Stainless Steel Tube Manufacturers in USA

SEAMLESS STAINLESS STEEL TUBE SUPPLIER, STAINLESS STEEL WELDED TUBE, SS TUBE EXPORTER, SS SEAMLESS TUBE DEALER, STAINLESS STEEL TUBE DISTRIBUTOR,STAINLESS STEEL TUBE SIZES

Leading in Stainless Steel Tube Suppliers. Our stock of 304 Stainless Steel Tube is manufactured with precision utilizing high-quality steel and contemporary technology under the supervision of skilled professionals. Stainless steel 202 tube primarily consist of the austenitic grades of stainless steel including TP316, TP316L, TP304, TP304L, and TP201 in annealed and bright annealed, pickled, mill finish and conditions. Our offered Stainless Steel Tube have excellent features like durable in nature, everlasting finish and easy to install. We are One of the fastest growing Stainless Steel Tube Manufacturer in USA. Buy stainless steel tube at best price in USA from us as compared to the market price.

Stainless Steel Tube SPECIFICATION

Siddhgiri Tubes offering Stainless Steel Tube in customized designs. SS 304 Tube are used for pressure operations such as moving liquids and gases in processing operations in the water treatment, chemical, petrochemical, food processing, dairy and marine industries. Welded tube is used as handrails, legs for office, kitchen, and hospital equipment and as architectural supports. Siddhgiri Tubes is specialized as providing Stainless Steel Tube in Polished Grit 120 - 600 finish. Stainless steel round tube dimensions are nominated by outside diameter indicated by the NPS (imperial) or DN (metric) designator and sometimes referred to as the 'nominal bore' - and wall thickness is determined by the schedule number.

Specification

STAINLESS STEEL TUBE SPECIFICATION
Specification
ASTM A213, ASTM A249, ASTM A268, ASTM A269, ASTM A270 & Its equivalent ASME, DIN & EN Standard.
Grades
304, 304L, 304H, 304LN, 309S, 310S, 316, 316L, 316H, 316Ti, 317, 317L, 321, 321H, 347, 347H, 410,420-2205,2507,904L
Type
Seamless / Welded
Diameter Size
1/4” OD, NB to 3” OD, NB sizes
Thickness
0.1mm to 12mm, SCH 5/5S, 10/10S, 20/20S, 40/40S, 80/80S, 120/120S, 160/160S as per ANSI B36.19/36.10
Length
Up to 12 meters, custom cut lengths
Ends
No.1 Pickled Finish, No.4 finish, BA Finish, Electropolished Seamless Tube
Delivery Conditions
As Rolled, Formed, Stress Relieved, Annealed, Hardened, Tempered, Cold Draw
Coating
Electropolish, Mechanical Polish, Satin Finish, Passivated
Testing
Product Analysis, Transverse Tension Test, Flattening Test, Etching Test, Radiographic Examination, Stabilizing Heat Treatment, Intergranular Corrosion Test, Weld Decay Test, Magnetic Particle Detection, Grain Size Test, NACE 0175, Dual Grade, PWHT (POST WELD HEAT TREATMENT), Flare Test, Bend Test, Hardness Test, Tensile Test etc
Dimension
All Stainless Steel Tube are Manufactured and Inspected / Tested to the Relevant standards including ASTM and ASME
Value Added Services
Draw / Expansion / Machining / Sand Blasting / Shot Blasting / Heat Treatment
Packaging
Loose / Bundle / Wooden Pallet / Wooden Box / Plastic Cloth Wraps / Plastic End Caps / Beveled Protector
Material Test Certificate
Manufacturer Test Certificate As Per EN10204 3.1, 3.2 / Laboratory Test Certificate From NABL Approved Lab. / Under Third Party Inspection Agency Like SGS, TUV, DNV, LLOYDS, ABS ETC
Delivery
By Road – Truck / Train, By Sea – Break-bulk Conventional Vessel / FCL (Full Container Load) / LCL (Less Container Load) / 20 Feet Container / 30 Feet Container / 35 Feet Container / High Cube Container / Open Top Container, By Air – Freighter Civil Passenger and Cargo Planes


We offering Stainless Steel Tube having a durable mill finish which is widely used for all types of fabrication projects that are exposed to the elements - chemical, fresh water, acidic, and saltwater environments. SS 304 Tube has inside and outside radius corners, with a protruding interior weld seam. Stainless Steel Tube are used for pressure operations such as moving liquids and gases in processing operations in the chemical, petrochemical, water treatment, food processing, dairy and marine industries. SS 304 Tube is ideal for all structural applications where greater strength and superior corrosion resistance is required. Siddhgiri tubes Steel Industries is specialized as providing Stainless Steel Tube in Grit 120 - 600 finish. We are one of the largest stockist and supplier of Stainless Steel Tube includes grades Stainless Steel 304L Tube, Stainless Steel 316 Tube, Stainless steel 316L Tube, and Stainless Steel 201 Tube those are used in various industrial applications

