Stainless Steel Pipe For Thermocouple
Stainless Steel Pipes for Thermocouple is available in Inconel nickel alloy and stainless steel. Tubes are available in open one end as well as closed at both ends. The standard length for Thermocouple Parts Protection Tube available from stock is 6 inches. Otherwise, with Kamal Steel practically any length tube is available on short delivery.
Stainless Steel Pipe For Thermocouple SPECIFICATION
Siddhgiri Tubes offering Stainless Steel Pipe For Thermocouple in customized designs. SS 304 Square Pipes are used for pressure operations such as moving liquids and gases in processing operations in the water treatment, chemical, petrochemical, food processing, dairy and marine industries. Welded tube is used as handrails, legs for office, kitchen, and hospital equipment and as architectural supports. Siddhgiri Tubes is specialized as providing Stainless Steel Pipe For Thermocouple in ERW Grit 120 - 600 finish. SS Square pipe dimensions are nominated by outside diameter indicated by the NPS (imperial) or DN (metric) designator and sometimes referred to as the 'nominal bore' - and wall thickness is determined by the schedule number.
STAINLESS STEEL THERMOCOUPLE PIPE SPECIFICATION
Material | SS |
SIze | According To Customer’s Drawing |
Type | High Temperature Hose |
Name | Thermocouple Protection Tubes |
Surface Roughness | According To Customer Requirements |
Service | OEM Or ODM |
STAINLESS STEEL THERMOCOUPLE PIPE DESCRIPTION Stainless Steel Thermocouple Tubes Suppliers in Bangalore and Chennai, ASTM A312 TP304 Thermocouple Material in Stock at Best Price in India
Siddhgiri Tubes protection tubes are intended for use with fine or heavy gauge thermocouples and ceramic insulators, as well as Kamal Steel standard thermocouple wire. Bare wire thermocouples can be insulated using ceramic insulators as well as the insulators used in replacement elements. Kamal Steel's protection tubes can be conveniently secured into vessels, pipes, and chambers by using compression fittings. Sleeve Pipe for Thermocouple is used for Thermocouple or Spring-type thermocouple. They are available in Diameter 6 mm &8mm and different length. 1/4 INCH DIAMETER 316 STAINLESS STEEL TUBING FOR THERMOCOUPLE IN STOCK, “SERIES 3H” CERAMIC PROTECTED THERMOCOUPLE DISTRIBUTOR High Temperature Tubing is available in many types of finish Zinc plate in white, yellow, blue, or black color, Zn/Ni plating, Mechanical zinc plating, Cr3+, black oxide, brass plate, Ni plate, electrophoresis, dacromet, hot-dipped galvanized, positive electrode oxidization. Flanged, Threaded, Van Stone and welded mounting styles with stem profile options allow for application flexibility. A wide selection of thermocouple protection tube from stainless steel to exotic materials meets varying process specifications. Flexible design modifiers for root bore & tip thickness allow customization for special application requirements. It has differing flange material from the stem for cost-efficiency. Metal Ceramic (Lt-1®) Protection Tubes are having material certification, NACE, and PMI, ensure material traceability or compatibility. Special testing options to meet process requirements including dye penetration test, external hydrostatic pressure test, and more.
