Stainless Steel Ornamental Tube
STAINLESS STEEL 316L ORNAMENTAL TUBE DEALER, STAINLESS STEEL 201 ORNAMENTAL TUBES SUPPLIER, 316 STAINLESS STEEL ORNAMENTAL TUBING, POLISHED ORNAMENTAL TUBING, STAINLESS STEEL WELDED ORNAMENTAL TUBE, STEEL ORNAMENTAL TUBING
SIDHGIRI TUBES is maintaining one of the nation's largest and most diversified inventories of Stainless Steel Seamless Ornamental Tubing manufactured as per with national and international standards. Our SS Ornamental Tubing is available in a variety of sizes and can be cut and polished to your specifications. We are one of the leading supplier, stockist & distributor of ornamental Tubing in a number of grades and standard sizes, including 316/316L and 304/304L. KAMAL Steel Industries is well known as 316 ornamental stainless steel tubing manufacturer in India. We have stock of including round, ornamental stainless tubing, square and rectangular models. Buy 304l stainless steel ornamental tube at best price in India.
Stainless Steel Ornamental Tube SPECIFICATION
Siddhgiri TUBES offering Stainless Steel Ornamental Tube in customized designs. SS 304 Square Pipes are used for pressure operations such as moving liquids and gases in processing operations in the water treatment, chemical, petrochemical, food processing, dairy and marine industries. Welded tube is used as handrails, legs for office, kitchen, and hospital equipment and as architectural supports. Siddhgiri TUBES is specialized as providing Stainless Steel Ornamental Tube in Polished Grit 120 - 600 finish. SS Square pipe dimensions are nominated by outside diameter indicated by the NPS (imperial) or DN (metric) designator and sometimes referred to as the 'nominal bore' - and wall thickness is determined by the schedule number.
Specification
| range | Rounds - 1/2" OD - 6" OD Wall Thickness - .035 - .120 |
| size range | Squares - 1/2" OD - 8" OD Wall Thickness - .065 - .250 |
| range | Rectangles - 1/2" x 1" to 12" Wall Thickness - .065 - .250 |
| Grades | TP - 304,304L,316,316L,201 |
Standards |
A554 - A778 - A789 - A790 |
| Finish | Polished Grit 120 - 600, Seamless, Welded, Brushed, Pickled, Solution Annealed and Pickled up to O.D. 219.1mm,Mirror Polished |
We offer the important benefit of corrosion resistance, along with a polished appearance that is easily maintained for Ornamental Steel Tubing. These SS Ornaments are easy to weld, cut, form and machine with the proper equipment and knowledge. We offer a comprehensive range of Stainless Steel Seamless Ornamental Tubing to our customers in various industry verticals. Ornamental SS Tubing is widely used for all kinds of structural applications and fabrication projects where greater strength and superior corrosion resistance is required. According to the different applications, the 304l stainless steel ornamental tube has different diameters. Whenever any customization is needed, these SS Ornamental Tubes can be customized very easily. We have a huge selection of ornamental round, ornamental square and ornamental rectangular shapes in a standard mill finish, as well as 180 Grit polish or 600 Grit Polish & Buff. SS Ornamental Tubing can be supplied polished to a 180 grit, 240 grit or 320 grit finish. With our various satin finishes, we can supply the perfect square ornamental tubing, polished round ornamental tubing or rectangular ornamental tubing to suit your needs. We can customize the ideal 316 Ornamental Stainless Steel Tubing for your unique application. Contact to Kamal Steel Industries for confirming availability and pricing.
Stainless Steel Ornamental Tube SIZES
Finished in accordance with customer needs regarding dimensional and wall thickness specifications as well as heat treatment for more demanding applications. In general a Stainless Steel Ornamental Tube is manufactured in sizes from 1/8” to 24” according to current standards ASTM, API and ASME. If required for special projects we can also supply SS Square seamless pipes & SS Square welded pipes for bigger sizes starting from outside diameter 26” up to 48”. More Information of Stainless Steel Pipe Sizes and Stainless Steel Ornamental Tube weight chart
- • Machinery