Stainless Steel Tube SIZES

stainless steel Tube are finished in accordance with customer needs regarding dimensional and wall thickness specifications as well as heat treatment for more demanding applications. In general a Stainless Steel Tube is manufactured in sizes from 1/8” to 24” according to current standards ASTM, API and ASME. If required for special projects we can also supply SS Square seamless pipes & SS Square welded pipes for bigger sizes starting from outside diameter 26” up to 48”. More Information of Stainless Steel Pipe Sizes and Stainless Steel Tube weight chart <>

  • • Machinery
  • • Automative
  • • Transport
  • • construction
  • • Home and commercial fixtures
    • Size
    OD, Inches
    BW
    Ga.
    Wall
    Dec-In.
    ID
    Weight
    Lbs/Ft.
    1/8
    22
    0.028
    0.069
    0.0290
    20
    0.035
    0.055
    0.0336
    3/16
    22
    0.028
    0.131
    0.0478
    1/4





    25
    0.020
    0.210
    0.0491
    22
    0.028
    0.194
    0.0664
    21
    0.032
    0.187
    0.0745
    20
    0.035
    0.180
    0.0804
    18
    0.049
    0.152
    0.1052
    16
    0.065
    0.120
    0.1284
    5/16


    20
    0.035
    0.242
    0.1039
    18
    0.049
    0.214
    0.1382
    16
    0.065
    0.182
    0.1722
    3/8



    22
    0.028
    0.319
    0.1038
    20
    0.035
    0.305
    0.1271
    18
    0.049
    0.277
    0.1706
    16
    0.065
    0.245
    0.2152
    7/16
    18
    0.049
    0.340
    0.2036
    1/2



    25
    0.020
    0.460
    0.1025
    20
    0.035
    0.430
    0.1738
    18
    0.049
    0.402
    0.2360
    16
    0.065
    0.370
    0.3020
    5/8


    20
    0.035
    0.555
    0.2205
    18
    0.049
    0.527
    0.3014
    16
    0.065
    0.495
    0.3888
    3/4



    20
    0.035
    0.680
    0.2673
    18
    0.049
    0.652
    0.3668
    16
    0.065
    0.620
    0.4755
    14
    0.083
    0.584
    0.5913
    7/8


    18
    0.049
    0.777
    0.4323
    16
    0.065
    0.745
    0.5623
    11
    0.120
    0.635
    0.9676
    1




    20
    0.035
    0.930
    0.3607
    18
    0.049
    0.902
    0.4977
    16
    0.065
    0.870
    0.6491
    14
    0.083
    0.834
    0.8129
    11
    0.120
    0.760
    1.1278
    1-1/4
    11
    0.120
    1.010
    1.4480

    Stainless Steel Tube DIMENSIONS AND WEIGHTS

    NOMINAL

    SIZE

    		 OUTSIDE DIAMETER (INCHES)
    1/2" 0.84
    3/4" 1.05
    1" 1.315
    1-1/4" 1.66
    1-1/2" 1.9
    2" 2.375
    2-1/2" 2.875
    3" 3.5
    3-1/2" 4