Stainless Steel Pipe For Thermocouple SIZES
SS Square pipes are finished in accordance with customer needs regarding dimensional and wall thickness specifications as well as heat treatment for more demanding applications. In general a Stainless Steel Pipe For Thermocouple is manufactured in sizes from 1/8” to 24” according to current standards ASTM, API and ASME. If required for special projects we can also supply SS Square seamless pipes & SS Square welded pipes for bigger sizes starting from outside diameter 26” up to 48”. More Information of Stainless Steel Pipe Sizes and Stainless Steel Pipe For Thermocouple weight chart
- • Machinery
- • Automative
- • Transport
- • construction
- • Home and commercial fixtures
Stainless Steel Pipe For Thermocouple DIMENSIONS AND WEIGHTS
MM | 0.65 | 0.80 | 0.90 | 0.95 | 1.00 | 1.20 | 1.50 | 2.00 | 2.50 | |
12.5 x 12.5 | 0.075 | 0.091 | 0.102 | 0.107 | 0.112 | 0.133 | 0.163 | |||
20 x 20 | 0.176 | 0.184 | 0.220 | 0.271 | 0.354 | 0.433 | 0.508 | |||
25 x 25 | 0.221 | 0.232 | 0.277 | 0.343 | 0.450 | 0.553 | 0.652 | |||
30 x 30 | 0.267 | 0.280 | 0.335 | 0.415 | 0.516 | 0.673 | 0.796 | |||
38 x 38 | 0.340 | 0.358 | 0.427 | 0.531 | 0.700 | 0.866 | 1.027 | |||
40 x 40 | 0.358 | 0.376 | 0.450 | 0.559 | 0.738 | 0.898 | 1.084 | |||
50 x 50 | 0.473 | 0.565 | 0.703 | 0.930 | 1.153 | 1.372 |
Stainless Steel Square ERW Section / Size / Dimensions / Weight Chart
Size (mm) | Thickness (mm) | Kg / Metre |
---|---|---|
20 X 20 Size (mm) | 2 Thickness (mm) | 1.11 Kg / Metre |
25 X 25 Size (mm) | 2 Thickness (mm) | 1.43 Kg / Metre |
25 X 25 Size (mm) | 2.5 Thickness (mm) | 1.74 Kg / Metre |
25 X 25 Size (mm) | 3 Thickness (mm) | 2.04 Kg / Metre |
30 X 30 Size (mm) | 2 Thickness (mm) | 1.74 Kg / Metre |
30 X 30 Size (mm) | 2.5 Thickness (mm) | 2.14 Kg / Metre |
30 X 30 Size (mm) | 3 Thickness (mm) | 2.51 Kg / Metre |
30 X 30 Size (mm) | 3.2 Thickness (mm) | 2.65 Kg / Metre |
40 X 40 Size (mm) | 2 Thickness (mm) | 2.37 Kg / Metre |
40 X 40 Size (mm) | 2.5 Thickness (mm) | 2.92 Kg / Metre |
40 X 40 Size (mm) | 3 Thickness (mm) | 3.45 Kg / Metre |
40 X 40 Size (mm) | 4 Thickness (mm) | 4.46 Kg / Metre |
40 X 40 Size (mm) | 5 Thickness (mm) | 5.40 Kg / Metre |
50 X 50 Size (mm) | 2 Thickness (mm) | 3.00 Kg / Metre |
50 X 50 Size (mm) | 2.5 Thickness (mm) | 3.71 Kg / Metre |
50 X 50 Size (mm) | 3 Thickness (mm) | 4.39 Kg / Metre |
50 X 50 Size (mm) | 4 Thickness (mm) | 5.72 Kg / Metre |
50 X 50 Size (mm) | 5 Thickness (mm) | 6.97 Kg / Metre |
50 X 50 Size (mm) | 6 Thickness (mm) | 8.20 Kg / Metre |
50 X 50 Size (mm) | 8 Thickness (mm) | 10.50 Kg / Metre |
60 X 60 Size (mm) | 3 Thickness (mm) | 5.34 Kg / Metre |
60 X 60 Size (mm) | 3.2 Thickness (mm) | 5.67 Kg / Metre |
60 X 60 Size (mm) | 3.6 Thickness (mm) | 6.34 Kg / Metre |