- • Automative
- • Transport
- • construction
- • Home and commercial fixtures
Sizes
| Alloy | Height A | Width B | Wall | Length | Weight Each | Finish |
|---|---|---|---|---|---|---|
| 304 / 316L | 1" | 1-1/2" | 11 GA | 20' | 36.8 # | Mill Finish |
| 304 / 316L | 1" | 2" | 11 GA | 20' | 45.4 # | Mill Finish |
| 304 / 316L | 1" | 2" | 16 GA | 20' | 25.4 # | Mill Finish |
| 304 / 316L | 1-1/2" | 2" | 11 GA | 20' | 53.2 # | Mill Finish |
| 304 / 316L | 1-1/2" | 2" | 11 GA | 24' | 63.84 # | Mill Finish |
| 304 / 316L | 1-1/2" | 2-1/2" | 11 GA | 20' | 61.2 # | Mill Finish |
| 304 / 316L | 1-1/2" | 3" | 11 GA | 20' | 69.4 # | Mill Finish |
| 304 / 316L | 2" | 3" | 11 GA | 20' | 77.6 # | Mill Finish |
| 304 / 316L | 2" | 3" | 7 GA | 20' | 113.4 # | Mill Finish |
| 304 / 316L | 2" | 3" | 1/4" | 20' | 154.8 # | Mill Finish |
| 304 / 316L | 2" | 4" | 11 GA | 20' | 94 # | Mill Finish |
| 304 / 316L | 2" | 4" | 7 GA | 20' | 138 # | Mill Finish |
| 304 / 316L | 2" | 4" | 1/4" | 20' | 189.4 # | Mill Finish |
Stainless Steel Square Hollow Section / Size / Dimensions / Weight Chart
| Size (mm) | Thickness (mm) | Kg / Metre |
|---|---|---|
| 20 X 20 Size (mm) | 2 Thickness (mm) | 1.11 Kg / Metre |
| 25 X 25 Size (mm) | 2 Thickness (mm) | 1.43 Kg / Metre |
| 25 X 25 Size (mm) | 2.5 Thickness (mm) | 1.74 Kg / Metre |
| 25 X 25 Size (mm) | 3 Thickness (mm) | 2.04 Kg / Metre |
| 30 X 30 Size (mm) | 2 Thickness (mm) | 1.74 Kg / Metre |
| 30 X 30 Size (mm) | 2.5 Thickness (mm) | 2.14 Kg / Metre |
| 30 X 30 Size (mm) | 3 Thickness (mm) | 2.51 Kg / Metre |
| 30 X 30 Size (mm) | 3.2 Thickness (mm) | 2.65 Kg / Metre |
| 40 X 40 Size (mm) | 2 Thickness (mm) | 2.37 Kg / Metre |
| 40 X 40 Size (mm) | 2.5 Thickness (mm) | 2.92 Kg / Metre |
| 40 X 40 Size (mm) | 3 Thickness (mm) | 3.45 Kg / Metre |
| 40 X 40 Size (mm) | 4 Thickness (mm) | 4.46 Kg / Metre |
| 40 X 40 Size (mm) | 5 Thickness (mm) | 5.40 Kg / Metre |
| 50 X 50 Size (mm) | 2 Thickness (mm) | 3.00 Kg / Metre |
| 50 X 50 Size (mm) | 2.5 Thickness (mm) | 3.71 Kg / Metre |
| 50 X 50 Size (mm) | 3 Thickness (mm) | 4.39 Kg / Metre |
| 50 X 50 Size (mm) | 4 Thickness (mm) | 5.72 Kg / Metre |
| 50 X 50 Size (mm) | 5 Thickness (mm) | 6.97 Kg / Metre |
| 50 X 50 Size (mm) | 6 Thickness (mm) | 8.20 Kg / Metre |
| 50 X 50 Size (mm) | 8 Thickness (mm) | 10.50 Kg / Metre |
| 60 X 60 Size (mm) | 3 Thickness (mm) | 5.34 Kg / Metre |
| 60 X 60 Size (mm) | 3.2 Thickness (mm) | 5.67 Kg / Metre |
| 60 X 60 Size (mm) | 3.6 Thickness (mm) | 6.34 Kg / Metre |
| 60 X 60 Size (mm) | 4 Thickness (mm) | 6.97 Kg / Metre |
| 60 X 60 Size (mm) | 5 Thickness (mm) | 8.54 Kg / Metre |
| 70 X 70 Size (mm) | 2.5 Thickness (mm) | 5.28 Kg / Metre |
| 70 X 70 Size (mm) | 3 Thickness (mm) | 6.28 Kg / Metre |
| 70 X 70 Size (mm) | 3.5 Thickness (mm) | 7.25 Kg / Metre |
| 70 X 70 Size (mm) | 3.6 Thickness (mm) | 7.46 Kg / Metre |
| 70 X 70 Size (mm) | 4 Thickness (mm) | 8.23 Kg / Metre |
| 70 X 70 Size (mm) | 5 Thickness (mm) | 10.10 Kg / Metre |
| 70 X 70 Size (mm) | 8 Thickness (mm) | 15.29 Kg / Metre |
| 70 X 70 Size (mm) | 10 Thickness (mm) | 19.13 Kg / Metre |
| 80 X 80 Size (mm) | 3 Thickness (mm) | 7.22 Kg / Metre |
| 80 X 80 Size (mm) | 3.5 Thickness (mm) | 8.35 Kg / Metre |
| 80 X 80 Size (mm) | 3.6 Thickness (mm) | 8.59 Kg / Metre |
| 80 X 80 Size (mm) | 4 Thickness (mm) | 9.48 Kg / Metre |
| 80 X 80 Size (mm) | 5 Thickness (mm) | 11.70 Kg / Metre |
| 80 X 80 Size (mm) | 6 Thickness (mm) | 13.80 Kg / Metre |
| 80 X 80 Size (mm) | 6.3 Thickness (mm) | 14.40 Kg / Metre |
| 80 X 80 Size (mm) | 8 Thickness (mm) | 17.83 Kg / Metre |
| 80 X 80 Size (mm) | 10 Thickness (mm) | 21.88 Kg / Metre |
| 90 X 90 Size (mm) | 3 Thickness (mm) | 8.16 Kg / Metre |
| 90 X 90 Size (mm) | 3.5 Thickness (mm) | 9.45 Kg / Metre |
| 90 X 90 Size (mm) | 3.6 Thickness (mm) | 9.72 Kg / Metre |
| 90 X 90 Size (mm) | 4 Thickness (mm) | 10.70 Kg / Metre |
| 90 X 90 Size (mm) | 5 Thickness (mm) | 13.30 Kg / Metre |
| 90 X 90 Size (mm) | 6 Thickness (mm) | 15.70 Kg / Metre |
| 90 X 90 Size (mm) | 6.3 Thickness (mm) | 16.40 Kg / Metre |
| 90 X 90 Size (mm) | 8 Thickness (mm) | 20.32 Kg / Metre |