    Stainless Steel Square Hollow Section / Size / Dimensions / Weight Chart

    Size (mm) Thickness (mm) Kg / Metre
    20 X 20 Size (mm) 2 Thickness (mm) 1.11 Kg / Metre
    25 X 25 Size (mm) 2 Thickness (mm) 1.43 Kg / Metre
    25 X 25 Size (mm) 2.5 Thickness (mm) 1.74 Kg / Metre
    25 X 25 Size (mm) 3 Thickness (mm) 2.04 Kg / Metre
    30 X 30 Size (mm) 2 Thickness (mm) 1.74 Kg / Metre
    30 X 30 Size (mm) 2.5 Thickness (mm) 2.14 Kg / Metre
    30 X 30 Size (mm) 3 Thickness (mm) 2.51 Kg / Metre
    30 X 30 Size (mm) 3.2 Thickness (mm) 2.65 Kg / Metre
    40 X 40 Size (mm) 2 Thickness (mm) 2.37 Kg / Metre
    40 X 40 Size (mm) 2.5 Thickness (mm) 2.92 Kg / Metre
    40 X 40 Size (mm) 3 Thickness (mm) 3.45 Kg / Metre
    40 X 40 Size (mm) 4 Thickness (mm) 4.46 Kg / Metre
    40 X 40 Size (mm) 5 Thickness (mm) 5.40 Kg / Metre
    50 X 50 Size (mm) 2 Thickness (mm) 3.00 Kg / Metre
    50 X 50 Size (mm) 2.5 Thickness (mm) 3.71 Kg / Metre
    50 X 50 Size (mm) 3 Thickness (mm) 4.39 Kg / Metre
    50 X 50 Size (mm) 4 Thickness (mm) 5.72 Kg / Metre
    50 X 50 Size (mm) 5 Thickness (mm) 6.97 Kg / Metre
    50 X 50 Size (mm) 6 Thickness (mm) 8.20 Kg / Metre
    50 X 50 Size (mm) 8 Thickness (mm) 10.50 Kg / Metre
    60 X 60 Size (mm) 3 Thickness (mm) 5.34 Kg / Metre
    60 X 60 Size (mm) 3.2 Thickness (mm) 5.67 Kg / Metre
    60 X 60 Size (mm) 3.6 Thickness (mm) 6.34 Kg / Metre
    60 X 60 Size (mm) 4 Thickness (mm) 6.97 Kg / Metre
    60 X 60 Size (mm) 5 Thickness (mm) 8.54 Kg / Metre
    70 X 70 Size (mm) 2.5 Thickness (mm) 5.28 Kg / Metre
    70 X 70 Size (mm) 3 Thickness (mm) 6.28 Kg / Metre
    70 X 70 Size (mm) 3.5 Thickness (mm) 7.25 Kg / Metre
    70 X 70 Size (mm) 3.6 Thickness (mm) 7.46 Kg / Metre
    70 X 70 Size (mm) 4 Thickness (mm) 8.23 Kg / Metre
    70 X 70 Size (mm) 5 Thickness (mm) 10.10 Kg / Metre
    70 X 70 Size (mm) 8 Thickness (mm) 15.29 Kg / Metre
    70 X 70 Size (mm) 10 Thickness (mm) 19.13 Kg / Metre
    80 X 80 Size (mm) 3 Thickness (mm) 7.22 Kg / Metre
    80 X 80 Size (mm) 3.5 Thickness (mm) 8.35 Kg / Metre
    80 X 80 Size (mm) 3.6 Thickness (mm) 8.59 Kg / Metre
    80 X 80 Size (mm) 4 Thickness (mm) 9.48 Kg / Metre
    80 X 80 Size (mm) 5 Thickness (mm) 11.70 Kg / Metre
    80 X 80 Size (mm) 6 Thickness (mm) 13.80 Kg / Metre
    80 X 80 Size (mm) 6.3 Thickness (mm) 14.40 Kg / Metre
    80 X 80 Size (mm) 8 Thickness (mm) 17.83 Kg / Metre
    80 X 80 Size (mm) 10 Thickness (mm) 21.88 Kg / Metre
    90 X 90 Size (mm) 3 Thickness (mm) 8.16 Kg / Metre
    90 X 90 Size (mm) 3.5 Thickness (mm) 9.45 Kg / Metre
    90 X 90 Size (mm) 3.6 Thickness (mm) 9.72 Kg / Metre
    90 X 90 Size (mm) 4 Thickness (mm) 10.70 Kg / Metre
    90 X 90 Size (mm) 5 Thickness (mm) 13.30 Kg / Metre
    90 X 90 Size (mm) 6 Thickness (mm) 15.70 Kg / Metre
    90 X 90 Size (mm) 6.3 Thickness (mm) 16.40 Kg / Metre
    90 X 90 Size (mm) 8 Thickness (mm) 20.32 Kg / Metre
    90 X 90 Size (mm) 10 Thickness (mm) 25.53 Kg / Metre
    100 X 100 Size (mm) 3 Thickness (mm) 9.10 Kg / Metre
    100 X 100 Size (mm) 4 Thickness (mm) 12.00 Kg / Metre
    100 X 100 Size (mm) 5 Thickness (mm) 14.80 Kg / Metre
    100 X 100 Size (mm) 6 Thickness (mm) 17.60 Kg / Metre
    100 X 100 Size (mm) 6.3 Thickness (mm) 18.40 Kg / Metre
    100 X 100 Size (mm) 8 Thickness (mm) 22.90 Kg / Metre
    100 X 100 Size (mm) 10 Thickness (mm) 27.86 Kg / Metre
    100 X 100 Size (mm) 12 Thickness (mm) 33.44 Kg / Metre
    120 X 120 Size (mm) 4 Thickness (mm) 14.50 Kg / Metre
    120 X 120 Size (mm) 5 Thickness (mm) 18.00 Kg / Metre