60 X 60 Size (mm) | 4 Thickness (mm) | 6.97 Kg / Metre |
60 X 60 Size (mm) | 5 Thickness (mm) | 8.54 Kg / Metre |
70 X 70 Size (mm) | 2.5 Thickness (mm) | 5.28 Kg / Metre |
70 X 70 Size (mm) | 3 Thickness (mm) | 6.28 Kg / Metre |
70 X 70 Size (mm) | 3.5 Thickness (mm) | 7.25 Kg / Metre |
70 X 70 Size (mm) | 3.6 Thickness (mm) | 7.46 Kg / Metre |
70 X 70 Size (mm) | 4 Thickness (mm) | 8.23 Kg / Metre |
70 X 70 Size (mm) | 5 Thickness (mm) | 10.10 Kg / Metre |
70 X 70 Size (mm) | 8 Thickness (mm) | 15.29 Kg / Metre |
70 X 70 Size (mm) | 10 Thickness (mm) | 19.13 Kg / Metre |
80 X 80 Size (mm) | 3 Thickness (mm) | 7.22 Kg / Metre |
80 X 80 Size (mm) | 3.5 Thickness (mm) | 8.35 Kg / Metre |
80 X 80 Size (mm) | 3.6 Thickness (mm) | 8.59 Kg / Metre |
80 X 80 Size (mm) | 4 Thickness (mm) | 9.48 Kg / Metre |
80 X 80 Size (mm) | 5 Thickness (mm) | 11.70 Kg / Metre |
80 X 80 Size (mm) | 6 Thickness (mm) | 13.80 Kg / Metre |
80 X 80 Size (mm) | 6.3 Thickness (mm) | 14.40 Kg / Metre |
80 X 80 Size (mm) | 8 Thickness (mm) | 17.83 Kg / Metre |
80 X 80 Size (mm) | 10 Thickness (mm) | 21.88 Kg / Metre |
90 X 90 Size (mm) | 3 Thickness (mm) | 8.16 Kg / Metre |
90 X 90 Size (mm) | 3.5 Thickness (mm) | 9.45 Kg / Metre |
90 X 90 Size (mm) | 3.6 Thickness (mm) | 9.72 Kg / Metre |
90 X 90 Size (mm) | 4 Thickness (mm) | 10.70 Kg / Metre |
90 X 90 Size (mm) | 5 Thickness (mm) | 13.30 Kg / Metre |
90 X 90 Size (mm) | 6 Thickness (mm) | 15.70 Kg / Metre |
90 X 90 Size (mm) | 6.3 Thickness (mm) | 16.40 Kg / Metre |
90 X 90 Size (mm) | 8 Thickness (mm) | 20.32 Kg / Metre |
90 X 90 Size (mm) | 10 Thickness (mm) | 25.53 Kg / Metre |
100 X 100 Size (mm) | 3 Thickness (mm) | 9.10 Kg / Metre |
100 X 100 Size (mm) | 4 Thickness (mm) | 12.00 Kg / Metre |
100 X 100 Size (mm) | 5 Thickness (mm) | 14.80 Kg / Metre |
100 X 100 Size (mm) | 6 Thickness (mm) | 17.60 Kg / Metre |
100 X 100 Size (mm) | 6.3 Thickness (mm) | 18.40 Kg / Metre |
100 X 100 Size (mm) | 8 Thickness (mm) | 22.90 Kg / Metre |
100 X 100 Size (mm) | 10 Thickness (mm) | 27.86 Kg / Metre |
100 X 100 Size (mm) | 12 Thickness (mm) | 33.44 Kg / Metre |
120 X 120 Size (mm) | 4 Thickness (mm) | 14.50 Kg / Metre |
120 X 120 Size (mm) | 5 Thickness (mm) | 18.00 Kg / Metre |
120 X 120 Size (mm) | 6 Thickness (mm) | 21.30 Kg / Metre |
120 X 120 Size (mm) | 6.3 Thickness (mm) | 22.30 Kg / Metre |
120 X 120 Size (mm) | 8 Thickness (mm) | 27.90 Kg / Metre |
120 X 120 Size (mm) | 10 Thickness (mm) | 34.13 Kg / Metre |
120 X 120 Size (mm) | 12 Thickness (mm) | 39.94 Kg / Metre |
120 X 120 Size (mm) | 16 Thickness (mm) | 54.64 Kg / Metre |
140 X 140 Size (mm) | 6 Thickness (mm) | 25.97 Kg / Metre |
140 X 140 Size (mm) | 8 Thickness (mm) | 32.89 Kg / Metre |
140 X 140 Size (mm) | 10 Thickness (mm) | 41.15 Kg / Metre |