| 90 X 90 Size (mm) | 10 Thickness (mm) | 25.53 Kg / Metre |
| 100 X 100 Size (mm) | 3 Thickness (mm) | 9.10 Kg / Metre |
| 100 X 100 Size (mm) | 4 Thickness (mm) | 12.00 Kg / Metre |
| 100 X 100 Size (mm) | 5 Thickness (mm) | 14.80 Kg / Metre |
| 100 X 100 Size (mm) | 6 Thickness (mm) | 17.60 Kg / Metre |
| 100 X 100 Size (mm) | 6.3 Thickness (mm) | 18.40 Kg / Metre |
| 100 X 100 Size (mm) | 8 Thickness (mm) | 22.90 Kg / Metre |
| 100 X 100 Size (mm) | 10 Thickness (mm) | 27.86 Kg / Metre |
| 100 X 100 Size (mm) | 12 Thickness (mm) | 33.44 Kg / Metre |
| 120 X 120 Size (mm) | 4 Thickness (mm) | 14.50 Kg / Metre |
| 120 X 120 Size (mm) | 5 Thickness (mm) | 18.00 Kg / Metre |
| 120 X 120 Size (mm) | 6 Thickness (mm) | 21.30 Kg / Metre |
| 120 X 120 Size (mm) | 6.3 Thickness (mm) | 22.30 Kg / Metre |
| 120 X 120 Size (mm) | 8 Thickness (mm) | 27.90 Kg / Metre |
| 120 X 120 Size (mm) | 10 Thickness (mm) | 34.13 Kg / Metre |
| 120 X 120 Size (mm) | 12 Thickness (mm) | 39.94 Kg / Metre |
| 120 X 120 Size (mm) | 16 Thickness (mm) | 54.64 Kg / Metre |
| 140 X 140 Size (mm) | 6 Thickness (mm) | 25.97 Kg / Metre |
| 140 X 140 Size (mm) | 8 Thickness (mm) | 32.89 Kg / Metre |
| 140 X 140 Size (mm) | 10 Thickness (mm) | 41.15 Kg / Metre |
| 150 X 150 Size (mm) | 4 Thickness (mm) | 18.30 Kg / Metre |
| 150 X 150 Size (mm) | 5 Thickness (mm) | 22.70 Kg / Metre |
| 150 X 150 Size (mm) | 6 Thickness (mm) | 27.00 Kg / Metre |
| 150 X 150 Size (mm) | 6.3 Thickness (mm) | 28.30 Kg / Metre |
| 150 X 150 Size (mm) | 8 Thickness (mm) | 35.40 Kg / Metre |
| 150 X 150 Size (mm) | 10 Thickness (mm) | 43.47 Kg / Metre |
| 150 X 150 Size (mm) | 12 Thickness (mm) | 53.48 Kg / Metre |
| 150 X 150 Size (mm) | 16 Thickness (mm) | 65.05 Kg / Metre |
| 160 X 160 Size (mm) | 6 Thickness (mm) | 27.39 Kg / Metre |
| 160 X 160 Size (mm) | 8 Thickness (mm) | 36.90 Kg / Metre |
| 160 X 160 Size (mm) | 10 Thickness (mm) | 46.88 Kg / Metre |
| 180 X 180 Size (mm) | 5 Thickness (mm) | 27.97 Kg / Metre |
| 180 X 180 Size (mm) | 6 Thickness (mm) | 33.26 Kg / Metre |
| 180 X 180 Size (mm) | 8 Thickness (mm) | 43.00 Kg / Metre |
| 180 X 180 Size (mm) | 10 Thickness (mm) | 53.00 Kg / Metre |
| 180 X 180 Size (mm) | 12 Thickness (mm) | 61.01 Kg / Metre |
| 180 X 180 Size (mm) | 12.5 Thickness (mm) | 65.20 Kg / Metre |
| 180 X 180 Size (mm) | 16 Thickness (mm) | 81.30 Kg / Metre |
| 200 X 200 Size (mm) | 5 Thickness (mm) | 31.18 Kg / Metre |
| 200 X 200 Size (mm) | 6 Thickness (mm) | 37.09 Kg / Metre |
| 200 X 200 Size (mm) | 8 Thickness (mm) | 48.00 Kg / Metre |
| 200 X 200 Size (mm) | 10 Thickness (mm) | 59.30 Kg / Metre |
| 200 X 200 Size (mm) | 12 Thickness (mm) | 68.84 Kg / Metre |
| 200 X 200 Size (mm) | 12.5 Thickness (mm) | 73.00 Kg / Metre |
| 200 X 200 Size (mm) | 16 Thickness (mm) | 90.91 Kg / Metre |
| 250 X 250 Size (mm) | 6 Thickness (mm) | 46.83 Kg / Metre |
| 250 X 250 Size (mm) | 8 Thickness (mm) | 60.50 Kg / Metre |
| 250 X 250 Size (mm) | 10 Thickness (mm) | 75.00 Kg / Metre |
| 250 X 250 Size (mm) | 12 Thickness (mm) | 88.45 Kg / Metre |
| 250 X 250 Size (mm) | 12.5 Thickness (mm) | 92.70 Kg / Metre |
| 250 X 250 Size (mm) | 16 Thickness (mm) | 111.48 Kg / Metre |
| 300 X 300 Size (mm) | 6 Thickness (mm) | 55.30 Kg / Metre |
| 300 X 300 Size (mm) | 8 Thickness (mm) | 74.18 Kg / Metre |
| 300 X 300 Size (mm) | 10 Thickness (mm) | 90.70 Kg / Metre |
| 300 X 300 Size (mm) | 12 Thickness (mm) | 108.68 Kg / Metre |
| 300 X 300 Size (mm) | 12.5 Thickness (mm) | 112.00 Kg / Metre |
| 300 X 300 Size (mm) | 16 Thickness (mm) | 141.84 Kg / Metre |
| 350 X 350 Size (mm) | 10 Thickness (mm) | 105.93 Kg / Metre |
| 350 X 350 Size (mm) | 12 Thickness (mm) | 126.74 Kg / Metre |
| 350 X 350 Size (mm) | 16 Thickness (mm) | 166.94 Kg / Metre |
| 400 X 400 Size (mm) | 8 Thickness (mm) | 97.56 Kg / Metre |
| 400 X 400 Size (mm) | 10 Thickness (mm) | 121.95 Kg / Metre |
| 400 X 400 Size (mm) | 12 Thickness (mm) | 151.97 Kg / Metre |
| 400 X 400 Size (mm) | 16 Thickness (mm) | 191.94 Kg / Metr |
| Gauge Size | Nominal Inches | OD | ID | 304 SS Item # | 316 SS Item # | ||||
|---|---|---|---|---|---|---|---|---|---|
| OD | Wall | ID | Min | Max | Min | Max | |||
