97.56 Kg / Metre
400 X 400 Size (mm)	10 Thickness (mm)	121.95 Kg / Metre
400 X 400 Size (mm)	12 Thickness (mm)	151.97 Kg / Metre
400 X 400 Size (mm)	16 Thickness (mm)	191.94 Kg / Metr

Size	kg / m
12 x 12 x 1.5 mm	0.59
15 x 15 x 1.2 mm	0.54
15 x 15 x 1.5 mm	0.66
20 x 20 x 1.2 mm	0.73
20 x 20 x 1.5 mm	0.90
20 x 20 x 2.0 mm	0.18
25 x 25 x 1.2 mm	0.93
25 x 25 x 1.5 mm	1.15
25 x 25 x 2.0 mm	1.50
25 x 25 x 3.0 mm	2.22
30 x 30 x 1.2 mm	1.11
30 x 30 x 1.5 mm	1.37
30 x 30 x 2.0 mm	1.84
30 x 30 x 3.0 mm	2.72
40 x 40 x 1.2 mm	1.50
40 x 40 x 1.5 mm	1.86
40 x 40 x 2.0 mm	2.45
40 x 40 x 3.0 mm	3.76

430 Stainless Steel Tube Steel Tube SCHEDULE CHART

NB SIZES	SCH 5	SCH 10	SCH 40	SCH 80	SCH 160
1/8″
1/4″
3/8″
1/2″
3/4″
1″
1 1/4″
1 1/2″
2″
2 1/2″
3″
4″
5″
6″

SS SQUARE PIPE NOMINAL BORE SCHEDULE SIZES

Nominal		SS Schedule 5			SS Schedule 10			SS Schedule 40
Inch	MM	Wt./MM	Kg./M	Kg./Ft	Wt./MM	Kg./M	Kg./Ft	Wt./MM	Kg./M	Kg./Ft
1 / 2	21	1.65	0.801	0.244	2.11	0.999	0.305	2.77	1.270	0.387
3 / 4	21.30	1.65	1.020	0.311	2.11	1.280	0.390	2.87	1.680	0.512
1	26.70	1.65	1.290	0.393	2.77	2.090	0.637	3.38	2.500	0.762
1 1 / 4	33.40	1.65	1.650	0.503	2.77	2.690	0.820	3.56	3.380	1.030
1 1 / 2	42.20	1.65	1.900	0.579	2.77	3.110	0.948	3.68	4.050	1.230
2	48.30	1.65	3.340	0.728	2.77	3.920	1.200
2 1 / 2	73.00	2.11	3.690	1.130	3.05	5.260	1.600
3	88.90	2.11	4.510	1.380	3.05	6.450	1.970
3 1 / 2	101.60	2.11	5.190	1.580	3.05	7.400	2.260

430 Stainless Steel Tube Steel Tube PRESSURE RATING

Pressure Rating (psig)
Pipe Size (inches)	Pipe Schedule	Temperature (oF)
Pipe Size (inches)	Pipe Schedule	100	200	300	400	500	600	650	700	750
1"	40	3048	2629	2362	2171	2019	1924	1867	1824	1810
	80	4213	3634	3265	3002	2791	2659	2580	2528	2501
	160	6140	5296	4759	4375	4068	3876	3761	3684	3646
1 1/2"	40	2257	1947	1750	1608	1496	1425	1383	1354	1340
	80	3182	2744	2466	2267	2108	2009	1949	1909	1889
	160	4619	3984	3580	3291	3060	2916	2829	2772	2743
2"	40	1902	1640	1474	1355	1260	1201	1165	1141	1129
	80	2747	2369	2129	1957	1820	1734	1682	1648	1631
	160	4499	3880	3486	3205	2980	2840	2755	2699	2671
3"	40	1806	1558	1400	1287	1196	1140	1106	1084	1072
	80	2553	2202	1979	1819	1691	1612	1564	1532	1516
	160	3840	3312	2976	2736	2544	2424	2352	2304	2280
4"	40	1531	1321	1187	1091	1014	967	938	919	909
	80	2213	1909	1715	1577	1466	1397	1355	1328	1314
	160	3601	3106	2791	2566	2386	2273	2206	2161	2138
5"	40	1342	1158	1040	956	889	847	822	805	797
	80	1981	1709	1535	1411	1312	1250	1213	1189	1176
	160	3414	2945	2646	2433	2262	2155	2091	2049	2027
6"	40	1219	1052	945	869	808	770	747	732	724
	80	1913	1650	1483	1363	1267	1208	1172	1148	1136
	160	3289	2836	2549	2343	2179	2076	2014	1973	1953
8"	40	1073	926	832	765	711	678	657	644	637
	80	1692	1459	1311	1205	1121	1068	1036	1015	1005
	160	3175	2738	2460	2262	2103	2004	1944	1905	1885
10"	40	974	840	755	694	645	615	596	584	578
	80	1609	1388	1247	1147	1066	1016	986	966	956
	160	3147	2714	2439	2242	2085	1986	1927	1880	1868