150 X 150 Size (mm) | 4 Thickness (mm) | 18.30 Kg / Metre |
150 X 150 Size (mm) | 5 Thickness (mm) | 22.70 Kg / Metre |
150 X 150 Size (mm) | 6 Thickness (mm) | 27.00 Kg / Metre |
150 X 150 Size (mm) | 6.3 Thickness (mm) | 28.30 Kg / Metre |
150 X 150 Size (mm) | 8 Thickness (mm) | 35.40 Kg / Metre |
150 X 150 Size (mm) | 10 Thickness (mm) | 43.47 Kg / Metre |
150 X 150 Size (mm) | 12 Thickness (mm) | 53.48 Kg / Metre |
150 X 150 Size (mm) | 16 Thickness (mm) | 65.05 Kg / Metre |
160 X 160 Size (mm) | 6 Thickness (mm) | 27.39 Kg / Metre |
160 X 160 Size (mm) | 8 Thickness (mm) | 36.90 Kg / Metre |
160 X 160 Size (mm) | 10 Thickness (mm) | 46.88 Kg / Metre |
180 X 180 Size (mm) | 5 Thickness (mm) | 27.97 Kg / Metre |
180 X 180 Size (mm) | 6 Thickness (mm) | 33.26 Kg / Metre |
180 X 180 Size (mm) | 8 Thickness (mm) | 43.00 Kg / Metre |
180 X 180 Size (mm) | 10 Thickness (mm) | 53.00 Kg / Metre |
180 X 180 Size (mm) | 12 Thickness (mm) | 61.01 Kg / Metre |
180 X 180 Size (mm) | 12.5 Thickness (mm) | 65.20 Kg / Metre |
180 X 180 Size (mm) | 16 Thickness (mm) | 81.30 Kg / Metre |
200 X 200 Size (mm) | 5 Thickness (mm) | 31.18 Kg / Metre |
200 X 200 Size (mm) | 6 Thickness (mm) | 37.09 Kg / Metre |
200 X 200 Size (mm) | 8 Thickness (mm) | 48.00 Kg / Metre |
200 X 200 Size (mm) | 10 Thickness (mm) | 59.30 Kg / Metre |
200 X 200 Size (mm) | 12 Thickness (mm) | 68.84 Kg / Metre |
200 X 200 Size (mm) | 12.5 Thickness (mm) | 73.00 Kg / Metre |
200 X 200 Size (mm) | 16 Thickness (mm) | 90.91 Kg / Metre |
250 X 250 Size (mm) | 6 Thickness (mm) | 46.83 Kg / Metre |
250 X 250 Size (mm) | 8 Thickness (mm) | 60.50 Kg / Metre |
250 X 250 Size (mm) | 10 Thickness (mm) | 75.00 Kg / Metre |
250 X 250 Size (mm) | 12 Thickness (mm) | 88.45 Kg / Metre |
250 X 250 Size (mm) | 12.5 Thickness (mm) | 92.70 Kg / Metre |
250 X 250 Size (mm) | 16 Thickness (mm) | 111.48 Kg / Metre |
300 X 300 Size (mm) | 6 Thickness (mm) | 55.30 Kg / Metre |
300 X 300 Size (mm) | 8 Thickness (mm) | 74.18 Kg / Metre |
300 X 300 Size (mm) | 10 Thickness (mm) | 90.70 Kg / Metre |
300 X 300 Size (mm) | 12 Thickness (mm) | 108.68 Kg / Metre |
300 X 300 Size (mm) | 12.5 Thickness (mm) | 112.00 Kg / Metre |
300 X 300 Size (mm) | 16 Thickness (mm) | 141.84 Kg / Metre |
350 X 350 Size (mm) | 10 Thickness (mm) | 105.93 Kg / Metre |
350 X 350 Size (mm) | 12 Thickness (mm) | 126.74 Kg / Metre |
350 X 350 Size (mm) | 16 Thickness (mm) | 166.94 Kg / Metre |
400 X 400 Size (mm) | 8 Thickness (mm) | 97.56 Kg / Metre |
400 X 400 Size (mm) | 10 Thickness (mm) | 121.95 Kg / Metre |
400 X 400 Size (mm) | 12 Thickness (mm) | 151.97 Kg / Metre |
400 X 400 Size (mm) | 16 Thickness (mm) | 191.94 Kg / Metr |
Size | kg / m |
12 x 12 x 1.5 mm | 0.59 |
15 x 15 x 1.2 mm | 0.54 |
15 x 15 x 1.5 mm | 0.66 |
20 x 20 x 1.2 mm | 0.73 |
20 x 20 x 1.5 mm | 0.90 |