| 3 RW | .259 | .02 | .219 | .257 | .261 | .216 | .222 | 304H03RW | |
| 3 TW | .259 | .015 | .229 | .257 | .261 | .227 | .231 | 304H03TW | |
| 3 X | .259 | .01 | .239 | .257 | .261 | .237 | .241 | 304H03X | |
| 4 RW | .238 | .02 | .198 | .236 | .24 | .195 | .201 | 304H04RW | 316H04RW |
| 4 TW | .238 | .015 | .208 | .236 | .24 | .206 | .21 | 304H04TW | |
| 4 TW | .238 | .01 | .218 | .236 | .24 | .216 | .22 | 304H04TW | |
| 5 RW | .219 | .015 | .189 | .217 | .221 | .186 | .192 | 304H05RW | |
| 5 X | .219 | .007 | .205 | .217 | .221 | .203 | .207 | 304H05X | |
| 6 RW | .2030 | .015 | .173 | .2020 | .2040 | .1700 | .1760 | 304H06RW | 316H06RW |
| 6 TW | .2030 | .010 | .183 | .2020 | .2040 | .1810 | .1850 | 304H06TW | 316H06TW |
| 6 X | .2030 | .007 | .189 | .2020 | .2040 | .1870 | .1910 | 304H06X | |
| 6.5 | .1880 | .010 | .168 | .1870 | .1890 | .1650 | .1710 | 304H06.5 | |
| 7 RW | .1800 | .015 | .150 | .1790 | .1810 | .1470 | .1530 | 304H07RW | 316H07RW |
| 7 TW | .1800 | .010 | .160 | .1790 | .1810 | .1580 | .1620 | 304H07TW | |
| 7 X | .1800 | .007 | .166 | .1790 | .1810 | .1640 | .1680 | 304H07X | |
| 7 XX | .1800 | .004 | .173 | .1790 | .1810 | .1720 | .1740 | 304H07XX | |
| 7.5 | .1720 | .011 | .150 | .1710 | .1730 | .1470 | .1530 | 304H07.5 | |
| 8 RW | .1650 | .015 | .135 | .1640 | .1660 | .1320 | .1380 | 304H08RW | 316H08RW |
| 8 TW | .1650 | .010 | .145 | .1640 | .1660 | .1430 | .1470 | 304H08TW | |
| 8 XX | .1650 | .007 | .150 | .1640 | .1660 | .1475 | .1530 | 304H08XX | |
| 8.5 | .1560 | .010 | .136 | .1550 | .1570 | .1330 | .1390 | 304H08.5 | |
| 9 RW | .1480 | .015 | .118 | .1470 | .1490 | .1150 | .1210 | 304H09RW | 316H09RW |
| 9 TW | .1480 | .010 | .128 | .1470 | .1490 | .1260 | .1300 | 304H09TW | 316H09TW |
| 9 XX | .1480 | .007 | .135 | .1470 | .1490 | .1330 | .1370 | 304H09XX | |
| 9 UX | .1480 | .005 | .138 | .1470 | .1490 | .1360 | .1400 | 304H09UX | |
| 9.5 | .1410 | .011 | .119 | .1400 | .1420 | .1170 | .1210 | 304H09.5 | |
| 10 RW | .1340 | .014 | .106 | .1330 | .1350 | .1040 | .1080 | 304H10RW | 316H10RW |
| 10 TW | .1340 | .010 | .114 | .1330 | .1350 | .1120 | .1160 | 304H10TW | 316H10TW |
| 10 X | .1340 | .008 | .118 | .1330 | .1350 | .1165 | .1200 | 304H10X | |
| 10 XX | .1340 | .006 | .122 | .1330 | .1350 | .1200 | .1240 | 304H10XX | |
| 10.5 | .1260 | .010 | .106 | .1250 | .1270 | .1040 | .1080 | 304H10.5 | |
| 11 RW | .1200 | .013 | .094 | .1190 | .1210 | .0920 | .0960 | 304H11RW | 316H11RW |
| 11 TW | .1200 | .010 | .100 | .1190 | .1210 | .0980 | .1020 | 304H11TW | 316H11TW |
| 11 X | .1200 | .007 | .106 | .1190 | .1210 | .1040 | .1080 | 304H11X | |
| 11 XX | .1200 | .004 | .112 | .1190 | .1210 | .1100 | .1140 | 304H11XX | |
| 11.5 | .1150 | .010 | .095 | .1140 | .1160 | .0930 | .0960 | 304H11.5 | |
| 12 H | .1090 | .016 | .077 | .1080 | .1100 | .0750 | .0790 | 304H12H | |
| 12 RW | .1090 | .012 | .085 | .1080 | .1100 | .0830 | .0870 | 304H12RW | 316H12RW |
| 12 TW | .1090 | .009 | .091 | .1080 | .1100 | .0890 | .0930 | 304H12TW | 316H12TW |
| 12 X | .1090 | .006 | .097 | .1080 | .1100 | .0950 | .0990 | 304H12X | |
| 12 XX | .1090 | .005 | .100 | .1080 | .1100 | .0990 | .1010 | 304H12XX | |
| 12.5 | .1000 | .009 | .082 | .0990 | .1010 | .0800 | .0840 | 304H12.5 | |
| 13 RW | .0950 | .012 | .071 | .0940 | .0960 | .0690 | .0730 | 304H13RW | 316H13RW |
| 13 TW | .0950 | .009 | .077 | .0940 | .0960 | .7500 | .0790 | 304H13TW | 316H13TW |
Stainless Steel Ornamental Tube SCHEDULE CHART
| NB SIZES | SCH 5 | SCH 10 | SCH 40 | SCH 80 | SCH 160 |
|---|---|---|---|---|---|
1/8″ |
|||||
1/4″ |
|||||
3/8″ |
|||||
1/2″ |
|||||
3/4″ |
|||||
1″ |
|||||
1 1/4″ |
|||||
1 1/2″ |
|||||
2″ |
|||||
2 1/2″ |
|||||
3″ |
|||||
4″ |
|||||
5″ |
|||||
6″ |
Dimension Sizes
| Ornamental Stainless Steel Tubing - Sizes & Weight per foot | |||||||
| Stainless Steel Ornamental Tube Type - 304/L and Type-316/L | |||||||
| Gauge | 18 | 16 | 14 | 11 | 7 | 1/4 | 3/8 |
| Inches | 0.049 | 0.065 | 0.083 | 0.120 | 0.180 | 0.250 | 0.375 |
| 1/2 x 3/4 | 0.38 | 0.05 | |||||
| 1/2 x 1 | 0.50 | 0.65 | 0.82 | 1.13 | |||
| 1/2 x 1-1/2 | 0.63 | 0.83 | 1.03 | 1.45 | |||
| 1/2 x 2 | 0.82 | 1.08 | 1.37 | 1.93 | 2.09 | ||