STAINLESS STEEL PIPE TOLERANCES

NPS Designator	Permissible Variations in Outside Diameter
NPS Designator	Over In.	Under In.
1/8 to 1-1/2, incl	1/64 (0.015)	1/32 (0.031)
Over 1-1/2 to 4, incl	1/32 (0.031)	1/32 (0.031)
Over 4 to 8, incl	1/16 (0.062)	1/32 (0.031)
Over 8 to 18, incl	3/23 (0.093)	1/32 (0.031)

Nominal Wall Thickness:

Nominal Wall Tolerance Plus 12.5%, Minus 12.5%

These do not conform to the American National Standard for Welded and Seamless Wrought Steel Pipe (ANSI B 36.10 – 1979)

NPS Designator	Outside Diameter in.	Schedule 10S in.	Schedule 40S in.	Schedule 80S in.	Schedule 160 in.	Schedule XX in.
1/4	0.540	0.065	0.088	0.119
3/8	0.675	0.065	0.091	0.126
1/2	0.840	0.083	0.109	0.147	.188	.294
3/4	1.050	0.083	0.113	0.154	.218	.308
1.0	1.315	0.109	0.133	0.179	.250	.358
1 1/4	1.660	0.109	0.140	0.191	.250	.382
1 1/2	1.900	0.109	0.145	0.200	.281	.400
2	2.375	0.109	0.154	0.218	.343	.436
2 1/2	2.875	0.120	0.203	0.276	.375	.552
3	3.500	0.120	0.216	0.300	.438	.600
3 1/2	4.000	0.120	0.226	0.318		.636
4	4.500	0.120	0.237	0.337	.534	.674
5	5.563	0.134	0.258	0.375	.625	.750
6	6.625	0.134	0.280	0.432	.719	.864
8	8.625	0.148	0.322	0.500	.906	.875
10	10.750	0.165	0.365	0.500	1.125
12	12.750	0.180	0.375	0.500	1.312
14	14.000	0.188	0.375	0.500	1.406
16	16.000	0.188	0.375	0.500	1.594

Minimum Wall Thickness on Inspection:

The following equation, upon which this table is based, may be applied to calculate minimum wall thicknesses from nominal wall thickness:

tn * 0.875 = tm Where: tn = nominal wall thickness, in. [mm], and tm= minimum wall thicknesses, in. [mm]
The wall thickness is inch-pound units is rounded to three decimal places in accordance with the rounding method of Practice E29. The wall thickness in SI units is rounded to one decimal place in accordance with the rounding method of Practice E29.

This table is a master table covering wall thicknesses available in the purchase of different classifications of pipe, but it is not meant to imply that all the walls listed herein are necessarily obtainable for the applicable product specification.