20 x 20 x 2.0 mm | 0.18 |
25 x 25 x 1.2 mm | 0.93 |
25 x 25 x 1.5 mm | 1.15 |
25 x 25 x 2.0 mm | 1.50 |
25 x 25 x 3.0 mm | 2.22 |
30 x 30 x 1.2 mm | 1.11 |
30 x 30 x 1.5 mm | 1.37 |
30 x 30 x 2.0 mm | 1.84 |
30 x 30 x 3.0 mm | 2.72 |
40 x 40 x 1.2 mm | 1.50 |
40 x 40 x 1.5 mm | 1.86 |
40 x 40 x 2.0 mm | 2.45 |
40 x 40 x 3.0 mm | 3.76 |
Stainless Steel Pipe For Thermocouple SCHEDULE CHART
NB SIZES | SCH 5 | SCH 10 | SCH 40 | SCH 80 | SCH 160 |
---|---|---|---|---|---|
1/8″ |
|||||
1/4″ |
|||||
3/8″ |
|||||
1/2″ |
|||||
3/4″ |
|||||
1″ |
|||||
1 1/4″ |
|||||
1 1/2″ |
|||||
2″ |
|||||
2 1/2″ |
|||||
3″ |
|||||
4″ |
|||||
5″ |
|||||
6″ |
SS SQUARE PIPE NOMINAL BORE SCHEDULE SIZES
Nominal | SS Schedule 5 | SS Schedule 10 | SS Schedule 40 | |||||||
Inch | MM | Wt./MM | Kg./M | Kg./Ft | Wt./MM | Kg./M | Kg./Ft | Wt./MM | Kg./M | Kg./Ft |
1 / 2 | 21 | 1.65 | 0.801 | 0.244 | 2.11 | 0.999 | 0.305 | 2.77 | 1.270 | 0.387 |
3 / 4 | 21.30 | 1.65 | 1.020 | 0.311 | 2.11 | 1.280 | 0.390 | 2.87 | 1.680 | 0.512 |
1 | 26.70 | 1.65 | 1.290 | 0.393 | 2.77 | 2.090 | 0.637 | 3.38 | 2.500 | 0.762 |
1 1 / 4 | 33.40 | 1.65 | 1.650 | 0.503 | 2.77 | 2.690 | 0.820 | 3.56 | 3.380 | 1.030 |
1 1 / 2 | 42.20 | 1.65 | 1.900 | 0.579 | 2.77 | 3.110 | 0.948 | 3.68 | 4.050 | 1.230 |
2 | 48.30 | 1.65 | 3.340 | 0.728 | 2.77 | 3.920 | 1.200 | |||
2 1 / 2 | 73.00 | 2.11 | 3.690 | 1.130 | 3.05 | 5.260 | 1.600 | |||
3 | 88.90 | 2.11 | 4.510 | 1.380 | 3.05 | 6.450 | 1.970 | |||
3 1 / 2 | 101.60 | 2.11 | 5.190 | 1.580 | 3.05 | 7.400 | 2.260 |
Stainless Steel Pipe For Thermocouple PRESSURE RATING
Pressure Rating (psig) | ||||||||||
---|---|---|---|---|---|---|---|---|---|---|
Pipe Size (inches) |
Pipe Schedule | Temperature (oF) | ||||||||
100 | 200 | 300 | 400 | 500 | 600 | 650 | 700 | 750 | ||
1" | 40 | 3048 | 2629 | 2362 | 2171 | 2019 | 1924 | 1867 | 1824 | 1810 |
80 | 4213 | 3634 | 3265 | 3002 | 2791 | 2659 | 2580 | 2528 | 2501 | |
160 | 6140 | 5296 | 4759 | 4375 | 4068 | 3876 | 3761 | 3684 | 3646 | |
1 1/2" | 40 | 2257 | 1947 | 1750 | 1608 | 1496 | 1425 | 1383 | 1354 | 1340 |
80 | 3182 | 2744 | 2466 | 2267 | 2108 | 2009 | 1949 | 1909 | 1889 | |
160 | 4619 | 3984 | 3580 | 3291 | 3060 | 2916 | 2829 | 2772 | 2743 | |
2" | 40 | 1902 | 1640 | 1474 | 1355 | 1260 | 1201 | 1165 | 1141 | 1129 |
80 | 2747 | 2369 | 2129 | 1957 | 1820 | 1734 | 1682 | 1648 | 1631 | |
160 | 4499 | 3880 | 3486 | 3205 | 2980 | 2840 | 2755 | 2699 | 2671 | |
3" | 40 | 1806 | 1558 | 1400 | 1287 | 1196 | 1140 | 1106 | 1084 | 1072 |
80 | 2553 | 2202 | 1979 | 1819 | 1691 | 1612 | 1564 | 1532 | 1516 | |
160 | 3840 | 3312 | 2976 | 2736 | 2544 | 2424 | 2352 | 2304 | 2280 | |
4" | 40 | 1531 | 1321 | 1187 | 1091 | 1014 | 967 | 938 | 919 | 909 |
80 | 2213 | 1909 | 1715 | 1577 | 1466 | 1397 | 1355 | 1328 | 1314 | |