| 3/4 x 1 | 0.56 | 0.74 | 0.92 | 1.29 | |||
| 3/4 x 1-1/4 | 0.63 | 0.83 | 1.03 | 1.45 | 2.17 | ||
| 3/4 x 1-1/2 | 0.99 | 1.25 | 1.77 | ||||
| 3/4 x 2 | 0.89 | 1.17 | 1.48 | 2.09 | |||
| 1 x 1-1/4 | 0.99 | 1.25 | 1.77 | ||||
| 1 x 1-1/2 | 0.82 | 1.08 | 1.37 | 1.93 | |||
| 1 x 2 | 0.97 | 1.27 | 1.51 | 2.26 | 3.63 | ||
| 1 x 2-1/2 | 1.49 | 1.88 | 2.66 | ||||
| 1 x 3 | 1.30 | 1.69 | 2.14 | 3.06 | 4.46 | 6.01 | |
| 1 x 4 | 2.72 | 3.88 | 5.68 | 7.67 | |||
| 1-1/2 x 2 | 1.49 | 1.88 | 2.66 | ||||
| 1-1/2 x 2-1/2 | 1.30 | 1.69 | 2.14 | 3.06 | 4.46 | 6.01 | |
| 1-1/2 x 3 | 1.93 | 2.45 | 3.48 | 5.28 | |||
| 1-1/2 x 4 | 1.81 | 2.38 | 3.03 | 4.33 | 5.30 | 7.58 | |
| 2 x 3 | 2.72 | 3.88 | 5.68 | 7.67 | |||
| 2 x 4 | 3.29 | 4.97 | 6.90 | 9.35 | 13.64 | ||
| 2 x 5 | 5.67 | 8.06 | 10.89 | ||||
| 2 x 6 | 6.26 | 9.27 | 12.68 | 18.52 | |||
| 2 x 8 | 8.02 | 11.90 | 16.35 | 23.53 | |||
| 2 x 10 | 9.46 | 14.07 | 18.77 | 28.53 | |||
| 3 x 4 | 5.67 | 8.06 | 10.89 | ||||
| 3 x 5 | 6.26 | 9.27 | 12.68 | 18.52 | |||
| 3 x 6 | 7.22 | 10.52 | 13.80 | 21.03 | |||
| 4 x 6 | 8.02 | 11.90 | 16.35 | 23.35 | |||
| 4 x 8 | 9.46 | 14.07 | 18.77 | 28.53 | |||
| 4 x 10 | 22.71 | 33.54 | |||||
| 4 x 12 | 26.03 | 38.55 | |||||
| 6 x 8 | 22.51 | 33.35 | |||||
| 6 x 10 | 26.27 | 38.91 | |||||
| All material offer as mill finish, polished 180 grit or polished 320 grit | |||||||
| All material produced to ASTM A554 specification (Latest Revision) | |||||||
Stainless Steel Ornamental Tube PRESSURE RATING
| Pressure Rating (psig) | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Pipe Size (inches) |
Pipe Schedule | Temperature (oF) | ||||||||
| 100 | 200 | 300 | 400 | 500 | 600 | 650 | 700 | 750 | ||
| 1" | 40 | 3048 | 2629 | 2362 | 2171 | 2019 | 1924 | 1867 | 1824 | 1810 |
| 80 | 4213 | 3634 | 3265 | 3002 | 2791 | 2659 | 2580 | 2528 | 2501 | |
| 160 | 6140 | 5296 | 4759 | 4375 | 4068 | 3876 | 3761 | 3684 | 3646 | |
| 1 1/2" | 40 | 2257 | 1947 | 1750 | 1608 | 1496 | 1425 | 1383 | 1354 | 1340 |
| 80 | 3182 | 2744 | 2466 | 2267 | 2108 | 2009 | 1949 | 1909 | 1889 | |
| 160 | 4619 | 3984 | 3580 | 3291 | 3060 | 2916 | 2829 | 2772 | 2743 | |
| 2" | 40 | 1902 | 1640 | 1474 | 1355 | 1260 | 1201 | 1165 | 1141 | 1129 |
| 80 | 2747 | 2369 | 2129 | 1957 | 1820 | 1734 | 1682 | 1648 | 1631 | |
| 160 | 4499 | 3880 | 3486 | 3205 | 2980 | 2840 | 2755 | 2699 | 2671 | |
| 3" | 40 | 1806 | 1558 | 1400 | 1287 | 1196 | 1140 | 1106 | 1084 | 1072 |
| 80 | 2553 | 2202 | 1979 | 1819 | 1691 | 1612 | 1564 | 1532 | 1516 | |
| 160 | 3840 | 3312 | 2976 | 2736 | 2544 | 2424 | 2352 | 2304 | 2280 | |
| 4" | 40 | 1531 | 1321 | 1187 | 1091 | 1014 | 967 | 938 | 919 | 909 |
| 80 | 2213 | 1909 | 1715 | 1577 | 1466 | 1397 | 1355 | 1328 | 1314 | |
| 160 | 3601 | 3106 | 2791 | 2566 | 2386 | 2273 | 2206 | 2161 | 2138 | |
| 5" | 40 | 1342 | 1158 | 1040 | 956 | 889 | 847 | 822 | 805 | 797 |
| 80 | 1981 | 1709 | 1535 | 1411 | 1312 | 1250 | 1213 | 1189 | 1176 | |
| 160 | 3414 | 2945 | 2646 | 2433 | 2262 | 2155 | 2091 | 2049 | 2027 | |
| 6" | 40 | 1219 | 1052 | 945 | 869 | 808 | 770 | 747 | 732 | 724 |
| 80 | 1913 | 1650 | 1483 | 1363 | 1267 | 1208 | 1172 | 1148 | 1136 | |
| 160 | 3289 | 2836 | 2549 | 2343 | 2179 | 2076 | 2014 | 1973 | 1953 | |
| 8" | 40 | 1073 | 926 | 832 | 765 | 711 | 678 | 657 | 644 | 637 |
| 80 | 1692 | 1459 | 1311 | 1205 | 1121 | 1068 | 1036 | 1015 | 1005 | |
| 160 | 3175 | 2738 | 2460 | 2262 | 2103 | 2004 | 1944 | 1905 | 1885 | |
| 10" | 40 | 974 | 840 | 755 | 694 | 645 | 615 | 596 | 584 | 578 |
| 80 | 1609 | 1388 | 1247 | 1147 | 1066 | 1016 | 986 | 966 | 956 | |
| 160 | 3147 | 2714 | 2439 | 2242 | 2085 | 1986 | 1927 | 1880 | 1868 | |
STAINLESS STEEL PIPE TOLERANCES
| NPS Designator | Permissible Variations in Outside Diameter | |
|---|---|---|
| Over In. | Under In. | |
| 1/8 to 1-1/2, incl | 1/64 (0.015) | 1/32 (0.031) |
| Over 1-1/2 to 4, incl | 1/32 (0.031) | 1/32 (0.031) |
| Over 4 to 8, incl | 1/16 (0.062) | 1/32 (0.031) |
| Over 8 to 18, incl | 3/23 (0.093) | 1/32 (0.031) |
Nominal Wall Thickness:
| NPS Designator | Outside Diameter in. | Schedule 10S in. | Schedule 40S in. | Schedule 80S in. | Schedule 160 in. | Schedule XX in. |