Nominal Thickness		Minimum Thickness on Inspection		Nominal Thickness		Minimum Thickness on Inspection		Nominal Thickness		Minimum Thickness on Inspection
in.	mm	in	mm	in	mm	in	mm	in	mm	in	mm
0.068	1.7	0.060	1.5	0.294	7.5	0.257	6.5	0.750	19.0	0.658	16.6
0.068	2.2	0.077	2.0	0.300	7.6	0.262	6.7	0.812	20.6	0.710	18.0
0.091	2.3	0.080	2.0	0.307	7.8	0.269	6.8	0.843	21.4	0.736	18.7
0.095	2.4	0.083	2.1	0.308	7.8	0.270	6.9	0.854	21.7	0.756	19.2
0.113	2.9	0.099	2.5	0.312	7.9	0.273	6.9	0.875	22.2	0.766	19.5
0.119	3.0	0.104	2.6	0.318	8.1	0.278	7.1	0.906	23.0	0.783	20.1
0.125	3.2	0.109	2.8	0.322	8.2	0.282	7.2	0.937	23.8	0.820	20.8
0.126	3.2	0.110	2.8	0.330	8.4	0.289	7.3	0.968	24.6	0.847	21.5
0.133	3.4	0.116	2.9	0.337	8.6	0.295	7.5	1.000	25.4	0.875	22.2
0.140	3.6	0.122	3.1	0.343	8.7	0.300	7.6	1.031	26.2	0.902	22.9
0.145	3.7	0.127	3.2	0.344	8.7	0.301	7.6	1.062	27.0	0.929	23.6
0.147	3.7	0.129	3.3	0.358	9.1	0.313	8.0	1.083	27.8	0.956	24.3
0.154	3.9	0.135	3.4	0.365	9.3	0.319	8.1	1.125	28.6	0.984	25.0
0.156	4.0	0.136	3.5	0.375	9.5	0.328	8.3	1.156	29.4	1.012	25.7
0.179	4.5	0.157	4.0	0.382	9.7	0.334	8.5	1.218	30.9	1.066	27.1
0.187	43.7	0.164	4.2	0.400	10.2	0.350	8.9	1.250	31.8	1.094	27.8
0.188	4.8	0.164	4.2	0.406	10.3	0.355	9.0	1.281	32.5	1.121	28.5
0.191	4.9	0.167	4.2	0.432	10.4	0.378	9.6	1.312	33.3	1.148	29.2
0.200	5.1	0.175	4.4	0.436	11.1	0.382	9.7	1.343	34.1	1.175	29.8
0.203	5.2	0.178	4.5	0.437	11.1	0.382	9.7	1.375	34.9	1.203	30.6
0.216	5.5	0.189	4.8	0.438	11.1	0.383	9.7	1.406	35.7	1.230	31.2
0.218	5.5	0.191	4.9	0.500	12.7	0.438	11.1	1.436	36.5	1.258	32.0
0.219	5.6	0.192	4.9	0.531	13.5	0.465	11.8	1.500	36.1	1.312	33.3
0.226	5.7	0.196	5.0	0.552	14.0	0.483	12.3	1.531	38.9	1.340	34.0
0.237	6.0	0.207	5.2	0.562	14.3	0.492	12.5	1.562	39.7	1.367	34.7
0.250	6.4	0.219	5.6	0.593	15.1	0.519	13.2	1.593	40.5	1.394	35.4
0.258	6.6	0.226	5.7	0.600	15.2	0.525	13.3	1.750	44.5	1.531	38.9
0.276	7.0	0.242	6.1	0.625	15.9	0.547	13.9	1.781	45.2	1.558	39.6
0.277	7.0	0.242	6.1	0.656	16.6	0.573	14.6	1.812	46.0	1.586	49.3
0.279	7.1	0.244	6.2	0.674	17.1	0.590	15.0	1.968	50.0	1.772	43.7
0.280	7.1	0.245	6.2	0.687	17.4	0.601	15.3	2.062	52.4	1.804	45.8
0.281	7.1	0.246	6.2	0.719	18.3	0.629	16.0	2.343	59.5	2.050	52.1

430 Stainless Steel Tube Steel Tube CHEMICAL COMPOSITION

The below table shows the chemical composition of the used for Stainless Steel Pipes:

GRADES	UNS	C	Mn	P	S	Si	Cr	Ni	Mo	Ti	Nb	N
TP304	S30400	0.08	2	0.045	0.03	1	18.0-20.0	8.0-11.0
TP304L	S30403	0.035	2	0.045	0.03	1	18.0-20.0	8.0-13.0
TP316	S3160	0.08	2	0.045	0.03	1	16.0-18.0	11.0-14.0	2.0-3.0
TP316L	S31603	0.035	2	0.045	0.03	1	16.0-18.0	10.0-14.0	2.0-3.0