160 | 3601 | 3106 | 2791 | 2566 | 2386 | 2273 | 2206 | 2161 | 2138 | |
5" | 40 | 1342 | 1158 | 1040 | 956 | 889 | 847 | 822 | 805 | 797 |
80 | 1981 | 1709 | 1535 | 1411 | 1312 | 1250 | 1213 | 1189 | 1176 | |
160 | 3414 | 2945 | 2646 | 2433 | 2262 | 2155 | 2091 | 2049 | 2027 | |
6" | 40 | 1219 | 1052 | 945 | 869 | 808 | 770 | 747 | 732 | 724 |
80 | 1913 | 1650 | 1483 | 1363 | 1267 | 1208 | 1172 | 1148 | 1136 | |
160 | 3289 | 2836 | 2549 | 2343 | 2179 | 2076 | 2014 | 1973 | 1953 | |
8" | 40 | 1073 | 926 | 832 | 765 | 711 | 678 | 657 | 644 | 637 |
80 | 1692 | 1459 | 1311 | 1205 | 1121 | 1068 | 1036 | 1015 | 1005 | |
160 | 3175 | 2738 | 2460 | 2262 | 2103 | 2004 | 1944 | 1905 | 1885 | |
10" | 40 | 974 | 840 | 755 | 694 | 645 | 615 | 596 | 584 | 578 |
80 | 1609 | 1388 | 1247 | 1147 | 1066 | 1016 | 986 | 966 | 956 | |
160 | 3147 | 2714 | 2439 | 2242 | 2085 | 1986 | 1927 | 1880 | 1868 |
STAINLESS STEEL PIPE TOLERANCES
NPS Designator | Permissible Variations in Outside Diameter | |
---|---|---|
Over In. | Under In. | |
1/8 to 1-1/2, incl | 1/64 (0.015) | 1/32 (0.031) |
Over 1-1/2 to 4, incl | 1/32 (0.031) | 1/32 (0.031) |
Over 4 to 8, incl | 1/16 (0.062) | 1/32 (0.031) |
Over 8 to 18, incl | 3/23 (0.093) | 1/32 (0.031) |
Nominal Wall Thickness:
NPS Designator | Outside Diameter in. | Schedule 10S in. | Schedule 40S in. | Schedule 80S in. | Schedule 160 in. | Schedule XX in. |
---|---|---|---|---|---|---|
1/4 | 0.540 | 0.065 | 0.088 | 0.119 | ||
3/8 | 0.675 | 0.065 | 0.091 | 0.126 | ||
1/2 | 0.840 | 0.083 | 0.109 | 0.147 | .188 | .294 |
3/4 | 1.050 | 0.083 | 0.113 | 0.154 | .218 | .308 |
1.0 | 1.315 | 0.109 | 0.133 | 0.179 | .250 | .358 |
1 1/4 | 1.660 | 0.109 | 0.140 | 0.191 | .250 | .382 |
1 1/2 | 1.900 | 0.109 | 0.145 | 0.200 | .281 | .400 |
2 | 2.375 | 0.109 | 0.154 | 0.218 | .343 | .436 |
2 1/2 | 2.875 | 0.120 | 0.203 | 0.276 | .375 | .552 |
3 | 3.500 | 0.120 | 0.216 | 0.300 | .438 | .600 |
3 1/2 | 4.000 | 0.120 | 0.226 | 0.318 | .636 | |
4 | 4.500 | 0.120 | 0.237 | 0.337 | .534 | .674 |
5 | 5.563 | 0.134 | 0.258 | 0.375 | .625 | .750 |
6 | 6.625 | 0.134 | 0.280 | 0.432 | .719 | .864 |
8 | 8.625 | 0.148 | 0.322 | 0.500 | .906 | .875 |
10 | 10.750 | 0.165 | 0.365 | 0.500 | 1.125 | |
12 | 12.750 | 0.180 | 0.375 | 0.500 | 1.312 | |
14 | 14.000 | 0.188 | 0.375 | 0.500 | 1.406 | |
16 | 16.000 | 0.188 | 0.375 | 0.500 | 1.594 |
TERMOCOUPLE PARTS PROTECTION TUBE OR SLEEVE PIPE FOR THERMOCOUPLE HIGH TEMPERATURE TUBING
- tn * 0.875 = tm Where: tn = nominal wall thickness, in. [mm], and tm= minimum wall thicknesses, in. [mm]
- The wall thickness is inch-pound units is rounded to three decimal places in accordance with the rounding method of Practice E29. The wall thickness in SI units is rounded to one decimal place in accordance with the rounding method of Practice E29.