|---|---|---|---|---|---|---|
| 1/4 | 0.540 | 0.065 | 0.088 | 0.119 | ||
| 3/8 | 0.675 | 0.065 | 0.091 | 0.126 | ||
| 1/2 | 0.840 | 0.083 | 0.109 | 0.147 | .188 | .294 |
| 3/4 | 1.050 | 0.083 | 0.113 | 0.154 | .218 | .308 |
| 1.0 | 1.315 | 0.109 | 0.133 | 0.179 | .250 | .358 |
| 1 1/4 | 1.660 | 0.109 | 0.140 | 0.191 | .250 | .382 |
| 1 1/2 | 1.900 | 0.109 | 0.145 | 0.200 | .281 | .400 |
| 2 | 2.375 | 0.109 | 0.154 | 0.218 | .343 | .436 |
| 2 1/2 | 2.875 | 0.120 | 0.203 | 0.276 | .375 | .552 |
| 3 | 3.500 | 0.120 | 0.216 | 0.300 | .438 | .600 |
| 3 1/2 | 4.000 | 0.120 | 0.226 | 0.318 | .636 | |
| 4 | 4.500 | 0.120 | 0.237 | 0.337 | .534 | .674 |
| 5 | 5.563 | 0.134 | 0.258 | 0.375 | .625 | .750 |
| 6 | 6.625 | 0.134 | 0.280 | 0.432 | .719 | .864 |
| 8 | 8.625 | 0.148 | 0.322 | 0.500 | .906 | .875 |
| 10 | 10.750 | 0.165 | 0.365 | 0.500 | 1.125 | |
| 12 | 12.750 | 0.180 | 0.375 | 0.500 | 1.312 | |
| 14 | 14.000 | 0.188 | 0.375 | 0.500 | 1.406 | |
| 16 | 16.000 | 0.188 | 0.375 | 0.500 | 1.594 |
Minimum Wall Thickness on Inspection:
- tn * 0.875 = tm Where: tn = nominal wall thickness, in. [mm], and tm= minimum wall thicknesses, in. [mm]
- The wall thickness is inch-pound units is rounded to three decimal places in accordance with the rounding method of Practice E29. The wall thickness in SI units is rounded to one decimal place in accordance with the rounding method of Practice E29.
| Nominal Thickness | Minimum Thickness on Inspection | Nominal Thickness | Minimum Thickness on Inspection | Nominal Thickness | Minimum Thickness on Inspection | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| in. | mm | in | mm | in | mm | in | mm | in | mm | in | mm |
| 0.068 | 1.7 | 0.060 | 1.5 | 0.294 | 7.5 | 0.257 | 6.5 | 0.750 | 19.0 | 0.658 | 16.6 |
| 0.068 | 2.2 | 0.077 | 2.0 | 0.300 | 7.6 | 0.262 | 6.7 | 0.812 | 20.6 | 0.710 | 18.0 |
| 0.091 | 2.3 | 0.080 | 2.0 | 0.307 | 7.8 | 0.269 | 6.8 | 0.843 | 21.4 | 0.736 | 18.7 |
| 0.095 | 2.4 | 0.083 | 2.1 | 0.308 | 7.8 | 0.270 | 6.9 | 0.854 | 21.7 | 0.756 | 19.2 |
| 0.113 | 2.9 | 0.099 | 2.5 | 0.312 | 7.9 | 0.273 | 6.9 | 0.875 | 22.2 | 0.766 | 19.5 |
| 0.119 | 3.0 | 0.104 | 2.6 | 0.318 | 8.1 | 0.278 | 7.1 | 0.906 | 23.0 | 0.783 | 20.1 |
| 0.125 | 3.2 | 0.109 | 2.8 | 0.322 | 8.2 | 0.282 | 7.2 | 0.937 | 23.8 | 0.820 | 20.8 |
| 0.126 | 3.2 | 0.110 | 2.8 | 0.330 | 8.4 | 0.289 | 7.3 | 0.968 | 24.6 | 0.847 | 21.5 |
| 0.133 | 3.4 | 0.116 | 2.9 | 0.337 | 8.6 | 0.295 | 7.5 | 1.000 | 25.4 | 0.875 | 22.2 |
| 0.140 | 3.6 | 0.122 | 3.1 | 0.343 | 8.7 | 0.300 | 7.6 | 1.031 | 26.2 | 0.902 | 22.9 |
| 0.145 | 3.7 | 0.127 | 3.2 | 0.344 | 8.7 | 0.301 | 7.6 | 1.062 | 27.0 | 0.929 | 23.6 |
| 0.147 | 3.7 | 0.129 | 3.3 | 0.358 | 9.1 | 0.313 | 8.0 | 1.083 | 27.8 | 0.956 | 24.3 |
| 0.154 | 3.9 | 0.135 | 3.4 | 0.365 | 9.3 | 0.319 | 8.1 | 1.125 | 28.6 | 0.984 | 25.0 |
| 0.156 | 4.0 | 0.136 | 3.5 | 0.375 | 9.5 | 0.328 | 8.3 | 1.156 | 29.4 | 1.012 | 25.7 |
| 0.179 | 4.5 | 0.157 | 4.0 | 0.382 | 9.7 | 0.334 | 8.5 | 1.218 | 30.9 | 1.066 | 27.1 |
| 0.187 | 43.7 | 0.164 | 4.2 | 0.400 | 10.2 | 0.350 | 8.9 | 1.250 | 31.8 | 1.094 | 27.8 |
| 0.188 | 4.8 | 0.164 | 4.2 | 0.406 | 10.3 | 0.355 | 9.0 | 1.281 | 32.5 | 1.121 | 28.5 |
| 0.191 | 4.9 | 0.167 | 4.2 | 0.432 | 10.4 | 0.378 | 9.6 | 1.312 | 33.3 | 1.148 | 29.2 |
| 0.200 | 5.1 | 0.175 | 4.4 | 0.436 | 11.1 | 0.382 | 9.7 | 1.343 | 34.1 | 1.175 | 29.8 |
| 0.203 | 5.2 | 0.178 | 4.5 | 0.437 | 11.1 | 0.382 | 9.7 | 1.375 | 34.9 | 1.203 | 30.6 |
| 0.216 | 5.5 | 0.189 | 4.8 | 0.438 | 11.1 | 0.383 | 9.7 | 1.406 | 35.7 | 1.230 | 31.2 |
| 0.218 | 5.5 | 0.191 | 4.9 | 0.500 | 12.7 | 0.438 | 11.1 | 1.436 | 36.5 | 1.258 | 32.0 |
| 0.219 | 5.6 | 0.192 | 4.9 | 0.531 | 13.5 | 0.465 | 11.8 | 1.500 | 36.1 | 1.312 | 33.3 |
| 0.226 | 5.7 | 0.196 | 5.0 | 0.552 | 14.0 | 0.483 | 12.3 | 1.531 | 38.9 | 1.340 | 34.0 |
| 0.237 | 6.0 | 0.207 | 5.2 | 0.562 | 14.3 | 0.492 | 12.5 | 1.562 | 39.7 | 1.367 | 34.7 |
| 0.250 | 6.4 | 0.219 | 5.6 | 0.593 | 15.1 | 0.519 | 13.2 | 1.593 | 40.5 | 1.394 | 35.4 |
| 0.258 | 6.6 | 0.226 | 5.7 | 0.600 | 15.2 | 0.525 | 13.3 | 1.750 | 44.5 | 1.531 | 38.9 |
| 0.276 | 7.0 | 0.242 | 6.1 | 0.625 | 15.9 | 0.547 | 13.9 | 1.781 | 45.2 | 1.558 | 39.6 |
