Stainless Steel Small Diameter Tubes
Stainless Steel Small Diameter Tubes MANUFACTURER IN INDIA, Stainless Steel Small Diameter Tubes 304, STAINLESS STEEL COILED TUBING SUPPLIERS
we manufacture Stainless Steel Small Diameter Tube using stainless steel, titanium, nickel and zirconium alloys, in a whole range of sizes & cross section shapes to suit your requirements. Stainless steel Small diameter tubing is available in pre-cut lengths from stock or can be custom lengths as per customer’s needs. All ultra small SS coil tubing is passivated post-manufacturing process.
.010" STAINLESS STEEL TUBING STOCKIST AND HYPODERMIC STAINLESS STEEL TUBING AND 23 GAUGE TUBING SUPPLIER IN MUMBAI AND CHENNAI DISTRIBUTOR OF THIN WALL SS PIPE AND STAINLESS STEEL SMALL BORE TUBE ALSO CHECK 2 INCH SQUARE TUBING PRICE PER FOOT
Stainless Steel Small Diameter Tubes
Siddhgiri Tubes offering Stainless Steel Small Diameter Tubes in customized designs. SS 304 Square Pipes are used for pressure operations such as moving liquids and gases in processing operations in the water treatment, chemical, petrochemical, food processing, dairy and marine industries. Welded tube is used as handrails, legs for office, kitchen, and hospital equipment and as architectural supports. Siddhgiri Exports is specialized as providing Stainless Steel Small Diameter Tubes in Polished Grit 120 - 600 finish. SS Square pipe dimensions are nominated by outside diameter indicated by the NPS (imperial) or DN (metric) designator and sometimes referred to as the 'nominal bore' - and wall thickness is determined by the schedule number.
Stainless Steel Small Diameter Tubes SPECIFICATION
Type
|
Seamless and Welded Austenitic and Ferritic/Austenitic Stainless Steel Sanitary Tubing
|
ASTM | ASTM A270 / ASME SA 270 |
OD. | 1/2” |
Wall | 16 Gauge (0.065”) |
Length | 20′ |
OD Tolerance | +/-0.005” / +/-0.13MM |
WT Tolerance | +/-10% |
Length Tolerance | +1/8” / +3.18MM |
Material | SS 304, SS 304L,SS 316,SS 316L |
Standard | 3A / ASTM A270 / A270M |
Finish | 20Ra ID / 32Ra OD |
Polish | Mechanical Polished |
Type | Seamless |
Certification | 3A – Food / Dairy Grade |
Mill Test Certificate | EN10204 3.1 |
Packing | Sleeved, Ends Capped, Wooden Boxed |
Stainless Steel Small Diameter Tubes SIZES
Both are welded and seamless products come both as straight lengths tubing as well as in coils form. Our cut miniature stainless steel tubing range is size is available from 0.010” (1/4 mm) right up to 1.25” (31.75mm) outside diameter, and we can produce finished wall thicknesses down to less than 0.002” (0.05 mm) to 0.150” (3.8mm). You can also order straight lengths of tubing at VMC up to 45ft (14m) long or coiled tubes up to 3,200ft (975m) in length.
- • Machinery
- • Automative
- • Transport
- • construction
- • Home and commercial fixtures
Stainless Steel Small Diameter Tubes (WELDED 304/L OR 316/L)
Outside Diameter (OD) | Wall Thickness |
1/8” – 3/4” | 0.5mm – 4mm |
Stainless Steel Small Diameter Tubes(SEAMLESS 316/L)
Outside Diameter (OD) | Wall Thickness | |
1/16” – 3/4” | 0.5mm – 4mm |
As the largest stockholder of Stainless Steel Small Diameter Tubes, we have huge inventory of Stainless Steel 316 Coil Tube, Stainless steel 316L Coil Tube, Stainless Steel 304 Coil Tube, Stainless Steel 304L Coil Tube, and stainless Steel 201 Coil Tube.