Product Name | thermocouple protection tube |
Material | Carbon Steel, Alloy Steel, Stainless Steel |
Description | 1. Protection tube are used for Thermocouple/Spring -type Thermocouple. Diameter 6mm, diameter 8mm and different length, and so on. |
Grade | 2, 4, 4.8, 5, 6, 6.8, 8, 8.8,10.9,12.9,14.9 |
Finsh | Zinc plate (white,blue,yellow,black), Zn/Ni plating, Mechanical zinc plating, Cr3+, black oxide, Ni plate, brass plate, electrophoresis, dacromet, hot-dipped galvanized, positive electrode oxidization, etc. |
AVAILABLE STOCK OF SS SQUARE PIPE
Stainless Steel Seamless Square Pipe Supplier & Manufacturer in India | SS Seamless Square Pipe Supplier |
Seamless SS Square Pipe Supplier & Manufacturer in India | SS ERW Square Pipe Supplier & Manufacturer in India |
Stainless Steel Pipe For Thermocouple Suppliers & Manufacturer in India | Stainless Steel Pipe For Thermocouple Exporter |
304 Stainless Steel Pipe For Thermocouple Suppliers & Manufacturer in India | 316L Stainless Steel Pipe For Thermocouple |
SS Square Pipe ERW Sections Supplier & Manufacturer in India | ASTM A312 TP304 SS Square Pipe Supplier & Manufacturer in India |
SS Bright Annealed Square Pipe | ASTM A312 TP304LStainless Steel Supplier & Manufacturer in India |
Stainless Steel 201 Square Pipes Supplier & Manufacturer in India | Stainless Steel Square 316 Pipe Supplier |
Large Diameter Stainless Steel Pipe For Thermocouple | ASTM A312 TP304/304L SS Square Pipe Supplier & Manufacturer in India |
SS Square Pipe Supplier & Manufacturer in India | ASTM A312 TP316 Stainless Steel Supplier & Manufacturer in India |
Hot Rolled Stainless Steel Pipe For Thermocouple Suppliers & Manufacturer in India | ASTM A312 TP316L Stainless SS & Manufacturer in India |
1/2″ NB in Thickness Schedule Stainless Steel Pipe For Thermocouple | ASTM A312 TP201 Stainless Steel Pipe For Thermocouple |
4″ NB in Thickness Schedule SS Square Pipe Supplier & Manufacturer in India | ASTM A312 TP316/316L Stainless Steel Pipe For Thermocouple Suppliers |
5″ NB in Thickness Schedule SS Square Pipe Supplier & Manufacturer in India | Schedule 40 SS Square Pipe Supplier & Manufacturer in India |
6″ NB in Thickness Schedule Stainless Steel Pipe For Thermocouple Suppliers & Manufacturer in India | Schedule 80 Stainless Steel Pipe For Thermocouple Suppliers & Manufacturer in India |
7″ NB in Thickness Schedule SS Square Pipe Supplier & Manufacturer in India | Schedule 10 SS Square Pipe Supplier |
8″ NB in Thickness Schedule Stainless Steel Pipe For Thermocouple Suppliers & Manufacturer in India | Sch 5 Stainless Steel Pipe For Thermocouple Suppliers |
14″ NB in Thickness Schedule SS Square Pipe Supplier | Stainless Steel Pipe For Thermocouple Weight per meter |
16″ NB in Thickness Schedule Stainless Steel Pipe For Thermocouple Supplier & Manufacturer in India | Weight of Stainless Steel Pipe For Thermocouple |
18″ NB in Thickness Schedule SS Square Pipe Supplier | Stainless Steel Pipe For Thermocouple Price in India |
PACKAGING AND LABELING
To ensure the safe transportation of our products, we take meticulous care in packaging them. In the case of exports, we employ standard wooden cases for packaging. Each pipe is marked with essential information, including Grade, Lot No, Size, Degree, and our trademark. Furthermore, we can provide custom markings on our products upon special requests.
QUALITY ASSURANCE
Our Products maintains stringent quality control measures for all fittings and bars throughout every production stage, from the procurement of raw materials to the dispatch of the final products. Visual inspections ensure compliance with industry-standard codes and regulations such as ASTM, ASME, MSS, DIN, EN, and JIS. Should the need arise, we can arrange for official certified Inspection Agencies to witness material reports, dimensions, and product quality conformity.