| 0.277 | 7.0 | 0.242 | 6.1 | 0.656 | 16.6 | 0.573 | 14.6 | 1.812 | 46.0 | 1.586 | 49.3 |
| 0.279 | 7.1 | 0.244 | 6.2 | 0.674 | 17.1 | 0.590 | 15.0 | 1.968 | 50.0 | 1.772 | 43.7 |
| 0.280 | 7.1 | 0.245 | 6.2 | 0.687 | 17.4 | 0.601 | 15.3 | 2.062 | 52.4 | 1.804 | 45.8 |
| 0.281 | 7.1 | 0.246 | 6.2 | 0.719 | 18.3 | 0.629 | 16.0 | 2.343 | 59.5 | 2.050 | 52.1 |
Stainless Steel Ornamental Tube CHEMICAL COMPOSITION
The below table shows the chemical composition of the used for Stainless Steel Pipes:
| GRADES | UNS | C | Mn | P | S | Si | Cr | Ni | Mo | Ti | Nb | N |
| TP304 | S30400 | 0.08 | 2 | 0.045 | 0.03 | 1 | 18.0-20.0 | 8.0-11.0 | ||||
| TP304L | S30403 | 0.035 | 2 | 0.045 | 0.03 | 1 | 18.0-20.0 | 8.0-13.0 | ||||
| TP316 | S3160 | 0.08 | 2 | 0.045 | 0.03 | 1 | 16.0-18.0 | 11.0-14.0 | 2.0-3.0 | |||
| TP316L | S31603 | 0.035 | 2 | 0.045 | 0.03 | 1 | 16.0-18.0 | 10.0-14.0 | 2.0-3.0 |
Stainless Steel Ornamental Tube MECHANICAL PROPERTIES
| Material | Heat | Temperure | Tensile Strength | Yield Strength | Elongation %, Min |
| Treatment | Min. | Ksi (MPa), Min. | Ksi (MPa), Min. | ||
| º F(º C) | |||||
| TP304 | Solution | 1900 (1040) | 75(515) | 30(205) | 35 |
| TP304L | Solution | 1900 (1040) | 70(485) | 25(170) | 35 |
| TP316 | Solution | 1900(1040) | 75(515) | 30(205) | 35 |
| TP316L | Solution | 1900(1040) | 70(485) | 25(170) | 35 |
AVAILABLE STOCK OF SS SQUARE PIPE
| Stainless Steel Seamless Square Pipe Supplier & Manufacturer in India | SS Seamless Square Pipe Supplier |
| Seamless SS Square Pipe Supplier & Manufacturer in India | SS Polished Square Pipe Supplier & Manufacturer in India |
| Stainless Steel Ornamental Tube Suppliers & Manufacturer in India | Stainless Steel Ornamental Tube Exporter |
| 304 Stainless Steel Ornamental Tube Suppliers & Manufacturer in India | 316L Stainless Steel Ornamental Tube |
| SS Square Pipe Hollow Sections Supplier & Manufacturer in India | ASTM A312 TP304 SS Square Pipe Supplier & Manufacturer in India |
| SS Bright Annealed Square Pipe | ASTM A312 TP304LStainless Steel Supplier & Manufacturer in India |
| Stainless Steel 201 Square Pipes Supplier & Manufacturer in India | Stainless Steel Square 316 Pipe Supplier |
| Large Diameter Stainless Steel Ornamental Tube | ASTM A312 TP304/304L SS Square Pipe Supplier & Manufacturer in India |
| SS Square Pipe Supplier & Manufacturer in India | ASTM A312 TP316 Stainless Steel Supplier & Manufacturer in India |
| Hot Rolled Stainless Steel Ornamental Tube Suppliers & Manufacturer in India | ASTM A312 TP316L Stainless SS & Manufacturer in India |
| 1/2″ NB in Thickness Schedule Stainless Steel Ornamental Tube | ASTM A312 TP201 Stainless Steel Ornamental Tube |
| 4″ NB in Thickness Schedule SS Square Pipe Supplier & Manufacturer in India | ASTM A312 TP316/316L Stainless Steel Ornamental Tube Suppliers |
| 5″ NB in Thickness Schedule SS Square Pipe Supplier & Manufacturer in India | Schedule 40 SS Square Pipe Supplier & Manufacturer in India |
| 6″ NB in Thickness Schedule Stainless Steel Ornamental Tube Suppliers & Manufacturer in India | Schedule 80 Stainless Steel Ornamental Tube Suppliers & Manufacturer in India |
| 7″ NB in Thickness Schedule SS Square Pipe Supplier & Manufacturer in India | Schedule 10 SS Square Pipe Supplier |
| 8″ NB in Thickness Schedule Stainless Steel Ornamental Tube Suppliers & Manufacturer in India | Sch 5 Stainless Steel Ornamental Tube Suppliers |
| 14″ NB in Thickness Schedule SS Square Pipe Supplier | Stainless Steel Ornamental Tube Weight per meter |
| 16″ NB in Thickness Schedule Stainless Steel Ornamental Tube Supplier & Manufacturer in India | Weight of Stainless Steel Ornamental Tube |
| 18″ NB in Thickness Schedule SS Square Pipe Supplier | Stainless Steel Ornamental Tube Price in India |
PACKAGING AND LABELING
To ensure the safe transportation of our products, we take meticulous care in packaging them. In the case of exports, we employ standard wooden cases for packaging. Each pipe is marked with essential information, including Grade, Lot No, Size, Degree, and our trademark. Furthermore, we can provide custom markings on our products upon special requests.