    120 X 120 Size (mm) 6 Thickness (mm) 21.30 Kg / Metre
    120 X 120 Size (mm) 6.3 Thickness (mm) 22.30 Kg / Metre
    120 X 120 Size (mm) 8 Thickness (mm) 27.90 Kg / Metre
    120 X 120 Size (mm) 10 Thickness (mm) 34.13 Kg / Metre
    120 X 120 Size (mm) 12 Thickness (mm) 39.94 Kg / Metre
    120 X 120 Size (mm) 16 Thickness (mm) 54.64 Kg / Metre
    140 X 140 Size (mm) 6 Thickness (mm) 25.97 Kg / Metre
    140 X 140 Size (mm) 8 Thickness (mm) 32.89 Kg / Metre
    140 X 140 Size (mm) 10 Thickness (mm) 41.15 Kg / Metre
    150 X 150 Size (mm) 4 Thickness (mm) 18.30 Kg / Metre
    150 X 150 Size (mm) 5 Thickness (mm) 22.70 Kg / Metre
    150 X 150 Size (mm) 6 Thickness (mm) 27.00 Kg / Metre
    150 X 150 Size (mm) 6.3 Thickness (mm) 28.30 Kg / Metre
    150 X 150 Size (mm) 8 Thickness (mm) 35.40 Kg / Metre
    150 X 150 Size (mm) 10 Thickness (mm) 43.47 Kg / Metre
    150 X 150 Size (mm) 12 Thickness (mm) 53.48 Kg / Metre
    150 X 150 Size (mm) 16 Thickness (mm) 65.05 Kg / Metre
    160 X 160 Size (mm) 6 Thickness (mm) 27.39 Kg / Metre
    160 X 160 Size (mm) 8 Thickness (mm) 36.90 Kg / Metre
    160 X 160 Size (mm) 10 Thickness (mm) 46.88 Kg / Metre
    180 X 180 Size (mm) 5 Thickness (mm) 27.97 Kg / Metre
    180 X 180 Size (mm) 6 Thickness (mm) 33.26 Kg / Metre
    180 X 180 Size (mm) 8 Thickness (mm) 43.00 Kg / Metre
    180 X 180 Size (mm) 10 Thickness (mm) 53.00 Kg / Metre
    180 X 180 Size (mm) 12 Thickness (mm) 61.01 Kg / Metre
    180 X 180 Size (mm) 12.5 Thickness (mm) 65.20 Kg / Metre
    180 X 180 Size (mm) 16 Thickness (mm) 81.30 Kg / Metre
    200 X 200 Size (mm) 5 Thickness (mm) 31.18 Kg / Metre
    200 X 200 Size (mm) 6 Thickness (mm) 37.09 Kg / Metre
    200 X 200 Size (mm) 8 Thickness (mm) 48.00 Kg / Metre
    200 X 200 Size (mm) 10 Thickness (mm) 59.30 Kg / Metre
    200 X 200 Size (mm) 12 Thickness (mm) 68.84 Kg / Metre
    200 X 200 Size (mm) 12.5 Thickness (mm) 73.00 Kg / Metre
    200 X 200 Size (mm) 16 Thickness (mm) 90.91 Kg / Metre
    250 X 250 Size (mm) 6 Thickness (mm) 46.83 Kg / Metre
    250 X 250 Size (mm) 8 Thickness (mm) 60.50 Kg / Metre
    250 X 250 Size (mm) 10 Thickness (mm) 75.00 Kg / Metre
    250 X 250 Size (mm) 12 Thickness (mm) 88.45 Kg / Metre
    250 X 250 Size (mm) 12.5 Thickness (mm) 92.70 Kg / Metre
    250 X 250 Size (mm) 16 Thickness (mm) 111.48 Kg / Metre
    300 X 300 Size (mm) 6 Thickness (mm) 55.30 Kg / Metre
    300 X 300 Size (mm) 8 Thickness (mm) 74.18 Kg / Metre
    300 X 300 Size (mm) 10 Thickness (mm) 90.70 Kg / Metre
    300 X 300 Size (mm) 12 Thickness (mm) 108.68 Kg / Metre
    300 X 300 Size (mm) 12.5 Thickness (mm) 112.00 Kg / Metre
    300 X 300 Size (mm) 16 Thickness (mm) 141.84 Kg / Metre
    350 X 350 Size (mm) 10 Thickness (mm) 105.93 Kg / Metre
    350 X 350 Size (mm) 12 Thickness (mm) 126.74 Kg / Metre
    350 X 350 Size (mm) 16 Thickness (mm) 166.94 Kg / Metre
    400 X 400 Size (mm) 8 Thickness (mm) 97.56 Kg / Metre
    400 X 400 Size (mm) 10 Thickness (mm) 121.95 Kg / Metre
    400 X 400 Size (mm) 12 Thickness (mm) 151.97 Kg / Metre
    400 X 400 Size (mm) 16 Thickness (mm) 191.94 Kg / Metr
    Size kg / m
    12 x 12 x 1.5 mm 0.59
    15 x 15 x 1.2 mm 0.54
    15 x 15 x 1.5 mm 0.66
    20 x 20 x 1.2 mm 0.73
    20 x 20 x 1.5 mm 0.90
    20 x 20 x 2.0 mm 0.18
    25 x 25 x 1.2 mm 0.93
    25 x 25 x 1.5 mm 1.15
    25 x 25 x 2.0 mm 1.50
    25 x 25 x 3.0 mm 2.22
    30 x 30 x 1.2 mm 1.11
    30 x 30 x 1.5 mm 1.37
    30 x 30 x 2.0 mm 1.84
    30 x 30 x 3.0 mm 2.72
    40 x 40 x 1.2 mm 1.50
    40 x 40 x 1.5 mm 1.86
    40 x 40 x 2.0 mm 2.45
    40 x 40 x 3.0 mm 3.76