430 Stainless Steel Tube Steel Tube MECHANICAL PROPERTIES

Material	Heat	Temperure	Tensile Strength	Yield Strength	Elongation %, Min
	Treatment	Min.	Ksi (MPa), Min.	Ksi (MPa), Min.
		º F(º C)
TP304	Solution	1900 (1040)	75(515)	30(205)	35
TP304L	Solution	1900 (1040)	70(485)	25(170)	35
TP316	Solution	1900(1040)	75(515)	30(205)	35
TP316L	Solution	1900(1040)	70(485)	25(170)	35

AVAILABLE STOCK OF SS SQUARE PIPE

Stainless Steel Seamless Square Pipe Supplier & Manufacturer in India	SS Seamless Square Pipe Supplier
Seamless SS Square Pipe Supplier & Manufacturer in India	SS Hollow Square Pipe Supplier & Manufacturer in India
430 Stainless Steel Tube Steel Tube Suppliers & Manufacturer in India	430 Stainless Steel Tube Steel Tube Exporter
304 430 Stainless Steel Tube Steel Tube Suppliers & Manufacturer in India	316L 430 Stainless Steel Tube Steel Tube
SS Square Pipe Hollow Sections Supplier & Manufacturer in India	ASTM A312 TP304 SS Square Pipe Supplier & Manufacturer in India
SS Bright Annealed Square Pipe	ASTM A312 TP304LStainless Steel Supplier & Manufacturer in India
Stainless Steel 201 Square Pipes Supplier & Manufacturer in India	Stainless Steel Square 316 Pipe Supplier
Large Diameter 430 Stainless Steel Tube Steel Tube	ASTM A312 TP304/304L SS Square Pipe Supplier & Manufacturer in India
SS Square Pipe Supplier & Manufacturer in India	ASTM A312 TP316 Stainless Steel Supplier & Manufacturer in India
Hot Rolled 430 Stainless Steel Tube Steel Tube Suppliers & Manufacturer in India	ASTM A312 TP316L Stainless SS & Manufacturer in India
1/2″ NB in Thickness Schedule 430 Stainless Steel Tube Steel Tube	ASTM A312 TP201 430 Stainless Steel Tube Steel Tube
4″ NB in Thickness Schedule SS Square Pipe Supplier & Manufacturer in India	ASTM A312 TP316/316L 430 Stainless Steel Tube Steel Tube Suppliers
5″ NB in Thickness Schedule SS Square Pipe Supplier & Manufacturer in India	Schedule 40 SS Square Pipe Supplier & Manufacturer in India
6″ NB in Thickness Schedule 430 Stainless Steel Tube Steel Tube Suppliers & Manufacturer in India	Schedule 80 430 Stainless Steel Tube Steel Tube Suppliers & Manufacturer in India
7″ NB in Thickness Schedule SS Square Pipe Supplier & Manufacturer in India	Schedule 10 SS Square Pipe Supplier
8″ NB in Thickness Schedule 430 Stainless Steel Tube Steel Tube Suppliers & Manufacturer in India	Sch 5 430 Stainless Steel Tube Steel Tube Suppliers
14″ NB in Thickness Schedule SS Square Pipe Supplier	430 Stainless Steel Tube Steel Tube Weight per meter
16″ NB in Thickness Schedule 430 Stainless Steel Tube Steel Tube Supplier & Manufacturer in India	Weight of 430 Stainless Steel Tube Steel Tube
18″ NB in Thickness Schedule SS Square Pipe Supplier	430 Stainless Steel Tube Steel Tube Price in India

PACKAGING AND LABELING

To ensure the safe transportation of our products, we take meticulous care in packaging them. In the case of exports, we employ standard wooden cases for packaging. Each pipe is marked with essential information, including Grade, Lot No, Size, Degree, and our trademark. Furthermore, we can provide custom markings on our products upon special requests.

QUALITY ASSURANCE

Our Products maintains stringent quality control measures for all fittings and bars throughout every production stage, from the procurement of raw materials to the dispatch of the final products. Visual inspections ensure compliance with industry-standard codes and regulations such as ASTM, ASME, MSS, DIN, EN, and JIS. Should the need arise, we can arrange for official certified Inspection Agencies to witness material reports, dimensions, and product quality conformity.

TEST CERTIFICATES

Our products come with a Manufacturer Test Certificate per EN 10204 / 3.1B and a Raw Materials Certificate. In addition, they undergo a 100% Radiography Test, and Third Party Inspection Reports can also be provided.