Stainless Steel Seamless Coil Tubing, SS Coil Tube sizes in india, SS Coil Tube Dealer in India, High Quality Stainless Steel Small Diameter Tubes, Stainless Steel Small Diameter Tubes Exporter in India,Coil Stainless Steel Tubing Exporter, Seamless Stainless Steel Small Diameter Tubess. SUPPLIERS OF Stainless Steel Small Diameter Tubes,1′STAINLESS STEEL COIL TUBING,STAINLESS STEEL TUBING COIL 1/2,STAINLESS STEEL TUBING COIL 3/4,STAINLESS STEEL TUBING COIL 1/4, 3/8 STAINLESS STEEL TUBING COIL, 304 COIL STEEL TUBE, Stainless Steel Small Diameter Tubes EXPORTER, SS 304 COIL TUBE SIZE CHART, SS 316 COIL TUBE SUPPLIER IN MUMBAI, INDIA.
SS COIL TUBE SIZES
SIZES, WEIGHT CHART
Stainless Steel Small Diameter Tubess are finished in accordance with customer needs regarding dimensional and wall thickness specifications as well as heat treatment for more demanding applications. In general a Stainless Steel Small Diameter Tubes is manufactured according to current standards API, ASTM, and ASME. If required for special projects we can also supply large diameter Coil Tubes.
Tube OD
|
Thikness
|
Grade
|
1/2
|
0.065
|
304
|
1/2
|
0.065
|
316
|
3/4
|
0.065
|
304
|
3/4
|
0.065
|
316
|
1
|
0.065
|
304
|
1
|
0.065
|
316
|
1 1/2
|
0.065
|
304
|
1 1/2
|
0.065
|
316
|
2
|
0.065
|
304
|
2
|
0.065
|
316
|
2 1/2
|
0.065
|
304
|
2 1/2
|
0.065
|
316
|
3
|
0.065
|
304
|
3
|
0.065
|
316
|
4
|
0.083
|
304
|
4
|
0.083
|
316
|
6
|
0.109
|
304
|
6
|
0.109
|
316
|
8
|
0.109
|
304
|
8
|
0.109
|
316
|
STAINLESS STEEL WELDED 304
OD | Wall | ID |
1/8” | .020 | .085 |
(.1250”) | .035 | .055 |
1/4” | .035 | .180 |
(.2500”) | ||
5/16” | .035 | .243 |
(.3125”) | ||
3/8” | .035 | .305 |
(.3750”) | ||
1/2” | .035 | .430 |
(.5000”) | .049 | .402 |
3/4” | .049 | .652 |
(.7500”) |
Stainless Steel Small Diameter Tubes PRESSURE RATING
Pressure Rating (psig) | ||||||||||
---|---|---|---|---|---|---|---|---|---|---|
Pipe Size (inches) |
Pipe Schedule | Temperature (oF) | ||||||||
100 | 200 | 300 | 400 | 500 | 600 | 650 | 700 | 750 | ||
1" | 40 | 3048 | 2629 | 2362 | 2171 | 2019 | 1924 | 1867 | 1824 | 1810 |
80 | 4213 | 3634 | 3265 | 3002 | 2791 | 2659 | 2580 | 2528 | 2501 | |
160 | 6140 | 5296 | 4759 | 4375 | 4068 | 3876 | 3761 | 3684 | 3646 | |
1 1/2" | 40 | 2257 | 1947 | 1750 | 1608 | 1496 | 1425 | 1383 | 1354 | 1340 |
80 | 3182 | 2744 | 2466 | 2267 | 2108 | 2009 | 1949 | 1909 | 1889 | |
160 | 4619 | 3984 | 3580 | 3291 | 3060 | 2916 | 2829 | 2772 | 2743 | |
2" | 40 | 1902 | 1640 | 1474 | 1355 | 1260 | 1201 | 1165 | 1141 | 1129 |
80 | 2747 | 2369 | 2129 | 1957 | 1820 | 1734 | 1682 | 1648 | 1631 | |
160 | 4499 | 3880 | 3486 | 3205 | 2980 | 2840 | 2755 | 2699 | 2671 | |
3" | 40 | 1806 | 1558 | 1400 | 1287 | 1196 | 1140 | 1106 | 1084 | 1072 |
80 | 2553 | 2202 | 1979 | 1819 | 1691 | 1612 | 1564 | 1532 | 1516 | |