TEST CERTIFICATES
Our products come with a Manufacturer Test Certificate per EN 10204 / 3.1B and a Raw Materials Certificate. In addition, they undergo a 100% Radiography Test, and Third Party Inspection Reports can also be provided.
SHIPPING POLICY
The delivery time and dates are determined based on the type and quantity of steel ordered. Our sales team will provide a delivery schedule when you request a quotation. Please note that the delivery schedule may occasionally be subject to change, so we recommend checking with our sales department when placing your orders. Orders are typically dispatched within 2-3 business days and may take 5-10 business days to reach their destination. If Forgings are out of stock, orders may require 2-4 weeks for shipping. Our Products will promptly notify the buyer if such a situation occurs.
Stainless Steel Square Rod
Stainless Steel Rods
Stainless Steel Rods
Stainless Steel Pipe For Thermocouples
Industry We Serve
Cities We Deliver To
Istanbul, Coimbatore, Jamshedpur, Haryana, Dammam, Ankara, Hyderabad, Sharjah, Kuala Lumpur, Mumbai, Surat, Ranchi, Pune, Bangkok, Busan, Kuwait City, Singapore, Indore, Vadodara, Madrid, Al Jubail, Dallas, Faridabad, Secunderabad, Toronto, Petaling Jaya, Brisbane, Jaipur, Thiruvananthapuram, Colombo, Atyrau, Algiers, Los Angeles, Houston, Visakhapatnam, Tehran, Thane, Doha, Hanoi, Edmonton, Karachi, Cairo, Gurgaon, Jakarta, Ahmedabad, Geoje-si, Ho Chi Minh City, Chiyoda, Kanpur, Riyadh, Rajkot, Bhopal, La Victoria, Milan, Muscat, Chennai, Bogota, Gimhae-si, New York, Ernakulam, Granada, Santiago, Ludhiana, Dubai, Kolkata, Caracas, Howrah, Jeddah, Lahore, Courbevoie, Perth, Pimpri-Chinchwad, Aberdeen, Manama, Nagpur, Ahvaz, Montreal, Seoul, Bengaluru, Sydney, Al Khobar, Lagos, Calgary, Vung Tau, New Delhi, Nashik, Ulsan, Noida, Mexico City, Hong Kong, Rio de Janeiro, Abu Dhabi, Melbourne, Chandigarh, Baroda, Port-of-Spain, London, Navi Mumbai, Moscow.
Countries We Deliver To
Peru, Kazakhstan, Bolivia, Bhutan, Poland, Nigeria, China, Bangladesh, Norway, Estonia, Costa Rica, Taiwan, Sri Lanka, Qatar, Iran, Canada, Zimbabwe, Malaysia, Morocco, Denmark, Poland, Thailand, Egypt, Iran, Gabon, Lithuania, Netherlands, Belgium, Bulgaria, Bahrain, Mexico, Japan, Turkey, Portugal, Venezuela, South Korea, Ecuador, United Arab Emirates, Namibia, Hong Kong, Ghana, Slovakia, Germany, Austria, Vietnam, Gambia, Mongolia, Ireland, Italy, Romania, United States, Kuwait, Spain, Indonesia, Greece, France, Chile, Czech Republic, Nigeria, Israel, Tunisia, Libya, Ukraine, Nepal, Jordan, Brazil, Serbia, Afghanistan, South Africa, Lebanon, Chile, Angola, Philippines, Hungary, Mexico, Yemen, United Kingdom, Sweden, Tibet, Macau, Kenya, Puerto Rico, New Zealand, Singapore, Algeria, Azerbaijan, Oman, Pakistan, India, Saudi Arabia, Russia, Iraq, Australia, Finland, Colombia, Argentina, Croatia, Belarus, Switzerland, Trinidad & Tobago.
Other Available Products of Aluminium Rods
» Stainless Steel Round Pipe
» Stainless Steel Rectangular Pipe
» Stainless Steel Pipe For Thermocouple
» Stainless Steel Perforated Pipe
» Stainless Steel 304 Pipe
» Stainless Steel 304L Pipe
» Stainless Steel Pipe For Thermocouple
» Stainless Steel 316 Pipe
» Stainless Steel 316L Pipe
» Stainless Steel Pipe For Thermocouple
» Stainless Steel Pipe For Thermocouple
People also search for Stainless Steel Products
Stainless Steel Tube price per kg, Stainless Steel Pipe For Thermocouple manufacturers in india, Stainless Steel Pipe For Thermocouple, Stainless Steel Pipe For Thermocouple.