SHIPPING POLICY

The delivery time and dates are determined based on the type and quantity of steel ordered. Our sales team will provide a delivery schedule when you request a quotation. Please note that the delivery schedule may occasionally be subject to change, so we recommend checking with our sales department when placing your orders. Orders are typically dispatched within 2-3 business days and may take 5-10 business days to reach their destination. If Forgings are out of stock, orders may require 2-4 weeks for shipping. Our Products will promptly notify the buyer if such a situation occurs.

Stainless Steel Square Rod

Stainless Steel Rods

430 Stainless Steel Tube Steel Tubes

Industry We Serve

Cities We Deliver To

Istanbul, Coimbatore, Jamshedpur, Haryana, Dammam, Ankara, Hyderabad, Sharjah, Kuala Lumpur, Mumbai, Surat, Ranchi, Pune, Bangkok, Busan, Kuwait City, Singapore, Indore, Vadodara, Madrid, Al Jubail, Dallas, Faridabad, Secunderabad, Toronto, Petaling Jaya, Brisbane, Jaipur, Thiruvananthapuram, Colombo, Atyrau, Algiers, Los Angeles, Houston, Visakhapatnam, Tehran, Thane, Doha, Hanoi, Edmonton, Karachi, Cairo, Gurgaon, Jakarta, Ahmedabad, Geoje-si, Ho Chi Minh City, Chiyoda, Kanpur, Riyadh, Rajkot, Bhopal, La Victoria, Milan, Muscat, Chennai, Bogota, Gimhae-si, New York, Ernakulam, Granada, Santiago, Ludhiana, Dubai, Kolkata, Caracas, Howrah, Jeddah, Lahore, Courbevoie, Perth, Pimpri-Chinchwad, Aberdeen, Manama, Nagpur, Ahvaz, Montreal, Seoul, Bengaluru, Sydney, Al Khobar, Lagos, Calgary, Vung Tau, New Delhi, Nashik, Ulsan, Noida, Mexico City, Hong Kong, Rio de Janeiro, Abu Dhabi, Melbourne, Chandigarh, Baroda, Port-of-Spain, London, Navi Mumbai, Moscow.

Countries We Deliver To

Peru, Kazakhstan, Bolivia, Bhutan, Poland, Nigeria, China, Bangladesh, Norway, Estonia, Costa Rica, Taiwan, Sri Lanka, Qatar, Iran, Canada, Zimbabwe, Malaysia, Morocco, Denmark, Poland, Thailand, Egypt, Iran, Gabon, Lithuania, Netherlands, Belgium, Bulgaria, Bahrain, Mexico, Japan, Turkey, Portugal, Venezuela, South Korea, Ecuador, United Arab Emirates, Namibia, Hong Kong, Ghana, Slovakia, Germany, Austria, Vietnam, Gambia, Mongolia, Ireland, Italy, Romania, United States, Kuwait, Spain, Indonesia, Greece, France, Chile, Czech Republic, Nigeria, Israel, Tunisia, Libya, Ukraine, Nepal, Jordan, Brazil, Serbia, Afghanistan, South Africa, Lebanon, Chile, Angola, Philippines, Hungary, Mexico, Yemen, United Kingdom, Sweden, Tibet, Macau, Kenya, Puerto Rico, New Zealand, Singapore, Algeria, Azerbaijan, Oman, Pakistan, India, Saudi Arabia, Russia, Iraq, Australia, Finland, Colombia, Argentina, Croatia, Belarus, Switzerland, Trinidad & Tobago.

Other Available Products of Aluminium Rods

»   Stainless Steel Round Pipe
»   Stainless Steel Rectangular Pipe
»   Stainless Steel Hydraulic Pipe
»   Stainless Steel Oval Pipe
»   Stainless Steel 304 Pipe
»   Stainless Steel 304L Pipe
»   Stainless Steel ERW Pipe
»   Stainless Steel 316 Pipe
»   Stainless Steel 316L Pipe

» 430 Stainless Steel Tube Steel Tube
» Stainless Steel Perforated Pipe

People also search for Stainless Steel Products

Stainless Steel Tube price per kg, 430 Stainless Steel Tube Steel Tube manufacturers in india, 430 Stainless Steel Tube Steel Tube, Stainless Steel Perforated Pipe.