160 | 3840 | 3312 | 2976 | 2736 | 2544 | 2424 | 2352 | 2304 | 2280 | |
4" | 40 | 1531 | 1321 | 1187 | 1091 | 1014 | 967 | 938 | 919 | 909 |
80 | 2213 | 1909 | 1715 | 1577 | 1466 | 1397 | 1355 | 1328 | 1314 | |
160 | 3601 | 3106 | 2791 | 2566 | 2386 | 2273 | 2206 | 2161 | 2138 | |
5" | 40 | 1342 | 1158 | 1040 | 956 | 889 | 847 | 822 | 805 | 797 |
80 | 1981 | 1709 | 1535 | 1411 | 1312 | 1250 | 1213 | 1189 | 1176 | |
160 | 3414 | 2945 | 2646 | 2433 | 2262 | 2155 | 2091 | 2049 | 2027 | |
6" | 40 | 1219 | 1052 | 945 | 869 | 808 | 770 | 747 | 732 | 724 |
80 | 1913 | 1650 | 1483 | 1363 | 1267 | 1208 | 1172 | 1148 | 1136 | |
160 | 3289 | 2836 | 2549 | 2343 | 2179 | 2076 | 2014 | 1973 | 1953 | |
8" | 40 | 1073 | 926 | 832 | 765 | 711 | 678 | 657 | 644 | 637 |
80 | 1692 | 1459 | 1311 | 1205 | 1121 | 1068 | 1036 | 1015 | 1005 | |
160 | 3175 | 2738 | 2460 | 2262 | 2103 | 2004 | 1944 | 1905 | 1885 | |
10" | 40 | 974 | 840 | 755 | 694 | 645 | 615 | 596 | 584 | 578 |
80 | 1609 | 1388 | 1247 | 1147 | 1066 | 1016 | 986 | 966 | 956 | |
160 | 3147 | 2714 | 2439 | 2242 | 2085 | 1986 | 1927 | 1880 | 1868 |
STAINLESS STEEL SEAMLESS 316 / L COILED TUBE SIZES
OD | Wall | ID |
1/16” | .010 | .043 |
(.0625”) | .020 | .023 |
1/8” | .035 | .055 |
(.1250”) | ||
1/4” | .035 | .180 |
(.2500”) | .049 | .152 |
.065 | .120 | |
3/8” | .035 | .305 |
(.3750”) | .049 | .277 |
.065 | .245 | |
1/2” | .035 | .430 |
(.5000”) | .049 | .402 |
.065 | .370 | |
5/8” | .035 | .555 |
(.6250”) | .049 | .527 |
3/4” | .035 | .680 |
(.7500”) | .049 | .652 |
.065 | .620 | |
.083 | .584 | |
.109 | .532 |
STAINLESS STEEL WELDED 316 / L COILED TUBE SIZES
OD | Wall | ID |
1/8” | .020 | .085 |
(.1250”) | .028 | .069 |
.035 | .055 | |
1/4” | .020 | .210 |
(.2500”) | .028 | .194 |
.035 | .180 | |
.049 | .152 | |
3/8” | .035 | .305 |
1/2” | .035 | .430 |
(.5000”) | .049 | .402 |
5/8” | .049 | .527 |
(.6250”) | ||
3/4” | .035 | .680 |
(.7500”) | .049 | .652 |
.065 | .620 | |
.083 | .584 |
Stainless Steel Small Diameter Tubes SCHEDULE CHART
NB SIZES | SCH 5 | SCH 10 | SCH 40 | SCH 80 | SCH 160 |
---|---|---|---|---|---|
1/8″ |
|||||
1/4″ |
|||||
3/8″ |
|||||
1/2″ |
|||||
3/4″ |
|||||
1″ |
|||||
1 1/4″ |
|||||
1 1/2″ |
|||||
2″ |
|||||
2 1/2″ |
|||||
3″ |
|||||
4″ |
|||||
5″ |
|||||
6″ |
Stainless Steel Small Diameter Tubes WALL THICKNESS AND COIL TUBE SCHEDULE
GAUGE | THICKNESS RANGE(INCHES) | TYPICAL VALUE (INCHES) |
---|---|---|
22 | 0.025 through 0.029 | 0.028 |
20 | 0.031 through 0.035 | 0.035 |
19 | 0.038 through 0.042 | 0.042 |
18 | 0.044 through 0.049 | 0.049 |
17 | 0.053 through 0.058 | 0.058 |
16 | 0.060 through 0.065 | 0.065 |
15 | 0.066 through 0.074 | 0.072 |
14 | 0.075 through 0.085 | 0.083 |
13 | 0.087 through 0.097 | 0.095 |
12 | 0.101 through 0.111 | 0.109 |
11 | 0.112 through 0.122 | 0.12 |