    Stainless Steel Tube SCHEDULE CHART

    NB SIZES SCH 5 SCH 10 SCH 40 SCH 80 SCH 160
    1/8″

    1/4″

    3/8″

    1/2″
    3/4″
    1″
    1 1/4″
    1 1/2″
    2″
    2 1/2″
    3″
    4″
    5″

    6″


    SS SQUARE PIPE NOMINAL BORE SCHEDULE SIZES

    Nominal SS Schedule 5 SS Schedule 10 SS Schedule 40
    Inch MM Wt./MM Kg./M Kg./Ft Wt./MM Kg./M Kg./Ft Wt./MM Kg./M Kg./Ft
    1 / 2 21 1.65 0.801 0.244 2.11 0.999 0.305 2.77 1.270 0.387
    3 / 4 21.30 1.65 1.020 0.311 2.11 1.280 0.390 2.87 1.680 0.512
    1 26.70 1.65 1.290 0.393 2.77 2.090 0.637 3.38 2.500 0.762
    1 1 / 4 33.40 1.65 1.650 0.503 2.77 2.690 0.820 3.56 3.380 1.030
    1 1 / 2 42.20 1.65 1.900 0.579 2.77 3.110 0.948 3.68 4.050 1.230
    2 48.30 1.65 3.340 0.728 2.77 3.920 1.200
    2 1 / 2 73.00 2.11 3.690 1.130 3.05 5.260 1.600
    3 88.90 2.11 4.510 1.380 3.05 6.450 1.970
    3 1 / 2 101.60 2.11 5.190 1.580 3.05 7.400 2.260

    Stainless Steel Tube PRESSURE RATING

    Pressure Rating (psig)
    Pipe Size
    (inches)    		 Pipe Schedule Temperature (oF)
    100 200 300 400 500 600 650 700 750
    1" 40 3048 2629 2362 2171 2019 1924 1867 1824 1810
    80 4213 3634 3265 3002 2791 2659 2580 2528 2501
    160 6140 5296 4759 4375 4068 3876 3761 3684 3646
    1 1/2" 40 2257 1947 1750 1608 1496 1425 1383 1354 1340
    80 3182 2744 2466 2267 2108 2009 1949 1909 1889
    160 4619 3984 3580 3291 3060 2916 2829 2772 2743
    2" 40 1902 1640 1474 1355 1260 1201 1165 1141 1129
    80 2747 2369 2129 1957 1820 1734 1682 1648 1631
    160 4499 3880 3486 3205 2980 2840 2755 2699 2671
    3" 40 1806 1558 1400 1287 1196 1140 1106 1084 1072
    80 2553 2202 1979 1819 1691 1612 1564 1532 1516
    160 3840 3312 2976 2736 2544 2424 2352 2304 2280
    4" 40 1531 1321 1187 1091 1014 967 938 919 909
    80 2213 1909 1715 1577 1466 1397 1355 1328 1314
    160 3601 3106 2791 2566 2386 2273 2206 2161 2138
    5" 40 1342 1158 1040 956 889 847 822 805 797
    80 1981 1709 1535 1411 1312 1250 1213 1189 1176
    160 3414 2945 2646 2433 2262 2155 2091 2049 2027
    6" 40 1219 1052 945 869 808 770 747 732 724
    80 1913 1650 1483 1363 1267 1208 1172 1148 1136
    160 3289 2836 2549 2343 2179 2076 2014 1973 1953
    8" 40 1073 926 832 765 711 678 657 644 637
    80 1692 1459 1311 1205 1121 1068 1036 1015 1005
    160 3175 2738 2460 2262 2103 2004 1944 1905 1885
    10" 40 974 840 755 694 645 615 596 584 578
    80 1609 1388 1247 1147 1066 1016 986 966 956
    160 3147 2714 2439 2242 2085 1986 1927 1880 1868

    Chemical Composition

    GRADES UNS C Mn P S Si Cr Ni Mo Ti Nb N
    TP304 S30400 0.08 2 0.045 0.03 1 18.0-20.0 8.0-11.0
    TP304L S30403 0.035 2 0.045 0.03 1 18.0-20.0 8.0-13.0
    TP316 S3160 0.08 2 0.045 0.03 1 16.0-18.0 11.0-14.0 2.0-3.0
    TP316L S31603 0.035 2 0.045 0.03 1 16.0-18.0 10.0-14.0 2.0-3.0

    Nominal Wall Thickness:

  • Nominal Wall Tolerance Plus 12.5%, Minus 12.5%
  • These do not conform to the American National Standard for Welded and Seamless Wrought Steel Pipe (ANSI B 36.10 – 1979)
    • NPS Designator Outside Diameter in. Schedule 10S in. Schedule 40S in. Schedule 80S in. Schedule 160 in. Schedule XX in.
    1/4 0.540 0.065 0.088 0.119
    3/8 0.675 0.065 0.091 0.126
    1/2 0.840 0.083 0.109 0.147 .188 .294
    3/4 1.050 0.083 0.113 0.154 .218 .308
    1.0 1.315 0.109 0.133 0.179 .250 .358
    1 1/4 1.660 0.109 0.140 0.191 .250 .382
    1 1/2 1.900 0.109 0.145 0.200 .281 .400
    2 2.375 0.109 0.154 0.218 .343 .436
    2 1/2 2.875 0.120 0.203 0.276 .375 .552
    3 3.500 0.120 0.216 0.300 .438 .600
    3 1/2 4.000 0.120 0.226 0.318   .636
    4 4.500 0.120 0.237 0.337 .534 .674
    5 5.563 0.134 0.258 0.375 .625 .750
    6 6.625 0.134 0.280 0.432 .719 .864
    8 8.625 0.148 0.322 0.500 .906 .875
    10 10.750 0.165 0.365 0.500 1.125
    12 12.750 0.180 0.375 0.500 1.312
    14 14.000 0.188 0.375 0.500 1.406
    16 16.000 0.188 0.375 0.500 1.594

    Minimum Wall Thickness on Inspection:

  • The following equation, upon which this table is based, may be applied to calculate minimum wall thicknesses from nominal wall thickness:
    • tn * 0.875 = tm Where: tn = nominal wall thickness, in. [mm], and tm= minimum wall thicknesses, in. [mm]
    • The wall thickness is inch-pound units is rounded to three decimal places in accordance with the rounding method of Practice E29. The wall thickness in SI units is rounded to one decimal place in accordance with the rounding method of Practice E29.
  • This table is a master table covering wall thicknesses available in the purchase of different classifications of pipe, but it is not meant to imply that all the walls listed herein are necessarily obtainable for the applicable product specification.
    • Nominal Thickness Minimum Thickness on Inspection Nominal Thickness Minimum Thickness on Inspection Nominal Thickness Minimum Thickness on Inspection
    in. mm in mm in mm in mm in mm in mm
    0.068 1.7 0.060 1.5 0.294 7.5 0.257 6.5 0.750 19.0 0.658 16.6
    0.068 2.2 0.077 2.0 0.300 7.6 0.262 6.7 0.812 20.6 0.710 18.0
    0.091 2.3 0.080 2.0 0.307 7.8 0.269 6.8 0.843 21.4 0.736 18.7
    0.095 2.4 0.083 2.1 0.308 7.8 0.270 6.9 0.854 21.7 0.756 19.2
    0.113 2.9 0.099 2.5 0.312 7.9 0.273 6.9 0.875 22.2 0.766 19.5
    0.119 3.0 0.104 2.6 0.318 8.1 0.278 7.1 0.906 23.0 0.783 20.1
    0.125 3.2 0.109 2.8 0.322 8.2 0.282 7.2 0.937 23.8 0.820 20.8
    0.126 3.2 0.110 2.8 0.330 8.4 0.289 7.3 0.968 24.6 0.847 21.5
    0.133 3.4 0.116 2.9 0.337 8.6 0.295 7.5 1.000 25.4 0.875 22.2
    0.140 3.6 0.122 3.1 0.343 8.7 0.300 7.6 1.031 26.2 0.902 22.9
    0.145 3.7 0.127 3.2 0.344 8.7 0.301 7.6 1.062 27.0 0.929 23.6
    0.147 3.7 0.129 3.3 0.358 9.1 0.313 8.0 1.083 27.8 0.956 24.3
    0.154 3.9 0.135 3.4 0.365 9.3 0.319 8.1 1.125 28.6 0.984 25.0
    0.156 4.0 0.136 3.5 0.375 9.5 0.328 8.3 1.156 29.4 1.012 25.7
    0.179 4.5 0.157 4.0 0.382 9.7 0.334 8.5 1.218 30.9 1.066 27.1
    0.187 43.7 0.164 4.2 0.400 10.2 0.350 8.9 1.250 31.8 1.094 27.8
    0.188 4.8 0.164 4.2 0.406 10.3 0.355 9.0 1.281 32.5 1.121 28.5
    0.191 4.9 0.167 4.2 0.432 10.4 0.378 9.6 1.312 33.3 1.148 29.2
    0.200 5.1 0.175 4.4 0.436 11.1 0.382 9.7 1.343 34.1 1.175 29.8
    0.203 5.2 0.178 4.5 0.437 11.1 0.382 9.7 1.375 34.9 1.203 30.6
    0.216 5.5 0.189 4.8 0.438 11.1 0.383 9.7 1.406 35.7 1.230 31.2
    0.218 5.5 0.191 4.9 0.500 12.7 0.438 11.1 1.436 36.5 1.258 32.0
    0.219 5.6 0.192 4.9 0.531 13.5 0.465 11.8 1.500 36.1 1.312 33.3
    0.226 5.7 0.196 5.0 0.552 14.0 0.483 12.3 1.531 38.9 1.340 34.0
    0.237 6.0 0.207 5.2 0.562 14.3 0.492 12.5 1.562 39.7 1.367 34.7
    0.250 6.4 0.219 5.6 0.593 15.1 0.519 13.2 1.593 40.5 1.394 35.4
    0.258 6.6 0.226 5.7 0.600 15.2 0.525 13.3 1.750 44.5 1.531 38.9
    0.276 7.0 0.242 6.1 0.625 15.9 0.547 13.9 1.781 45.2 1.558 39.6
    0.277 7.0 0.242 6.1 0.656 16.6 0.573 14.6 1.812 46.0 1.586 49.3
    0.279 7.1 0.244 6.2 0.674 17.1 0.590 15.0 1.968 50.0 1.772 43.7
    0.280 7.1 0.245 6.2 0.687 17.4 0.601 15.3 2.062 52.4 1.804 45.8
    0.281 7.1 0.246 6.2 0.719 18.3 0.629 16.0 2.343 59.5 2.050 52.1