QUALITY ASSURANCE
Our Products maintains stringent quality control measures for all fittings and bars throughout every production stage, from the procurement of raw materials to the dispatch of the final products. Visual inspections ensure compliance with industry-standard codes and regulations such as ASTM, ASME, MSS, DIN, EN, and JIS. Should the need arise, we can arrange for official certified Inspection Agencies to witness material reports, dimensions, and product quality conformity.
TEST CERTIFICATES
Our products come with a Manufacturer Test Certificate per EN 10204 / 3.1B and a Raw Materials Certificate. In addition, they undergo a 100% Radiography Test, and Third Party Inspection Reports can also be provided.
SHIPPING POLICY
The delivery time and dates are determined based on the type and quantity of steel ordered. Our sales team will provide a delivery schedule when you request a quotation. Please note that the delivery schedule may occasionally be subject to change, so we recommend checking with our sales department when placing your orders. Orders are typically dispatched within 2-3 business days and may take 5-10 business days to reach their destination. If Forgings are out of stock, orders may require 2-4 weeks for shipping. Our Products will promptly notify the buyer if such a situation occurs.
Stainless Steel Square Rod
Stainless Steel Rods
Stainless Steel Rods
Stainless Steel Ornamental Tubes
Industry We Serve
Cities We Deliver To
Istanbul, Coimbatore, Jamshedpur, Haryana, Dammam, Ankara, Hyderabad, Sharjah, Kuala Lumpur, Mumbai, Surat, Ranchi, Pune, Bangkok, Busan, Kuwait City, Singapore, Indore, Vadodara, Madrid, Al Jubail, Dallas, Faridabad, Secunderabad, Toronto, Petaling Jaya, Brisbane, Jaipur, Thiruvananthapuram, Colombo, Atyrau, Algiers, Los Angeles, Houston, Visakhapatnam, Tehran, Thane, Doha, Hanoi, Edmonton, Karachi, Cairo, Gurgaon, Jakarta, Ahmedabad, Geoje-si, Ho Chi Minh City, Chiyoda, Kanpur, Riyadh, Rajkot, Bhopal, La Victoria, Milan, Muscat, Chennai, Bogota, Gimhae-si, New York, Ernakulam, Granada, Santiago, Ludhiana, Dubai, Kolkata, Caracas, Howrah, Jeddah, Lahore, Courbevoie, Perth, Pimpri-Chinchwad, Aberdeen, Manama, Nagpur, Ahvaz, Montreal, Seoul, Bengaluru, Sydney, Al Khobar, Lagos, Calgary, Vung Tau, New Delhi, Nashik, Ulsan, Noida, Mexico City, Hong Kong, Rio de Janeiro, Abu Dhabi, Melbourne, Chandigarh, Baroda, Port-of-Spain, London, Navi Mumbai, Moscow.
Countries We Deliver To
Peru, Kazakhstan, Bolivia, Bhutan, Poland, Nigeria, China, Bangladesh, Norway, Estonia, Costa Rica, Taiwan, Sri Lanka, Qatar, Iran, Canada, Zimbabwe, Malaysia, Morocco, Denmark, Poland, Thailand, Egypt, Iran, Gabon, Lithuania, Netherlands, Belgium, Bulgaria, Bahrain, Mexico, Japan, Turkey, Portugal, Venezuela, South Korea, Ecuador, United Arab Emirates, Namibia, Hong Kong, Ghana, Slovakia, Germany, Austria, Vietnam, Gambia, Mongolia, Ireland, Italy, Romania, United States, Kuwait, Spain, Indonesia, Greece, France, Chile, Czech Republic, Nigeria, Israel, Tunisia, Libya, Ukraine, Nepal, Jordan, Brazil, Serbia, Afghanistan, South Africa, Lebanon, Chile, Angola, Philippines, Hungary, Mexico, Yemen, United Kingdom, Sweden, Tibet, Macau, Kenya, Puerto Rico, New Zealand, Singapore, Algeria, Azerbaijan, Oman, Pakistan, India, Saudi Arabia, Russia, Iraq, Australia, Finland, Colombia, Argentina, Croatia, Belarus, Switzerland, Trinidad & Tobago.
Other Available Products of Aluminium Rods
» Stainless Steel Round Pipe
» Stainless Steel Rectangular Pipe
» Stainless Steel Hydraulic Pipe
» Stainless Steel Oval Pipe
» Stainless Steel 304 Pipe
» Stainless Steel 304L Pipe
» Stainless Steel ERW Pipe
» Stainless Steel 316 Pipe
» Stainless Steel 316L Pipe
» Stainless Steel Hollow Pipe
» Stainless Steel Perforated Pipe
People also search for Stainless Steel Products
Stainless Steel Tube price per kg, Stainless Steel Ornamental Tube manufacturers in india, Stainless Steel Rectangular Pipe, Stainless Steel Perforated Pipe.