10 | 0.126 through 0.136 | 0.134 |
9 | 0.140 through 0.150 | 0.148 |
8 | 0.157 through 0.167 | 0.165 |
7 | 0.175 through 0.185 | 0.18 |
Stainless Steel Small Diameter Tubes PRESSURE RATING
AVE. WALL INCHES | MIN YIELD STRENGTH (PSI) | MIN TENSILE STRENGTH (PSI) | THEORETICAL BURST PRESSURE * (PSI) | WORKING PRESSURE (PSI) 25% OF BURST | THEORETICAL YIELD POINT ** (PSI) | COLLAPSE PRESSURE *** (PSI) | |
---|---|---|---|---|---|---|---|
0.250 | 0.020 | 30,000 | 75,000 | 14,286 | 3,571 | 5,714 | 4,416 |
0.250 | 0.028 | 30,000 | 75,000 | 21,649 | 5,412 | 8,660 | 5,967 |
0.250 | 0.035 | 30,000 | 75,000 | 29,167 | 7,292 | 11,667 | 7,224 |
0.250 | 0.049 | 30,000 | 75,000 | 48,355 | 12,089 | 19,342 | 9,455 |
0.250 | 0.065 | 30,000 | 75,000 | 81,250 | 20,313 | 32,500 | 11,544 |
0.375 | 0.020 | 30,000 | 75,000 | 8,955 | 2,239 | 3,582 | 3,029 |
0.375 | 0.028 | 30,000 | 75,000 | 13,166 | 3,292 | 5,266 | 4,145 |
0.375 | 0.035 | 30,000 | 75,000 | 17,213 | 4,303 | 6,885 | 5,077 |
0.375 | 0.049 | 30,000 | 75,000 | 26,534 | 6,634 | 10,614 | 6,816 |
0.375 | 0.065 | 30,000 | 75,000 | 39,796 | 9,949 | 15,918 | 8,597 |
0.500 | 0.020 | 30,000 | 75,000 | 6,522 | 1,630 | 2,609 | 2,304 |
0.500 | 0.028 | 30,000 | 75,000 | 9,459 | 2,365 | 3,784 | 3,172 |
0.500 | 0.035 | 30,000 | 75,000 | 12,209 | 3,052 | 4,884 | 3,906 |
0.500 | 0.049 | 30,000 | 75,000 | 18,284 | 4,571 | 7,313 | 5,304 |
0.500 | 0.065 | 30,000 | 75,000 | 26,351 | 6,588 | 10,541 | 6,786 |
0.500 | 0.083 | 30,000 | 75,000 | 37,275 | 9,319 | 14,910 | 8,307 |
0.625 | 0.020 | 30,000 | 75,000 | 5,128 | 1,282 | 2,051 | 1,859 |
0.625 | 0.028 | 30,000 | 75,000 | 7,381 | 1,845 | 2,953 | 2,568 |
0.625 | 0.035 | 30,000 | 75,000 | 9,459 | 2,365 | 3,784 | 3,172 |
0.625 | 0.049 | 30,000 | 75,000 | 13,947 | 3,487 | 5,579 | 4,335 |
0.625 | 0.065 | 30,000 | 75,000 | 19,697 | 4,924 | 7,879 | 5,591 |
0.625 | 0.083 | 30,000 | 75,000 | 27,124 | 6,781 | 10,850 | 6,910 |
0.625 | 0.095 | 30,000 | 75,000 | 32,759 | 8,190 | 13,103 | 7,734 |
0.625 | 0.109 | 30,000 | 75,000 | 40,172 | 10,043 | 16,069 | 8,639 |
0.750 | 0.028 | 30,000 | 75,000 | 6,052 | 1,513 | 2,421 | 2,156 |
0.750 | 0.035 | 30,000 | 75,000 | 7,721 | 1,930 | 3,088 | 2,669 |
0.750 | 0.049 | 30,000 | 75,000 | 11,273 | 2,818 | 4,509 | 3,664 |
0.750 | 0.065 | 30,000 | 75,000 | 15,726 | 3,931 | 6,290 | 4,749 |
0.750 | 0.083 | 30,000 | 75,000 | 21,318 | 5,330 | 8,527 | 5,905 |
0.750 | 0.095 | 30,000 | 75,000 | 25,446 | 6,362 | 10,179 | 6,637 |
0.750 | 0.109 | 30,000 | 75,000 | 30,733 | 7,683 | 12,293 | 7,453 |
0.750 | 0.120 | 30,000 | 75,000 | 35,294 | 8,824 | 14,118 | 8,064 |
0.875 | 0.020 | 30,000 | 75,000 | 3,593 | 898 | 1,437 | 1,340 |
0.875 | 0.028 | 30,000 | 75,000 | 5,128 | 1,282 | 2,051 | 1,859 |
0.875 | 0.035 | 30,000 | 75,000 | 6,522 | 1,630 | 2,609 | 2,304 |