    Stainless Steel Tubing CHEMICAL COMPOSITION

    The below table shows the chemical composition of the used for Stainless Steel Pipes:

    GRADES UNS C Mn P S Si Cr Ni Mo Ti Nb N
    TP304 S30400 0.08 2 0.045 0.03 1 18.0-20.0 8.0-11.0
    TP304L S30403 0.035 2 0.045 0.03 1 18.0-20.0 8.0-13.0
    TP316 S3160 0.08 2 0.045 0.03 1 16.0-18.0 11.0-14.0 2.0-3.0
    TP316L S31603 0.035 2 0.045 0.03 1 16.0-18.0 10.0-14.0 2.0-3.0

    Stainless Steel Tubing MECHANICAL PROPERTIES

    Material Heat Temperure Tensile Strength Yield Strength Elongation %, Min
    Treatment Min. Ksi (MPa), Min. Ksi (MPa), Min.
      º F(º C)
    TP304 Solution 1900 (1040) 75(515) 30(205) 35
    TP304L Solution 1900 (1040) 70(485) 25(170) 35
    TP316 Solution 1900(1040) 75(515) 30(205) 35
    TP316L Solution 1900(1040) 70(485) 25(170) 35

    AVAILABLE STOCK OF STAINLESS STEEL TUBE

    Stainless Steel Seamless Square Tube Supplier & Manufacturer in USA SS Seamless Square Tube Supplier
    Seamless SS Square Tube Supplier & Manufacturer in USA SS Polished Square Tube Supplier & Manufacturer in USA
    Stainless Steel Tubing Suppliers & Manufacturer in USA Stainless Steel Tubing Exporter
    304 Stainless Steel Tubing Suppliers & Manufacturer in USA 316L Stainless Steel Tubing
    SS Square Tube Hollow Sections Supplier & Manufacturer in USA ASTM A312 TP304 SS Square Tube Supplier & Manufacturer in USA
    SS Bright Annealed Square Tube ASTM A312 TP304LStainless Steel Supplier & Manufacturer in USA
    Stainless Steel 201 Square Tube Supplier & Manufacturer in USA Stainless Steel Square 316 Pipe Supplier
    Large Diameter Stainless Steel Tubing ASTM A312 TP304/304L SS Square Tube Supplier & Manufacturer in USA
    SS Square Tube Supplier & Manufacturer in USA ASTM A312 TP316 Stainless Steel Supplier & Manufacturer in USA
    Hot Rolled Stainless Steel Tubing Suppliers & Manufacturer in USA ASTM A312 TP316L Stainless SS & Manufacturer in USA
    1/2″ NB in Thickness Schedule Stainless Steel Tubing ASTM A312 TP201 Stainless Steel Tubing
    4″ NB in Thickness Schedule SS Square Tube Supplier & Manufacturer in USA ASTM A312 TP316/316L Stainless Steel Tubing Suppliers
    5″ NB in Thickness Schedule SS Square Tube Supplier & Manufacturer in USA Schedule 40 SS Square Tube Supplier & Manufacturer in USA
    6″ NB in Thickness Schedule Stainless Steel Tubing Suppliers & Manufacturer in USA Schedule 80 Stainless Steel Tubing Suppliers & Manufacturer in USA
    7″ NB in Thickness Schedule SS Square Tube Supplier & Manufacturer in USA Schedule 10 SS Square Tube Supplier
    8″ NB in Thickness Schedule Stainless Steel Tubing Suppliers & Manufacturer in USA Sch 5 Stainless Steel Tubing Suppliers
    14″ NB in Thickness Schedule SS Square Tube Supplier Stainless Steel Tubing Weight per meter
    16″ NB in Thickness Schedule Stainless Steel Tubing Supplier & Manufacturer in USA Weight of Stainless Steel Tubing
    18″ NB in Thickness Schedule SS Square Tube Supplier Stainless Steel Tubing Price in USA

    PACKAGING AND LABELING

    To ensure the safe transportation of our products, we take meticulous care in packaging them. In the case of exports, we employ standard wooden cases for packaging. Each pipe is marked with essential information, including Grade, Lot No, Size, Degree, and our trademark. Furthermore, we can provide custom markings on our products upon special requests.

    QUALITY ASSURANCE

    Our Products maintains stringent quality control measures for all fittings and bars throughout every production stage, from the procurement of raw materials to the dispatch of the final products. Visual inspections ensure compliance with industry-standard codes and regulations such as ASTM, ASME, MSS, DIN, EN, and JIS. Should the need arise, we can arrange for official certified Inspection Agencies to witness material reports, dimensions, and product quality conformity.

    TEST CERTIFICATES

    Our products come with a Manufacturer Test Certificate per EN 10204 / 3.1B and a Raw Materials Certificate. In addition, they undergo a 100% Radiography Test, and Third Party Inspection Reports can also be provided.

    SHIPPING POLICY

    The delivery time and dates are determined based on the type and quantity of steel ordered. Our sales team will provide a delivery schedule when you request a quotation. Please note that the delivery schedule may occasionally be subject to change, so we recommend checking with our sales department when placing your orders. Orders are typically dispatched within 2-3 business days and may take 5-10 business days to reach their destination. If Forgings are out of stock, orders may require 2-4 weeks for shipping. Our Products will promptly notify the buyer if such a situation occurs.

    Aluminium Rods

    Stainless Steel Polish Tube

    Aluminium Rod

    Stainless Steel seamles Tube

    Aluminium Rod

    Stainless Steel welded tube

    Aluminium Rod

    Stainless Steel Round Tube

    Industry We Serve

    Application Industry

    Cities We Deliver To

    Istanbul, Coimbatore, Jamshedpur, Haryana, Dammam, Ankara, Hyderabad, Sharjah, Kuala Lumpur, Mumbai, Surat, Ranchi, Pune, Bangkok, Busan, Kuwait City, Singapore, Indore, Vadodara, Madrid, Al Jubail, Dallas, Faridabad, Secunderabad, Toronto, Petaling Jaya, Brisbane, Jaipur, Thiruvananthapuram, Colombo, Atyrau, Algiers, Los Angeles, Houston, Visakhapatnam, Tehran, Thane, Doha, Hanoi, Edmonton, Karachi, Cairo, Gurgaon, Jakarta, Ahmedabad, Geoje-si, Ho Chi Minh City, Chiyoda, Kanpur, Riyadh, Rajkot, Bhopal, La Victoria, Milan, Muscat, Chennai, Bogota, Gimhae-si, New York, Ernakulam, Granada, Santiago, Ludhiana, Dubai, Kolkata, Caracas, Howrah, Jeddah, Lahore, Courbevoie, Perth, Pimpri-Chinchwad, Aberdeen, Manama, Nagpur, Ahvaz, Montreal, Seoul, Bengaluru, Sydney, Al Khobar, Lagos, Calgary, Vung Tau, New Delhi, Nashik, Ulsan, Noida, Mexico City, Hong Kong, Rio de Janeiro, Abu Dhabi, Melbourne, Chandigarh, Baroda, Port-of-Spain, London, Navi Mumbai, Moscow.

    Countries We Deliver To

    Peru, Kazakhstan, Bolivia, Bhutan, Poland, Nigeria, China, Bangladesh, Norway, Estonia, Costa Rica, Taiwan, Sri Lanka, Qatar, Iran, Canada, Zimbabwe, Malaysia, Morocco, Denmark, Poland, Thailand, Egypt, Iran, Gabon, Lithuania, Netherlands, Belgium, Bulgaria, Bahrain, Mexico, Japan, Turkey, Portugal, Venezuela, South Korea, Ecuador, United Arab Emirates, Namibia, Hong Kong, Ghana, Slovakia, Germany, Austria, Vietnam, Gambia, Mongolia, Ireland, Italy, Romania, United States, Kuwait, Spain, Indonesia, Greece, France, Chile, Czech Republic, Nigeria, Israel, Tunisia, Libya, Ukraine, Nepal, Jordan, Brazil, Serbia, Afghanistan, South Africa, Lebanon, Chile, Angola, Philippines, Hungary, Mexico, Yemen, United Kingdom, Sweden, Tibet, Macau, Kenya, Puerto Rico, New Zealand, Singapore, Algeria, Azerbaijan, Oman, Pakistan, India, Saudi Arabia, Russia, Iraq, Australia, Finland, Colombia, Argentina, Croatia, Belarus, Switzerland, Trinidad & Tobago.

    Other Available Products of Stainless steel Tube

    »   Stainless Steel Round Tube
    »   Stainless Steel Rectangular Tube
    »   Stainless Steel Hydraulic Tube
    »   Stainless Steel Oval Tube
    »   Stainless Steel 304 Tube
    »   Stainless Steel 304L Tube
    »   Stainless Steel ERW Tube
    »   Stainless Steel 316 Tube
    »   Stainless Steel 316L Tube

    »   Stainless Steel Hollow Tube
    »   Stainless Steel Perforated Tube

    People also search for Stainless Steel Products

    Stainless Steel Tube price per kg, Stainless Steel Tubing manufacturers in USA, Stainless Steel Rectangular Tube, Stainless Steel Perforated Tube.