0.049 | 30,000 | 75,000 | 9,459 | 2,365 | 3,784 | 3,172 | |
0.875 | 0.065 | 30,000 | 75,000 | 13,087 | 3,272 | 5,235 | 4,126 |
0.875 | 0.083 | 30,000 | 75,000 | 17,560 | 4,390 | 7,024 | 5,152 |
0.875 | 0.095 | 30,000 | 75,000 | 20,803 | 5,201 | 8,321 | 5,807 |
0.875 | 0.109 | 30,000 | 75,000 | 24,886 | 6,221 | 9,954 | 6,543 |
0.875 | 0.120 | 30,000 | 75,000 | 28,346 | 7,087 | 11,339 | 7,100 |
1.000 | 0.028 | 30,000 | 75,000 | 4,449 | 1,112 | 1,780 | 1,633 |
1.000 | 0.035 | 30,000 | 75,000 | 5,645 | 1,411 | 2,258 | 2,027 |
1.000 | 0.049 | 30,000 | 75,000 | 8,149 | 2,037 | 3,259 | 2,796 |
1.000 | 0.065 | 30,000 | 75,000 | 11,207 | 2,802 | 4,483 | 3,647 |
1.000 | 0.083 | 30,000 | 75,000 | 14,928 | 3,732 | 5,971 | 4,567 |
1.000 | 0.095 | 30,000 | 75,000 | 17,593 | 4,398 | 7,037 | 5,159 |
1.000 | 0.109 | 30,000 | 75,000 | 20,908 | 5,227 | 8,363 | 5,827 |
1.000 | 0.120 | 30,000 | 75,000 | 23,684 | 5,921 | 9,474 | 6,336 |
1.000 | 0.134 | 30,000 | 75,000 | 27,459 | 6,865 | 10,984 | 6,963 |
1.250 | 0.035 | 30,000 | 75,000 | 4,449 | 1,112 | 1,780 | 1,633 |
1.250 | 0.049 | 30,000 | 75,000 | 6,380 | 1,595 | 2,552 | 2,260 |
PACKAGING AND LABELING
To ensure the safe transportation of our products, we take meticulous care in packaging them. In the case of exports, we employ standard wooden cases for packaging. Each pipe is marked with essential information, including Grade, Lot No, Size, Degree, and our trademark. Furthermore, we can provide custom markings on our products upon special requests.
QUALITY ASSURANCE
Our Products maintains stringent quality control measures for all fittings and bars throughout every production stage, from the procurement of raw materials to the dispatch of the final products. Visual inspections ensure compliance with industry-standard codes and regulations such as ASTM, ASME, MSS, DIN, EN, and JIS. Should the need arise, we can arrange for official certified Inspection Agencies to witness material reports, dimensions, and product quality conformity.
TEST CERTIFICATES
Our products come with a Manufacturer Test Certificate per EN 10204 / 3.1B and a Raw Materials Certificate. In addition, they undergo a 100% Radiography Test, and Third Party Inspection Reports can also be provided.
SHIPPING POLICY
The delivery time and dates are determined based on the type and quantity of steel ordered. Our sales team will provide a delivery schedule when you request a quotation. Please note that the delivery schedule may occasionally be subject to change, so we recommend checking with our sales department when placing your orders. Orders are typically dispatched within 2-3 business days and may take 5-10 business days to reach their destination. If Forgings are out of stock, orders may require 2-4 weeks for shipping. Our Products will promptly notify the buyer if such a situation occurs.
